Hyundai Terracan (2007 year). Instruction - part 17





VEHICLE SPECIFICATIONS
Measurement
9-2
Engine
9-3
Lubrication Chart
9-4
9
9
9 VEHICLE SPECIFICATIONS
2
J010A02HP-GAT
J030A02HP-GAT
MEASUREMENT
mm
TIRE
Kpa(psi)
Overall length
4700 (4765*1 )
Tire Size
Inflation Pressure
Overall width
1860
Standard
255/65 R16
200kPa (29 psi)
Overall height
1795 (1840*2 )
Spare
Full Size
Wheel base
2750
J040A02HP-GAT
Wheel tread
Front
1530
ELECTRICAL
Rear
1530
DIESEL
*1: With Bumper Guard
ITEM
GASOLINE
*2: With Roof Rack
2.5 TCI
2.9 CRDi
Battery
MF 68AH
MF 90AH
MF 100AH
Alternator
120A (13.5V)
90A (12 V)
110A (12V)
J020A01HP-GAT
POWER STEERING
Ball and nut, torsion bar type
J050A02HP-GAT
Type
BRAKE
(Integral type)
Wheel free play
0 ~ 30 mm (0 ~ 1.18 in.)
Type
Dual hydraulic with brake booster
Oil pump type
Vane type
Front brake type
Ventilated disc
Rear
E.C only
Disc type
brake
Disc type (with ABS)
J060A01Y-GAT
Except E.C
FUEL SYSTEM
type
Drum type (without ABS)
Fuel tank capacity
75 liter
Parking brake
Cable operated on rear wheel
VEHICLE SPECIFICATIONS
9
ENGINE
3
J070A04HP-GAT
Gasoline Engine
Diesel Engine
ITEMS
3.5 V6
2.5 TCI
2.9 CRDi
Engine Type
6-Cyl., V-type DOHC
4-Cyl., In-line SOHC
4-Cyl., In-line DOHC
Bore x Stroke
93.0 x 85.8 mm (3.67 x 3.38 in.)
91.1 x 95 mm (3.59 x 3.74 in.)
97.1 x 98 mm (3.82 x 3.86 in.)
Displacement
3497cc
2476cc
2902cc
Compression Ratio
10
22
16.5
Firing Order
1 - 2 - 3 - 4 - 5 - 6
1 - 3 - 4 - 2
Valve clearance
Cold
Auto lash
0.15 mm
Auto lash
(Intake/Exhaust)
Hot
Auto lash
0.25 mm
Auto lash
Idle Speed (rpm)
800
750 ± 100
800 ± 100
Injection (or lgnition) Timing
BTDC 5° ± 2°
ATDC 7° ± 1°
Automatically Adjusted
9 VEHICLE SPECIFICATIONS
LUBRICATION CHART
4
J080A11HP-GAT
Item
Oil & Grease Standard
Q'ty (liter)
Engine Oil
Gasoline
API SJ, SL or ABOVE,
SAE 5W-20, 5W-30
Drain and refill (With oil filter) : 4.3
ILSAC GF-3 or ABOVE
SAE 10W-30 [ABOVE -18°C(-0.4°F)]
SAE 15W-40 [ABOVE -13°C(8.6°F)]
SAE 20W-50 [ABOVE -7°C(19.4°F)]
Recommends
Diesel
API CF-4 or ABOVE,
SAE #30 [ABOVE 0°C(32°F)]
Drain and refill (With oil filter) : 5.1
(2.5 TCI)
ACEA B2 or B3
SAE 20W-40 [ABOVE -10°C(14°F)]
SAE 15W-40 [ABOVE -15°C(5°F)]
SAE 10W-30 [-20°C ~ 40°C (-4°F ~ 104°F)]
SAE 5W-30 [-25°C ~10°C (-13°F ~ 50°F)]
SAE 0W-30 [BELOW 10°C(50°F)] *1
Diesel
API CF-4 or ABOVE,
SAE 15W-40 [ABOVE -15°C (5°F)]
Drain and refill (With oil filter) :
(2.9 CRDi)
ACEA B4 or ABOVE
SAE 10W-30 [-20°C ~ 40°C(-4°F ~ 104°F)]
2WD : 6.6
SAE 5W-30 [-25°C~40°C (-13°F~104°F)]
4WD : 6.0
SAE 0W-30 [BELOW 10°C(50°F)] *1
*1. Restricted by driving condition and dealing area
Engine Oil Consumption
Normal driving condition
MAX. 1L /1500 Km
Severe driving condition
MAX. 1L /1000 Km
VEHICLE SPECIFICATIONS
9
5
J080A11HP-GAT
Item
Oil & Grease Standard
Q'ty (liter)
Transmission
Manual
HYUNDAI GENUINE PARTS MTF 75W/85 (API GL-4)
2.5 (2.5 TCI), 3.2 (2.9 CRDi or 3.5 V6)
Fluid
Automatic
MOBIL DEXRON-II
8.2 (2.5 TCI), 11.8 (2.9 CRDi ), 10.5 (3.5 V6)
Transfer Case Oil
ATF DEXRON-III
1.42
Front Axle Gear Oil
HYPOID GEAR OIL API GL-5 or HIGHER,
Part-time 4WD : 1.8
SAE 80W[BELOW -30°C(-22°F)]/90W[ABOVE -30°C(-22°F)]
Full-time 4WD : 1.3
Rear Axle
MITSUBISHI GENUINE GEAR OIL PART NO. 8149630EX or
Gear Oil
CASTROL HYPOY LS(2.5 TCI)
With LSD
MOBIL INFILREX 33 or MOBILUBE LS 85W-90
NO.7 : 2.6, NO.7.5 : 2.8
(2.9 CRDi or 3.5 V6)
Without
HYPOID GEAR OIL API GL-5 or HIGHER,
LSD
SAE 80W[BELOW -30°C(-22°F)]/90W[ABOVE -30°C(-22°F)]
Coolant
Ethylene glycol base for aluminum radiator
8(2.5 TCI), 9(2.9 CRDi), 11(3.5 V6)
Power Steering Oil
PSF-3 TYPE FLUID
1.3
Brakes and Clutch Fluid
DOT 3, DOT 4 or Equivalent
As required
