Maintenance
Tread: The portion of a tire that
Vehicle Normal Load on the Tire:
All season tires
comes into contact with the road.
Load on an individual tire that is
HYUNDAI specifies all season tires
determined by distributing to each
Treadwear Indicators: Narrow
on some models to provide good
axle its share of the curb weight,
bands, sometimes called "wear bars",
performance for use all year round,
accessory weight, and normal occu-
that show across the tread of a tire
including snowy and icy road condi-
pant weight and dividing by 2.
when only 2/32 inch of tread remains.
tions. All season tires are identified
UTQGS: Uniform Tire Quality
Vehicle Placard: A label permanent-
by ALL SEASON and/or M+S (Mud
Grading Standards, a tire information
ly attached to a vehicle showing the
and Snow) on the tire sidewall. Snow
system that provides consumers with
original equipment tire size and rec-
tires have better snow traction than
ratings for a tire's traction, tempera-
ommended inflation pressure.
all season tires and may be more
ture and treadwear. Ratings are
appropriate in some areas.
determined by tire manufacturers
using government testing proce-
Summer tires
dures. The ratings are molded into
HYUNDAI specifies summer tires on
the sidewall of the tire.
some models to provide superior
Vehicle Capacity Weight: The num-
performance on dry roads. Summer
ber of designated seating positions
tire performance is substantially
multiplied by 150 lbs. (68 kg) plus the
reduced in snow and ice. Summer
rated cargo and luggage load.
tires do not have the tire traction rat-
Vehicle Maximum Load on the Tire:
ing M+S (Mud and Snow) on the tire
Load on an individual tire due to curb
side wall. if you plan to operate your
and accessory weight plus maximum
vehicle in snowy or icy conditions.
occupant and cargo weight.
HYUNDAI recommends the use of
snow tires or all season tires on all
four wheels.
7 60
Maintenance
Snow tires
Tire chains
WARNING - Snow or ice
If you equip your car with snow tires,
Tire chains, if necessary, should be
they should be the same size and
installed on the drive wheels as fol-
•
When driving on roads covered
with snow or ice, drive at less
have the same load capacity as the
lows.
original tires. Snow tires should be
than 20 mph (30 km/h).
2WD : Front wheels
installed on all four wheels; other-
•
Use the SAE "S" class or wire
AWD : All four wheels
wise, poor handling may result.
chains.
If a full set of chains is not
Snow tires should carry 4 psi (28
•
If you hear noise caused by
available for a AWD vehicle,
kPa) more air pressure than the
chains contacting the body,
chains may be installed on
pressure recommended for the stan-
retighten the chain to avoid
the front wheels only.
dard tires on the tire label on the dri-
contact with the vehicle body.
ver's side of the center pillar, or up to
Be sure that the chains are installed
•
To prevent body damage,
the maximum pressure shown on the
in accordance with the manufactur-
retighten the chains after driv-
tire sidewall, whichever is less.
er's instructions.
ing 0.3~0.6 miles (0.5~1.0 km).
Do not drive faster than 75 mph (120
To minimize tire and chain wear, do
•
Do not use tire chains on vehi-
km/h) when your car is equipped with
not continue to use tire chains when
cles equipped with aluminum
snow tires.
they are no longer needed.
wheels. In unavoidable circum-
stance, use a wire type chain.
•
Use wire chains less than 0.59
inches (15mm) to prevent dam-
age to the chain's connection.
7 61
Maintenance
Radial-ply tires
Low aspect ratio tire
CAUTION
(if equipped)
Radial-ply tires provide improved
Because the sidewall of the low
tread life, road hazard resistance and
Low aspect ratio tires, whose aspect
aspect ratio tire is shorter than
smoother high speed ride. The radi-
ratio is lower than 50, are provided
the normal, the wheel and tire of
al-ply tires used on this vehicle are of
for sporty looks.
the low aspect ratio tire is easi-
belted construction, and are selected
Because the low aspect ratio tires
er to be damaged. So, follow the
to complement the ride and handling
are optimized for handling and brak-
instructions below.
characteristics of your vehicle.
ing, it may be more uncomfortable to
Radial-ply tires have the same load
• When driving on a rough road
ride in and there is more noise com-
carrying capacity, as bias-ply or bias
or off road, drive cautiously
pare with normal tires.
belted tires of the same size, and use
because tires and wheels may
the same recommended inflation
be damaged. And after driv-
pressure. Mixing of radial-ply tires
ing, inspect tires and wheels.
with bias-ply or bias belted tires is
•
When passing over a pothole,
not recommended. Any combina-
speed bump, manhole, or curb
tions of radial-ply and bias-ply or bias
stone, drive slowly so that the
belted tires when used on the same
tires and wheels are not dam-
vehicle will seriously deteriorate
aged.
vehicle handling. The best rule to fol-
low is: Identical radial-ply tires should
•
If the tire is impacted, inspect
always be used as a set of four.
the tire condition or contact
an authorized HYUNDAI deal-
Longer wearing tires can be more
er.
susceptible to irregular tread wear. It
is very important to follow the tire
•
To prevent damage to the tire,
rotation interval shown in this section
inspect the tire condition and
to achieve the tread life potential of
pressure every
1,800miles
these tires. Cuts and punctures in
(3,000km).
radial-ply tires are repairable only in
the tread area, because of sidewall
flexing. Consult your tire dealer for
radial-ply tire repairs.
7
62
Maintenance
CAUTION
•
It is not easy to recognize the
tire damage with your own
eyes. But if there is the slight-
est hint of tire damage, even
though you cannot see the tire
damage with your own eyes,
have the tire checked or
replaced because the tire
damage may cause air leak-
age from the tire.
•
If the tire is damaged by driv-
ing on a rough road, off road,
pothole, manhole, or curb
stone, it will not be covered by
the warranty.
•
You can find out the tire infor-
mation on the tire sidewall.
7 63
Maintenance
FUSES
■ Blade type
A vehicle's electrical system is pro-
tected from electrical overload dam-
WARNING - Fuse
age by fuses.
replacement
This vehicle has 2 fuse panels, one
•
Never replace a fuse with any-
Normal
Blown
located in the driver's side panel bol-
thing but another fuse of the
ster, the other in the engine compart-
same rating.
■ Cartridge type
ment near the battery.
•
A higher capacity fuse could
If any of your vehicle's lights, acces-
cause damage and possibly a
sories, or controls do not work, check
fire.
the appropriate circuit fuse. If a fuse
•
Never install a wire or alu-
has blown, the element inside the
minum foil instead of the
fuse will be melted.
proper fuse - even as a tem-
Normal
Blown
If the electrical system does not
porary repair. It may cause
■ Multi fuse
work, first check the driver's side
extensive wiring damage and
fuse panel.
a possible fire.
Always replace a blown fuse with
one of the same rating.
Before replacing an open fuse, dis-
CAUTION
Normal
Blown
connect the negative battery cable.
Do not use a screwdriver or any
■ Battery fuse terminal
If the replacement fuse blows, this
other metal object to remove
indicates an electrical problem. Avoid
fuses because it may cause a
using the system involved and imme-
short circuit and damage the
diately consult an authorized
system.
HYUNDAI dealer.
Three kinds of fuses are used: blade
✽ NOTICE
type for lower amperage rating, car-
Normal
Blown
The actual fuse/relay panel label
tridge type, and multi fuse for higher
may differ from equipped items.
OLM079051N
amperage ratings.
7 64
Maintenance
Inner panel fuse replacement
CAUTION
•
When replacing an open fuse
or relay with a new one, make
sure the new fuse or relay fits
tightly into the clips. The
incomplete fastening fuse or
relay may cause the vehicle
wiring and electric systems
damage and a possible fire.
•
Do not remove fuses, relays
and terminals fastened with
ONCNMC2030
bolts or nuts. The fuses, relays
3. Pull the suspected fuse straight
ODM072017
and terminals may be fas-
out. Use the removal tool provided
tened incompletely, and it may
1. Turn the ignition switch and all
in the engine compartment fuse
cause a possible fire. If fuses,
other switches off.
panel.
relays and terminals fastened
2. Open the fuse panel cover.
4. Check the removed fuse; replace it
with bolts or nuts are open,
if it is blown.
consult with an authorized
HYUNDAI dealer.
5. Push in a new fuse of the same
rating, and make sure it fits tightly
•
Do not input any other objects
in the clips.
except fuses or relays into
fuse/relay terminals such as a
If it fits loosely, consult an authorized
driver or wiring. It may cause
HYUNDAI dealer.
contact failure and system
If you do not have a spare, use a fuse
malfunction.
of the same rating from a circuit you
may not need for operating the vehi-
cle, such as the cigar lighter fuse.
7 65
Maintenance
If the headlights or other electrical
Fuse switch
Engine compartment panel fuse
components do not work and the
replacement
fuses are OK, check the fuse block in
the engine compartment. If a fuse is
blown, it must be replaced.
ODM072019
Always, put the mode switch at the
ONCNMC2032
ON position.
1. Turn the ignition switch and all
If you move the switch to the OFF
other switches off.
position, some items such as audio
2. Remove the fuse box cover by
and digital clock must be reset and
pressing the tab and pulling up.
transmitter (or smart key) may not
work properly.
CAUTION
Always place the fuse switch in
the ON position while driving
the vehicle.
7 66
Maintenance
3. Check the removed fuse; replace it
Multi fuse
Main fuse
if it is blown. To remove or insert
the fuse, use the fuse puller in the
engine compartment fuse panel.
4. Push in a new fuse of the same
rating, and make sure it fits tightly
in the clips. If it fits loosely, consult
an authorized HYUNDAI dealer.
CAUTION
After checking the fuse box in
the
engine compartment,
securely install the fuse box
ONCNMC2033
ONCDMC2037
cover. If not, electrical failures
If the multi fuse is blown, it must be
If the main fuse is blown, it must be
may occur from water leaking in.
removed as follows:
removed as follows:
1. Disconnect the negative battery
1. Disconnect the negative battery
cable.
cable.
2. Remove the bolts shown in the
2. Remove the nuts shown in the pic-
picture above.
ture above.
3. Replace the fuse with a new one
3. Replace the fuse with a new one
of the same rating.
of the same rating.
4. Reinstall in the reverse order of
4. Reinstall in the reverse order of
removal.
removal.
✽ NOTICE
If the multi fuse is blown, consult an
Authorized HYUNDAI Dealer.
7 67
Maintenance
Fuse/Relay panel description
ODM072017
Inside the fuse/relay box covers, you
can find the fuse/relay label describ-
ing fuse/relay name and capacity.
✽ NOTICE
Not all fuse panel descriptions in
ONC077023N
this manual may be applicable to
your vehicle. It is accurate at the
time of printing. When you inspect
the fuse box on your vehicle, refer to
the fuse box label.
7 68
Maintenance
Description
Fuse rating
Protected Component
A/BAG IND
10A
Instrument Cluster, A/C Control Module
A/BAG
15A
ACU, Passenger Occupant Detection Sensor
RR_BLOWER, AVM, AC_INVERTER_UNIT,Smart Key Control Module, BCM, Rear Seat Warmer
5 MODULE
7.5A
LH/RH,Driver/Passenger Seat Warmer Module,
Sport Mode Switch, Key Solenoid, Console Switch LH/RH,Rear Power Window Switch LH/RH,
1 MODULE
7.5A
Data Link Connector
FOG LAMP REAR
10A
-
BCM, Tire Pressure Monitoring Module, Electro Chromic Mirror, Driver/Passenger Door Module, Auto
2 MEMORY
10A
Light & Photo Sensor, A/C Control Module, Instrument Cluster, FRT_DRV_SEAT
2 SMART KEY
7.5A
Smart Key Control Module, Immobilizer Module
BCM, Instrument Cluster, Tire Pressure Monitoring Module, A/C Control Module,
Driver/Passenger Door Module, ATM Shift Lever Indicator, Rear Seat Warmer LH/RH, 4WD ECU,
3 MODULE
10A
Driver/Passenger Seat Warmer Module, MTS Module, Rear(SMART) Parking Assist Sensor LH/RH,
A/V & Navigation Head Unit, Rear Parking Assist Sensor (Center)LH/RH, AMP, SAS_ESP,EPB_EXT,
Electro Chromic Mirror, BSD
4 SMART KEY
10A
Start/Stop Button Switch, Immobilizer Module
Cargo Lamp, Vanity Lamp LH/RH, Overhead Console Lamp, Center Room Lamp, Personal Lamp
INTERIOR LAMP
15A
LH/RH
MULTI MEDIA
15A
Audio, A/V & Navigation Head Unit, MTS Module,D_CLOCK
MDPS
7.5A
MDPS Unit
HTD STRG
15A
Steering Wheel Switch
FOG LAMP FRONT
15A
FRT FOG LAMP LH/RH
1 MEMORY
10A
RF Receiver, Ignition Key Ill. & Door Warning Switch
7 69
Maintenance
Description
Fuse rating
Protected Component
W/O IMMO. & Smart Key : ICM Relay Box (Burglar Alarm Relay)
START
7.5A
With IMMO. or Smart Key : INHIBIT_SW(POSITION_SW)
Crash Pad Switch, Multipurpose Check Connector, Head Lamp Leveling Device Actuator LH/RH, Auto
2 MODULE
10A
Head Lamp Leveling Device Module, Stop Lamp Switch,AFLS_UNIT, F_WATER_SNSR,
GLOW_RLY_UNIT_METAL, FPAS_SNSR, DSL_BOX
CORNERING LAMP
10A
-
2 SUNROOF
20A
Sunroof_MTR
S/HEATER RR
15A
Rear Seat Warmer LH/RH
IGN
20A
E/R Fuse & Relay Box (Fuse - ABS 3, SENSOR 5, TCU)
1 A/CON
7.5A
E/R Fuse & Relay Box (Blower Relay), A/C Control Module, Cluster Ionizer, DSL_BOX(PTC_RLY)
WIPER RR
15A
Rear Wiper Relay, Rear Wiper Motor, Multifunction Switch, BCM
1 SMART KEY
25A
Smart Key Control Module
S/HEATER FRT
20A
Driver/Passenger Seat Warmer Module
2 A/CON
7.5A
A/C Control Module
C/LIGHTER
20A
Front Power Outlet & Cigarette Lighter, Luggage Power Outlet
WIPER FRT
15A
Multifunction Switch, E/R Fuse & Relay Box (Wiper HI Relay, IG2 Relay)
A/CON RR
20A
-
P/WDW RH
25A
Passenger Door Module, Rear Power Window Switch RH
REAR HTD
10A
A/C Control Module
BRAKE SWITCH
7.5A
Smart Key Control Module, Stop Lamp Switch
7 70
Maintenance
Description
Fuse rating
Protected Component
1 SUNROOF
20A
SUNROOF_MTR
P/WDW LH
25A
Driver Safety Power Window Module, Driver Door Module, Rear Power Window Switch LH
FUEL LID
15A
Fuel Fillar Door Switch (DOOR_EXT)
3 SMART KEY
7.5A
Smart Key Control Module
STOP LAMP
15A
Stop Signal Electronic Module
P/SEAT (PASS)
20A
Passenger Seat Manual Switch, Passenger Lumbar Support Switch
AMP
30A
AMP
Audio, A/V & Navigation Head Unit, BCM, AMP, MTS Module, Power Outside Mirror Switch,
4 MODULE
10A
E/R Fuse & Relay Box (Power Outlet Relay), AVM, D_CLOCK, USB_CHARGE
DOOR LOCK
20A
Door Lock/Unlock Relay, Tail Gate Relay, ICM Relay Box (Dead Lock Relay)
P/SEAT (DRV)
30A
Driver IMS Module, Driver Seat Manual Switch, Driver Lumbar Support Switch
7 71
Maintenance
Engine compartment fuse panel
ONCNMC2036
ONC077024N
7 72
Maintenance
Relay NO.
Relay Name
Relay Type
E30
POWER OUTLET RELAY
ISO MICRO
E31
START RELAY
ISO MICRO
E32
FRONT DEICER RELAY
ISO MICRO
E33
BLOWER RELAY
ISO MICRO
E34
WIPER LO RELAY
ISO MICRO
E36
ACC RELAY
ISO MICRO
E37
IG1 RELAY
ISO MICRO
E38
IG2 RELAY
ISO MICRO
E39
COOLING FAN RELAY
ISO MINI
E40
WIPER HI RELAY
ISO MICRO
E41
REAR DEFOGGER RELAY
ISO MICRO
E42
HORN RELAY
ISO MICRO
7 73
Maintenance
Description
Fuse rating
Protected Component
MDPS
80A
MDPS Unit
Smart Junction Box (IPS 1 (4CH), IPS 2 (1CH), IPS 5 (1CH), Fuse - SUNROOF 1, P/SEAT
2 B+
60A
PASS, P/SEAT DRV), RR A/CON
BLOWER
40A
Blower Relay
MULTI
RR HTD
40A
Rear Defogger Relay
FUSE
ABS1
40A
ESC Module, Multipurpose Check Connector
ABS2
40A
ESC Module
C/FAN
60A
Cooling Fan Relay
Smart Junction Box (Fuse - MODULE 1, SMART KEY 4, SUNROOF 2, SMART KEY 1, Leak
3 B+
60A
Current Autocut Device)
Smart Junction Box (IPS 3 (4CH), IPS 6 (2CH), Fuse - F/LID, STOP LAMP, DR LOCK, BRAKE
4 B+
50A
SWITCH), FUEL LID
ECU
40A
ECU Box
IG1
40A
W/O Smart Key : Ignition Switch, With Smart Key - ACC Relay, IG1 Relay
IG2
40A
Start Relay, IG2 Relay, W/O Smart Key : Ignition Switch
TRAILER
30A
Trailer Power Outlet
FUSE
1 B+
50A
Smart Junction Box (Fuse - S/HEATER RR, S/HEATER FRT, P/WDW RH, P/WDW LH)
HORN
15A
Horn Relay
DEICER
15A
Front Deicer Relay
POWER OUTLET
25A
Power Outlet Relay
AC INVERTER
30A
AC Inverter Module
7 74
Maintenance
Description
Fuse rating
Protected Component
POWER TAILGATE
30A
Power Tail Gate Module
IDB
15A
IDB Module
4WD
20A
4WD ECM
AMS
10A
Battery Sensor
AMS (WIPER)
10A
BCM, PCM
WIPER FRT
25A
Wiper LO Relay, Front Wiper Motor
A/T - Rear Combination Lamp (IN) LH/RH, Electro Chromic Mirror, Audio, A/V & Navigation
B/UP LAMP
10A
Head Unit
ABS3
7.5A
ESC Module
5 SENSOR
7.5A
PCM
FUSE
TCU
15A
A/T : Transaxle Range Switch
F/PUMP
15A
Fuel Pump Relay
1 ECU
15A
PCM
2 ECU
10A
IDB Module
3 SENSOR
10A
Fuel Pump Relay
IGN COIL
20A
Condenser, Ignition Coil #1/#2/#3/#4
2 SENSOR
10A
Purge Control Solenoid Valve, Variable Intake Solenoid Valve(G4KJ), Oil Control Valve #1/#2
Oxygen sensor(#1/#2/#3/#4), PCM, Oxygen Sensor(Down), E/R Fuse & Relay Box (Cooling
1 SENSOR
15A
Fan Relay)
B/A HORN
10A
Burgl Aralarm Horn Relay
7 75
Maintenance
LIGHT BULBS
✽ NOTICE
WARNING - Working on
CAUTION
After heavy, driving rain or wash-
the lights
If you don't have necessary
ing, headlamp and taillamp lenses
Prior to working on the light,
tools, the correct bulbs and the
could appear frosty. This condition
firmly apply the parking brake,
expertise, consult an authorized
is caused by the temperature differ-
ensure that the ignition switch
HYUNDAI dealer. In many cases,
ence between the lamp inside and
is turned to the "LOCK" posi-
it is difficult to replace vehicle
outside. This is similar to the con-
tion and turn off the lights to
light bulbs because other parts
densation on your windows inside
avoid sudden movement of the
of the vehicle must be removed
your vehicle during the rain and
vehicle and burning your fin-
before you can get to the bulb.
doesn't indicate a problem with
gers or receiving an electric
This is especially true if you
your vehicle. If the water leaks into
shock.
have to remove the headlight
the lamp bulb circuitry, have the
assembly to get to the bulb(s).
vehicle checked by an authorized
Removing/installing the head-
HYUNDAI dealer.
Use only the bulbs of the specified
light assembly can result in
wattage.
damage to the vehicle.
✽ NOTICE - Headlamp desic-
cant (if equipped)
CAUTION
This vehicle is equipped with desic-
Be sure to replace the burned-
cant to reduce fogging inside the
out bulb with one of the same
headlamp due to moisture.
wattage rating. Otherwise, it
The desiccant is consumable and its
may cause damage to the fuse
performance may change based on
or electric wiring system.
the used period or environment.
If fogging inside the headlamp due
to moisture continues for a long
time, have your vehicle checked by
an authorized HYUNDAI dealer.
7 76
