Hyundai Santa Fe XL (2019 year). Instruction - part 25

What to do in an emergency

IF THE ENGINE WILL NOT START

If engine doesn't turn over or

If engine turns over normally

turns over slowly

but does not start

1. If your vehicle has an automatic

1. Check fuel level.

transaxle, be sure the shift lever is

2. With the ignition switch in the LOCK

in N (Neutral) or P (Park) and the

position, check all connectors at

emergency brake is set.

ignition coils and spark plugs.

2. Check the battery connections to

Reconnect any that may be discon-

be sure they are clean and tight.

nected or loose.

3. Turn on the interior light. If the light

3. If the engine still does not start, call

dims or goes out when you oper-

an authorized HYUNDAI dealer or

ate the starter, the battery is dis-

seek other qualified assistance.

charged.

4. Do not push or pull the vehicle to

start it. See instructions for "Jump

starting".

WARNING

If the engine will not start, do

not push or pull the vehicle to

start it. This could result in a

collision or cause other dam-

age. In addition, push or pull

starting may cause the catalytic

converter to be overloaded and

create a fire hazard.

6 4

What to do in an emergency

EMERGENCY STARTING

Jumper Cables

Jump starting

WARNING - Battery

Jump starting can be dangerous if

done incorrectly. Therefore, to avoid

•

Keep all flames or sparks

away from the battery. The

harm to yourself or damage to your

vehicle or battery, follow the jump

battery produces hydrogen

gas which may explode if

starting procedures. If in doubt, we

strongly recommend that you have a

exposed to flame or sparks.

Booster

technician or towing service jump

If these instructions are not fol-

battery

start your vehicle.

lowed exactly, serious personal

injury and damage to the vehi-

cle may occur! If you are not

1VQA4001

CAUTION

sure how to follow this proce-

Connect cables in numerical order

Use only a 12-volt jumper sys-

dure, seek qualified assis-

and disconnect in reverse order.

tem. You can damage a 12-volt

tance. Automobile batteries

starting motor, ignition system,

contain sulfuric acid. This is

and other electrical parts

poisonous and highly corro-

beyond repair by use of a 24-volt

sive. When jump starting, wear

power supply (either two 12-volt

protective glasses and be care-

batteries in series or a 24-volt

ful not to get acid on yourself,

motor generator set).

your clothing or on the car.

•

Do not attempt to jump start

the vehicle if the discharged

battery is frozen or if the elec-

trolyte level is low; the battery

may rupture or explode.

6 5

What to do in an emergency

Jump starting procedure

4.Connect the jumper cables in the

exact sequence shown in the illus-

CAUTION - Battery cables

✽ NOTICE

tration. First connect one end of a

Do not connect the jumper cable

If the battery is discharged, the

jumper cable to the positive termi-

from the negative terminal of the

engine can be started using a battery

nal of the discharged battery (1),

booster battery to the negative

of another vehicle and two jumper

then connect the other end to the

terminal of the discharged bat-

cables. Only use jumper cables with

positive terminal on the booster

tery. This can cause the dis-

fully insulated clamp handles.

battery

(2). Proceed to connect

charged battery to overheat and

To prevent personal injury or dam-

one end of the other jumper cable

crack, releasing battery acid.

age to both vehicles, adhere strictly

to the negative terminal of the

to the following procedure.

booster battery (3), then the other

5.Start the engine of the vehicle with

end to a solid, stationary, metallic

1.Make sure the booster battery is

the booster battery and let it run at

point (for example, the engine lift-

12-volt and that its negative termi-

2,000 rpm, then start the engine of

ing bracket) away from the battery

nal is grounded.

the vehicle with the discharged

(4). Do not connect it to or near any

battery. If the first starting attempt

2.If the booster battery is in another

part that moves when the engine is

is not successful, wait a few min-

vehicle, do not allow the vehicles to

cranked.

utes before making another

touch.

Make sure that there is no contact

attempt in order to allow the dis-

3.Turn off all unnecessary electrical

between the bodywork of the two

charged battery to recharge.

loads.

vehicles; otherwise, there is the

To charge the discharged battery

danger of short circuits.

enough, it is recommended to let the

Do not allow the jumper cables to

engine at idle or to drive the vehicle

contact anything except the correct

for a certain period of time.

battery terminals or the correct

If the cause of your battery discharg-

ground. Do not lean over the bat-

ing is not apparent, you should have

tery when making connections.

your vehicle checked by an author-

ized HYUNDAI dealer.

6 6

What to do in an emergency

Push-starting

Vehicles equipped with automatic

transaxle cannot be push-started.

Follow the directions in this section

for jump-starting.

WARNING

Never tow a vehicle to start it

because the sudden surge for-

ward when the engine starts

could cause a collision with the

tow vehicle.

6 7

What to do in an emergency

IF THE ENGINE OVERHEATS

If your temperature gauge indicates

4. Check to see if the water pump

overheating, you experience a loss

drive belt is missing. If it is not

WARNING

of power, or hear loud pinging or

missing, check to see that it is

Do not remove the radiator cap

knocking, the engine is probably too

tight. If the drive belt seems to be

when the engine is hot. This

hot. If this happens, you should:

satisfactory, check for coolant

may result in coolant being

leaking from the radiator, hoses or

blown out of the opening and

under the car. (If the air condition-

1. Pull off the road and stop as soon

cause serious burns.

ing had been in use, it is normal

as it is safe to do so.

for cold water to be draining from it

2. Place the shift lever in P and set

6. If you cannot find the cause of the

when you stop.)

the parking brake. If the air condi-

overheating, wait until the engine

tioning is on, turn it off.

temperature has returned to nor-

WARNING

mal. Then, if coolant has been lost,

3. If engine coolant is running out

under the car or steam is coming

While the engine is running,

carefully add coolant to the reser-

out from the hood, stop the

keep hair, hands and clothing

voir to bring the fluid level in the

engine. Do not open the hood until

away from moving parts such

reservoir up to the halfway mark.

the coolant has stopped running

as the fan and drive belts to pre-

7. Proceed with caution, keeping

or the steaming has stopped. If

vent injury.

alert for further signs of overheat-

there is no visible loss of engine

ing. If overheating happens again,

coolant and no steam, leave the

call an authorized HYUNDAI deal-

5. If the water pump drive belt is bro-

engine running and check to be

er for assistance.

ken or engine coolant is leaking

sure the engine cooling fan is

out, stop the engine immediately

operating. If the fan is not running,

and call the nearest authorized

CAUTION

turn the engine off.

HYUNDAI dealer for assistance.

Serious loss of coolant indi-

cates there is a leak in the cool-

ing system and this should be

checked as soon as possible by

an authorized HYUNDAI dealer.

6 8

What to do in an emergency

TIRE PRESSURE MONITORING SYSTEM (TPMS)

Check tire pressure

• You can change the tire pressure

unit in the user settings mode on

the cluster.

- Refer to "User settings mode" in

chapter 4.

ODM062002

OAN067006N

•

You can check the tire pressure in

the information mode on the clus-

ter.

- Refer to "User settings mode" in

chapter 4.

•

Tire pressure is displayed 1~2 min-

utes later after driving.

OAN067005N

•

If tire pressure is not displayed

(1) Low Tire Pressure Telltale/

when the vehicle is stopped, "Drive

TPMS Malfunction Indicator

to display" message displays. After

(2) Low tire pressure position telltale

driving, check the tire pressure.

and tire pressure telltale

(Shown on the LCD display)

6 9

What to do in an emergency

Tire pressure monitoring sys-

As an added safety feature, your

Your vehicle has also been equipped

tem

vehicle has been equipped with a tire

with a TPMS malfunction indicator to

pressure monitoring system (TPMS)

indicate when the system is not

that illuminates a low tire pressure

operating properly. The TPMS mal-

WARNING

telltale when one or more of your

function indicator is combined with

Over-inflation or under-inflation

tires is significantly under-inflated.

the low tire pressure telltale. When

can reduce tire life, adversely

Accordingly, when the low tire pres-

the system detects a malfunction,

affect vehicle handling, and

sure telltale illuminates, you should

the telltale will flash for approximate-

lead to sudden tire failure that

stop and check your tires as soon as

ly one minute and then remain con-

may cause loss of vehicle con-

possible, and inflate them to the

tinuously illuminated. This sequence

trol resulting in an accident.

proper pressure. Driving on a signifi-

will continue upon subsequent vehi-

cantly under-inflated tire causes the

cle start-ups as long as the malfunc-

tire to overheat and can lead to tire

tion exists. When the malfunction

Each tire, including the spare (if pro-

failure. Under-inflation also reduces

indicator is illuminated, the system

vided), should be checked monthly

fuel efficiency and tire tread life, and

may not be able to detect or signal

when cold and inflated to the inflation

may affect the vehicle’s handling and

low tire pressure as intended.

pressure recommended by the vehi-

stopping ability.

TPMS malfunctions may occur for a

cle manufacturer on the vehicle plac-

ard or tire inflation pressure label. (If

Please note that the TPMS is not a

variety of reasons, including the

substitute for proper tire mainte-

installation of replacement or alter-

your vehicle has tires of a different

size than the size indicated on the

nance, and it is the driver’s responsi-

nate tires or wheels on the vehicle

bility to maintain correct tire pres-

that prevent the TPMS from function-

vehicle placard or tire inflation pres-

sure label, you should determine the

sure, even if under-inflation has not

ing properly. Always check the TPMS

reached the level to trigger illumina-

malfunction telltale after replacing

proper tire inflation pressure for

those tires.)

tion of the TPMS low tire pressure

one or more tires or wheels on your

telltale.

vehicle to ensure that the replace-

ment or alternate tires and wheels

allow the TPMS to continue to func-

tion properly.

6 10

What to do in an emergency

✽ NOTICE

Low tire pressure

If either telltale illuminates, immedi-

telltale

ately reduce your speed, avoid hard

If any of the below happens, have

cornering and anticipate increased

the system checked by an authorized

stopping distances. You should stop

HYUNDAI dealer.

Low tire pressure position tell-

and check your tires as soon as pos-

1.The low tire pressure telltale/

tale and tire pressure telltale

sible. Inflate the tires to the proper

TPMS malfunction indicator does

pressure as indicated on the vehi-

not illuminate for 3 seconds when

cle’s placard or tire inflation pressure

Engine Start/Stop button is turned

label located on the driver’s side cen-

to the ON or engine is running.

ter pillar outer panel. If you cannot

2.The TPMS malfunction indicator

reach a service station or if the tire

remains illuminated after blinking

cannot hold the newly added air,

for approximately 1 minute.

replace the low pressure tire with a

3.The Low tire pressure position

spare tire.

telltale remains illuminated.

If you drive the vehicle for about 20

minutes at speeds above 15.5 mph

(25 km/h) after replacing the low

OAN067005N

pressure tire with the spare tire, the

When the tire pressure monitoring

below will happen:

system warning indicators are illumi-

• The TPMS malfunction indicator

nated and warning massage dis-

1

may blink for approximately

played on the cluster LCD display,

minute and then remain continu-

one or more of your tires is signifi-

ously illuminated because the

cantly under-inflated. The low tire

TPMS sensor is not mounted on

pressure position telltale light will

the spare wheel.

indicate which tire is significantly

under-inflated by illuminating the cor-

responding position light.

6 11

What to do in an emergency

✽ NOTICE

TPMS (Tire Pressure

WARNING - Low pressure

Monitoring System)

The spare tire is not equipped with a

damage

malfunction indicator

tire pressure sensor.

Significantly low tire pressure

makes the vehicle unstable and

CAUTION

The TPMS malfunction indicator will

can contribute to loss of vehicle

In winter or cold weather, the

control and increased braking

illuminate after it blinks for approxi-

mately one minute when there is a

low tire pressure telltale may

distances.

illuminate if the tire pressure

problem with the Tire Pressure

Continued driving on low pres-

Monitoring System.

was adjusted to the recom-

sure tires can cause the tires to

mended tire inflation pressure

Have the system checked by an

overheat and fail.

in warm weather. It does not

authorized HYUNDAI dealer.

mean your TPMS is malfunction-

ing because the decreased tem-

✽ NOTICE

perature leads to a lowering of

tire pressure.

If there is a malfunction with the

TPMS, the low tire pressure position

When you drive your vehicle

telltale will not be displayed even

from a warm area to a cold area

though the vehicle has an under-

or from a cold area to a warm

inflated tire.

area, or the outside temperature

is higher or lower, you should

check the tire inflation pressure

and adjust the tires to the rec-

ommended tire inflation pres-

sure.

6 12

What to do in an emergency

Changing a tire with TPMS

If you drive the vehicle for about 20

CAUTION

minutes at speeds above 15.5 mph

If you have a flat tire, the low Tire

•

The TPMS malfunction indica-

(25 km/h) after replacing the low

Pressure and Position telltales will

tor may blink for approximate-

pressure tire with the spare tire, the

come on. Have the system checked

ly 1 minute and then remain

below will happen:

by an authorized HYUNDAI dealer.

continuously illuminated if the

• The TPMS malfunction indicator

vehicle is moving around elec-

may blink for approximately

1

tric power supply cables or

CAUTION

minute and then remain continu-

radios transmitter such as at

NEVER use a puncture-repair-

ously illuminated because the

police stations, government

ing agent to repair and/or inflate

TPMS sensor is not mounted on

and public offices, broadcast-

a low pressure tire. The tire

the spare wheel.

ing stations, military installa-

sealant can damage the tire

tions, airports, or transmitting

pressure sensor. If used, you

You may not be able identify a low

towers, etc. This can interfere

will have to replace the tire pres-

tire by simply looking at it. Always

with normal operation of the

sure sensor.

use a good quality tire pressure

Tire Pressure Monitoring

gauge to measure the tire's inflation

System (TPMS).

Each wheel is equipped with a tire

pressure. Please note that a tire that

•

The TPMS malfunction indica-

pressure sensor mounted inside the

is hot (from being driven) will have a

tor may blink for approximate-

tire behind the valve stem. You must

higher pressure measurement than a

ly 1 minute and then remain

use TPMS specific wheels. It is rec-

tire that is cold (from sitting station-

continuously illuminated if

ommended that you have your tires

ary for at least 3 hours and driven

snow chains are used or some

serviced by an authorized HYUNDAI

less than 1 mile (1.6 km) during that

separate electronic devices

dealer.

3 hour period).

such as notebook computer,

Allow the tire to cool before measur-

mobile charger, remote starter

ing the inflation pressure. Always be

or navigation etc., are used in

sure the tire is cold before inflating to

the vehicle.

the recommended pressure.

This can interfere with normal

operation of the Tire Pressure

Monitoring System (TPMS).

6 13

What to do in an emergency

A cold tire means the vehicle has

This device complies with Part

been sitting for 3 hours and driven for

WARNING - Protecting

15 of the FCC rules.

less than 1 mile (1.6 km) in that 3

TPMS

Operation is subject to the following

hour period.

Tampering with, modifying, or

two conditions:

disabling the Tire Pressure

1. This device may not cause harm-

Monitoring System

(TPMS)

WARNING - TPMS

ful interference, and

components may interfere with

• The TPMS cannot alert you to

the system's ability to warn the

2. This device must accept any inter-

severe and sudden tire dam-

driver of low tire pressure con-

ference received, including inter-

age caused by external fac-

ditions and/or TPMS malfunc-

ference that may cause undesired

tors such as nails or road

tions. Tampering with, modify-

operation.

debris.

ing, or disabling the Tire

• If you feel any vehicle instabil-

Pressure Monitoring System

CAUTION

ity, immediately take your foot

(TPMS) components may void

the warranty for that portion of

Changes or modifications not

off the accelerator, apply the

brakes gradually and with

the vehicle.

expressly approved by the party

responsible for compliance

light force, and slowly move to

could void the user’s authority

a safe position off the road.

to operate the equipment.

6 14

What to do in an emergency

IF YOU HAVE A FLAT TIRE

Jack and tools

Jacking instructions

WARNING - Changing

The jack is provided for emergency

tire changing only.

tires

•

Never attempt vehicle repairs

To prevent the jack from “rattling”

in the traffic lanes of a public

while the vehicle is in motion, store it

road or highway.

properly.

•

Always move the vehicle com-

Follow jacking instructions to reduce

the possibility of personal injury.

pletely off the road and onto

the shoulder before trying to

change a tire. The jack should

be used on level firm ground.

If you cannot find a firm, level

place off the road, call a tow-

ONCDEM2003N

ing service company for

The jack, jack handle, and wheel lug

assistance.

nut wrench are stored in the luggage

•

Be sure to use the correct

compartment. Pull up the luggage

front and rear jacking posi-

box cover to find these equipment.

tions on the vehicle; never use

(1) Jack handle

the bumpers or any other part

(2) Jack

of the vehicle for jack support.

(3) Wheel lug nut wrench

•

The vehicle can roll off the

jack causing serious injury or

death. No person should

place any portion of their

body under a vehicle that is

supported only by a jack; use

vehicle support stands.

(Continued)

6 15

What to do in an emergency

Removing and storing the

(Continued)

spare tire

•

Do not start or run the engine

while the vehicle is on the

jack.

•

Do not allow anyone to remain

in the vehicle while it is on the

jack.

•

Make sure any children pres-

ent are in a secure place away

from the road and from the

vehicle to be raised with the

ONCNEM2002

jack.

3.Connect the wheel lug nut wrench.

ONCNEM2001

4.Loosen the bolt enough to lower

the spare tire.

Your spare tire is stored underneath

Turn the wrench counterclockwise

your vehicle, directly below the cargo

until the spare tire reaches the

area.

ground.

To remove the spare tire:

1.Open the liftgate (tailgate).

2.Remove cover with coin or flat-

head screwdriver.

6 16

What to do in an emergency

WARNING - Storing the

spare tire

Ensure the spare tire retainer is

properly aligned with the center

of the spare tire to prevent the

spare tire from “rattling”.

Otherwise, it may cause the

spare tire to fall off the carrier

and lead to an accident.

ODM062006

ODM062007

5. After the spare tire reaches the

To store the spare tire:

ground, continue to turn the

1. Lay the tire on the ground with the

wrench counterclockwise, and

valve stem facing up.

draw the spare tire outside. Never

2. Place the wheel under the vehicle

rotate the wrench excessively, oth-

and install the retainer (1) through

erwise the spare tire carrier may

the wheel center.

be damaged.

3. Turn the wrench clockwise until it

6. Remove the retainer (1) from the

clicks.

center of the spare tire

6 17

What to do in an emergency

Changing tires

WARNING - Changing a

tire

•

To prevent vehicle movement

while changing a tire, always

set the parking brake fully,

and always block the wheel

diagonally opposite the wheel

being changed.

•

We recommend that the

wheels of the vehicle be

1VQA4023

blocked, and that no person

4. Remove the wheel lug nut wrench,

remain in a vehicle that is

1VQA4022

jack, jack handle, and spare tire

being jacked.

1. Park on a level surface and apply

from the vehicle.

the parking brake firmly.

5. Block both the front and rear of the

2. Shift the shift lever into P (Park).

wheel that is diagonally opposite

3. Activate the hazard warning flash-

the jack position.

er.

6 18

What to do in an emergency

ODM062008

ONC066030

ODM062010

6. Loosen the wheel lug nuts coun-

7. Place the jack at the front or rear

8. Insert the jack handle into the jack

terclockwise one turn each, but do

jacking position closest to the tire

and turn it clockwise, raising the

not remove any nut until the tire

you are changing. Place the jack

vehicle until the tire just clears the

has been raised off the ground.

at the designated locations under

ground. This measurement is

the frame.

approximately

1.2 in

(30 mm).

Before removing the wheel lug

nuts, make sure the vehicle is sta-

WARNING - Jack location

ble and that there is no chance for

To reduce the possibility of

movement or slippage.

injury, be sure to use only the

jack provided with the vehicle

and in the correct jack position;

never use any other part of the

vehicle for jack support.

6 19

Content   ..  23  24  25  26   ..
