Features of your vehicle
Defogging logic
To reduce the probability of fogging up
the inside of the windshield, the air intake
is controlled automatically according to
certain conditions such as
or
position. To cancel or return the defog-
ging logic, perform the following steps.
OYF049133
OYF049222
Manual climate control system
Automatic climate control system
1. Turn the ignition switch to the ON posi-
1. Turn the ignition switch to the ON
tion.
position.
2. Turn the mode selection knob to the
2. Select the defrost position pressing
defrost position (
).
defrost button (
).
3. Push the air intake control button at
3. While holding the air conditioning but-
least 5 times within 3 seconds.
ton (A/C) pressed, press the air intake
The indicator light in the air intake control
control button at least 5 times within 3
button will blink 3 times with 0.5 second
seconds.
of interval. It indicates that the defogging
The indicator on the air intake control
logic is canceled or returned to the pro-
button blinks 3 times with 0.5 second of
grammed status.
interval. It indicates that the defogging
logic is canceled or returned to the pro-
If the battery has been discharged or dis-
grammed status.
connected, the system resets to the pro-
grammed defogging logic.
If the battery has been discharged or dis-
connected, the system resets to the pro-
grammed defogging logic.
4 97
Features of your vehicle
STORAGE COMPARTMENTS
These compartments can be used to
store small items.
CAUTION
• To avoid possible theft, do not
leave valuables in the storage
compartments.
• Always keep the storage com-
partment covers closed while
driving. Do not attempt to place
so many items in the storage
compartment that the storage
OYF049137
OYF049138
compartment cover cannot close
securely.
Center console storage
Glove box
To open the center console storage, pull
The glove box can be locked and
up the lever.
unlocked with a master key
(or the
WARNING - Flammable
mechanical key of the smartkey) (1).
materials
To open the glove box, pull the handle
and the glove box will automatically
Do not store cigarette lighters,
propane cylinders, or other flamma-
open. Close the glove box after use.
ble/explosive materials in the vehi-
cle. These items may catch fire
WARNING
and/or explode if the vehicle is
To reduce the risk of injury in an
exposed to hot temperatures for
accident or sudden stop, always
extended periods.
keep the glove box door closed
while driving.
4 98
Features of your vehicle
WARNING
•
Do not keep objects except sun-
glasses inside the sunglass hold-
er. Such objects can be thrown
from the holder in the event of a
sudden stop or an accident, pos-
sibly injuring the passengers in
the vehicle.
•
Do not open the sunglass holder
while the vehicle is moving. The
rear view mirror of the vehicle
OYF049139N
can be blocked by an open sun-
OYF049140N
Sunglass holder
glass holder.
Multi box
To open the sunglass holder, press the
To open the cover, press the button and
cover and the holder will slowly open.
the multibox will automatically open.
Place your sunglasses in the compart-
ment door with the lenses facing out.
Push to close.
4 99
Features of your vehicle
INTERIOR FEATURES
Cup holder
■ Front
WARNING - Hot liquids
• Do not place uncovered cups of
hot liquid in the cup holder while
the vehicle is in motion. If the hot
liquid spills, you may burn your-
self. Such a burn to the driver
could lead to loss of control of
the vehicle.
• To reduce the risk of personal
OYF049143N
OYF049145
injury in the event of sudden stop
■ Rear
or collision, do not place uncov-
ered or unsecured bottles, glass-
es, cans, etc., in the cup holder
while the vehicle is in motion.
OYF049144N
HTG2174
Cups or small beverage cans may be
Sunvisor
placed in the cup holders.
Use the sunvisor to shield direct light
through the front or side windows.
To use a sunvisor, pull it downward.
To use a sunvisor for a side window, pull
it downward, unsnap it from the bracket
(1) and swing it to the side (2).
4 100
Features of your vehicle
Adjust the sunvisor extension forward or
backward (4).
CAUTION
To use the vanity mirror, pull down the
•
Use the power outlet only when
visor and slide the mirror cover (3).
the engine is running and remove
Push the switch to turn the light on or off.
the accessory plug after use.
(if equipped)
Using the accessory plug for pro-
longed periods of time with the
•
: The light turns on.
engine off could cause the bat-
• O
: The light turns off.
tery to discharge.
•
Only use 12V electric accessories
CAUTION - Vanity mirror
which are less than 10A in elec-
lamp (if equipped)
tric capacity.
•
Always have the switch in the off
OYF049146N
•
Adjust the air-conditioner or
position when the vanity mirror
heater to the lowest operating
Power outlet
lamp is not in use. If the sunvisor
level when using the power outlet.
The power outlet is designed to provide
is closed without the lamp off, it
•
Close the cover when not in use.
power for mobile telephones or other
may discharge the battery or
devices designed to operate with vehicle
•
Some electronic devices can
damage the sunvisor.
cause electronic interference
electrical systems. The devices should
•
Always use the sunvisor exten-
when plugged into a vehicle’s
draw less than 10 amps with the engine
sion, after swing the sunvisor to
power outlet. These devices may
running.
the side.
cause excessive audio static and
malfunctions in other electronic
systems or devices used in your
vehicle.
WARNING
Do not put a finger or a foreign ele-
ment (pin, etc.) into a power outlet
and do not touch with a wet hand.
You may get an electric shock.
4 101
Features of your vehicle
Hour (1)
Pressing the H button with your finger, a
pencil or similar object will advance the
time displayed by one hour.
Minute (2)
Pressing the M button with your finger, a
pencil or similar object will advance the
time displayed by one minute.
Display conversion
To change the 12 hour format to the 24
OYF049224
OUN026348
hour format, press the “H” and “M” but-
Digital clock (if equipped)
tons at the same time for more than 3
Clothes hanger (if equipped)
seconds.
To use the hanger, pull down the upper
For example, if the “H” and “M” buttons
portion of hanger.
WARNING
are pressed for more than 3 seconds
Do not adjust the clock while driv-
while the time is 10:15 p.m., the display
ing. You may lose your steering
CAUTION
will be changed to 22:15.
control and cause an accident that
Do not hang heavy clothes,
results in severe personal injury or
because it may damage the hook.
❈ For the type of the clock built in the
death.
audio or navigation, refer to a separately
supplied manual.
Whenever the battery terminals or relat-
ed fuses are disconnected, you must
reset the time.
When the ignition switch is in the ACC or
ON position, the clock buttons operate as
follows:
4 102
Features of your vehicle
WARNING
The following must be observed
when installing ANY floor mat to
the vehicle.
• Ensure that the floor mats are
securely attached to the vehicle’s
floor mat anchor(s) before driving
the vehicle.
• Do not use ANY floor mat that
cannot be firmly attached to the
vehicle’s floor mat anchors.
OYF049234N
OYF049147N
• Do not stack floor mats on top of
Floor mat anchor(s)
one another (e.g. all-weather rub-
Aux, USB and iPod® port
When using a floor mat on the front floor
ber mat on top of a carpeted floor
(if equipped)
carpet, make sure it attaches to the floor
mat). Only a single floor mat
If your vehicle has an aux and/or
mat anchor(s) in your vehicle. This keeps
should be installed in each posi-
USB(universal serial bus) port or iPod
the floor mat from sliding forward.
tion.
port, you can use an aux port to connect
IMPORTANT - Your vehicle was
audio devices and a USB port to plug in
manufactured with driver’s side
a USB, and an iPod port to plug in an
floor mat anchors that are
iPod.
designed to securely hold the
floor mat in place. To avoid any
✽ NOTICE
interference with pedal operation,
HYUNDAI recommends that only
When using a portable audio device
the HYUNDAI floor mat designed
connected to the power outlet, noise may
for use in your vehicle be
occur during playback. If this happens,
installed.
use the power source of the portable
audio device.
❈ iPod is a trademark of Apple Inc.
4 103
Features of your vehicle
Navigation system (if equipped)
The navigation system ascertains the
present position of your vehicle by using
information from satellites and guides
you to the place you assign as the desti-
nation.
Detailed information for the navigation
system is described in a separately sup-
plied manual.
Bluetooth hands-free
(if equipped)
You can use the phone wirelessly by
using the Bluetooth.
Detailed information for the Bluetooth
hands-free is described in the “audio” in
this chapter or in the manual supplied
separately.
4 104
Features of your vehicle
AUDIO SYSTEM
✽ NOTICE
If you install an after market HID head
lamp, your vehicle's audio and electron-
2
ic device may malfunction.
1
3
OYF049150
Steering wheel audio control
Antenna
(if equipped)
Glass antenna (if equipped)
The steering wheel may incorporate
When the radio power switch is turned on
audio control buttons.
while the ignition key is in either the “ON”
or “ACC” position, your car will receive
both AM and FM broadcast signals
CAUTION
through the antenna in the rear window
Do not operate audio remote con-
glass.
trol buttons simultaneously.
CAUTION
• Do not clean the inside of the rear
window glass with a cleaner or
scraper to remove foreign deposits
as this may cause damage to the
antenna elements.
• Avoid adding metallic coatings
such as Ni, Cd, and so on. These
can disturb receiving AM and FM
broadcast signals.
4 105
Features of your vehicle
1. VOLUME (VOL+/-)
RADIO mode
FM radio reception
• Push the lever upward (+) to increase the
It will function as the PRESET STATION
volume.
buttons.
• Push the lever downward (-) to decrease
the volume.
CD/USB/ iPod mode
2. PRESET/SEEK (
/
)
It will function as TRACK UP/DOWN
The SEEK/PRESET button has different
button.
functions based on the system mode.
For the following functions the button
3. MODE
should be pressed for
0.8 second or
Press the button to change audio source.
more.
- FM(1~2)➟ AM➟ SAT(1~3)➟ CD➟ USB
JBM001
AUX(iPod) FM...
D300800AHM
RADIO mode
How vehicle audio works
It will function as the AUTO SEEK select
Detailed information for audio control
AM and FM radio signals are broadcast
button.
buttons are described in the following
from transmitter towers located around
pages in this section.
your city. They are intercepted by the
CD/USB/ iPod mode
radio antenna on your vehicle. This signal
It will function as the FF/REW button.
is then received by the radio and sent to
your vehicle speakers.
If the SEEK/PRESET button is pressed
When a strong radio signal has reached
for less than 0.8 second, it will work as
your vehicle, the precise engineering of
follows in each mode.
your audio system ensures the best pos-
sible quality reproduction. However, in
some cases the signal coming to your
vehicle may not be strong and clear. This
can be due to factors such as the dis-
tance from the radio station, closeness of
other strong radio stations or the pres-
ence of buildings, bridges or other large
obstructions in the area.
4
106
Features of your vehicle
AM (MW, LW) radio reception
FM radio station
JBM002
JBM003
JBM004
AM (MW, LW) broadcasts can be
FM broadcasts are transmitted at high
• Fading - As your car moves away from
received at greater distances than FM
frequencies and do not bend to follow the
the radio station, the signal will weaken
broadcasts. This is because AM (MW,
earth's surface. Because of this, FM
and sound will begin to fade. When this
LW) radio waves are transmitted at low
broadcasts generally begin to fade at
occurs, we suggest that you select
frequencies. These long, low frequency
short distances from the station. Also,
another stronger station.
FM signals are easily affected by build-
radio waves can follow the curvature of
• Flutter/Static
- Weak FM signals or
ings, mountains, or other obstructions.
the earth rather than travelling straight
large obstructions between the trans-
These can result in certain listening con-
out into the atmosphere. In addition, they
mitter and your radio can disturb the
ditions which might lead you to believe a
curve around obstructions so that they
signal causing static or fluttering nois-
problem exists with your radio. The fol-
can provide better signal coverage.
es to occur. Reducing the treble level
lowing conditions are normal and do not
may lessen this effect until the distur-
indicate radio trouble:
bance clears.
4 107
Features of your vehicle
Satellite radio reception
• If you are driving on a mountain road
where the signal is blocked by mountains.
You may experience problems in receiv-
ing XM™ satellite radio signals in the fol-
lowing situations.
JBM005
• Station Swapping
- As a FM signal
weakens, another more powerful signal
SATELITE2
near the same frequency may begin to
• If you are driving in an area with tall
play. This is because your radio is
SATELITE1
trees that block the signal(10m or
designed to lock onto the clearest sig-
• If you are driving in a tunnel or a cov-
more), for example on a road through a
nal. If this occurs, select another sta-
ered parking area.
dense forest.
tion with a stronger signal.
• If you are driving beneath the top level
• The signal can become weak in some
• Multi-Path Cancellation - Radio signals
of a multi-level freeway.
areas that are not covered by the
being received from several directions
repeater station network.
• If you drive under a bridge.
can cause distortion or fluttering. This
• If you are driving next to a tall vechi-
can be caused by a direct and reflect-
Please note that these may be other
cle(such as a truck or a bus) that block
ed signal from the same station, or by
unforeseen circumstances when there
the signal.
signals from two stations with close fre-
are problems with the reception of XM™
• If you are driving in a valley where the
quencies. If this occurs, select another
satellite radio signal.
surrounding hills or peaks block the
station until the condition has passed.
signal from the satellite.
4 108
Features of your vehicle
Using a cellular phone or a two-
Care of disc (if equipped)
• Depending on the type of CD-R/CD-
way radio
RW CDs, certain CDs may not operate
•
If the temperature inside the car is too
When a cellular phone is used inside the
high, open the car windows for ventilation
normally according to manufacturing
vehicle, noise may be produced from the
before using your car audio.
companies or making and recording
methods. In such circumstances, if you
audio equipment. This does not mean
•
It is illegal to copy and use MP3/WMA/
that something is wrong with the audio
still continue to use those CDs, they
AAC/WAVE files without permission.
equipment. In such a case, use the cellu-
may cause the malfunction of your car
Use CDs that are created only by lawful
lar phone at a place as far as possible
audio system.
means.
from the audio equipment.
•
Do not apply volatile agents such as
✽ NOTICE - Playing an
benzene and thinner, normal cleaners
CAUTION
and magnetic sprays made for ana-
Incompatible Copy-Protected
When using a communication sys-
logue disc onto CDs.
Audio CD
tem such a cellular phone or a radio
•
To prevent the disc surface from get-
Some copy protected CDs, which do not
set inside the vehicle, a separate
comply with the international audio CD
ting damaged. Hold and carry CDs by
external antenna must be fitted.
standards (Red Book), may not play on
the edges or the edges of the center
When a cellular phone or a radio set
your car audio. Please note that if you
hole only.
is used with an internal antenna
try to play copy protected CDs and the
•
Clean the disc surface with a piece of
alone, it may interfere with the vehi-
CD player does not perform correctly
soft cloth before playback (wipe it from
cle's electrical system and adverse-
the CDs maybe defective, not the CD
the center to the outside edge).
ly affect safe operation of the vehi-
player.
cle.
•
Do not damage the disc surface or
attach pieces of sticky tape or paper
onto it.
•
Make sure on undesirable matter other
WARNING
than CDs are inserted into the CD
Don't use a cellular phone when
player (Do not insert more than one
you are driving. You must stop at a
CD at a time).
safe place to use a cellular phone.
•
Keep CDs in their cases after use to
protect them from scratches or dirt.
4 109
Features of your vehicle
RADIO, SET UP, VOLUME, AUDIO CONTROL
CD Player : PA710YF
1. AM Selection Button
2. FM Selection Button
3. FM/AM Button
4. Power ON/OFF Button & Volume Control
Knob
5. Preset Button
6. SCAN Button
7. MUTE Button
CD Changer : PA760YF
8. SETUP Button
9. Manual Channel Selector & Sound
Quality Control Knob
10. Manual Channel Selector
11. Automatic Channel Selection Button
❈ The actual feature may differ from the illustration.
❋There will be no
,
,
logo if the Bluetooth/XM SATELLITE/HD RADIO feature is not supported.
4 110
Features of your vehicle
1. AM Selection Button
5. Preset Button
8. SETUP Button
Pressing the [AM] button selects the AM
Push [1]~[6] buttons less than 0.8 sec-
CD Player : PA710YF
band. AM Mode is displayed on the LCD.
ond to play the channel saved in each
Press this button to turn to the XM option
button.Push Preset button for 0.8 second
and the other adjustment mode.
or longer to save current channel to the
2. FM Selection Button
If no action is taken for 5 seconds after
respective button with a beep.
pressing the button, it will return to the
Turns to FM mode and toggles FM1and
play mode.(After entering SEPUP mode,
FM2 when the button is pressed each
6. SCAN Button
move between items using the left, right
time.
and PUSH functions of the
[TUNE]
• When the button is pressed, it automat-
ically scans the radio stations upwards.
knob.)
3. FM/AM Button
The setup changes in the order of TEXT
• The SCAN feature steps through each
Turns to FM or AM mode, and toggles in
SCROLL➟AVC➟BT➟XM
station, starting from the initial station,
the order of FM1➟FM2➟AM➟FM1...
for ten seconds.
when the button is pressed each time.
• press the [SCAN] button again to stop
CD Changer : PA760YF
the scan feature and to listen to the cur-
In case of PA760YF, Using the [ FOLD-
4. Power ON/OFF Button & Volume
rently selected channel.
ER
] and [ENTER] button.
Control Knob
The setup Change in the order of
Turns on/off the set when the IGNITION
7. MUTE Button
SOUND➟XM➟HD RADIO➟AVC➟CLOCK
SWITCH is on ACC or ON. If the button
Press the button to mute the sound.
➟SCROLL➟PHONE➟RETURN
is turned to the right, it increases the vol-
ume and left,decreases the volume.
• Adjusts the volume of the car audio
• SCROLL(TEXT SCROLL)
system. Rotate clockwise to increase
(CD Player : PA710YF)
the volume or counterclockwise to
This funtion is used to display charac-
decrease.
ters longer than the LCD text display
and can be turned ON/OFF through the
sound quality control knob.
(For CD Changer : PA760YF, Press the
[
FOLDER
] button.)
4 111
Features of your vehicle
• AVC
• CLOCK(CD Changer : PA760YF)
Pressing the [ FOLDER
] button to
This funtion automatically adjusts the
select the Variable EQ the following order
Pressing the [ FOLDER
] button
volume level according to the speed of
: Normal, Powerful, Concert Select and
to adjust the clock in the following
the vehicle and can be turned ON/OFF
press the [ENTER] button to complete
order: CLOCK SET, TIME FORMAT,
through the sound quality control knob.
and exit from Variable EQ set up mode.
RETURN. Adjust the CLOCK SET and
(For CD Changer : PA760YF, Press the
press [ENTER] button to set.
[
FOLDER
] button.)
Use the same method to adjust TIME
• XM
FORMAT and press the [ENTER] but-
It will be able to change the XM display.
ton to complete and exit and from clock
• SOUND(CD Changer : PA760YF)
ex) Display by category/channel or
adjustment mode.
Pressing the [ FOLDER
] button
artist/song title.
to select the sound the following order
Select the XM Display through the [
: Sound Setup, Variable EQ Select the
9. Manual Channel Selector &
FOLDER
] button(for CD Player :
Sound Setup and press [ENTER] the
Sound Quality Control Knob
PA710YF, Turn the control knob), and
button to set.
press the [ENTER] button(for CD Player
CD Player : PA710YF
Pressing the [ENTER] button to adjust
: PA710YF, press the [TUNE] knob) to
Turn this control while listening to a radio
the Sound Setup the following order :
complete and exit XM setup mode.
channel to manually adjust frequency.
BASS, MIDDLE, TREBLE, FADER,
BALANCE. Select the BASS and press
Turn clockwise to increase frequency
• HD RADIO
the [
FOLDER
] button to set.
and counterclockwise to reduce fre-
This funtion is used to enable FM/AM
Use the same method to adjust MID-
quency. Pressing the button changes
HD RADIO receptions, and detail dis-
DLE, TREBLE, FADER, BALANCE
the BASS, MIDDLE, TREBLE, FADER
play. Press the [ FOLDER
] button
and press the button to [ENTER] com-
and BALANCE TUNE mode.
to select the HD RADIO setup the fol-
plete and exit from Sound Setup adjust-
The mode selected is shown on the dis-
lowing order
: HD RADIO FM, HD
ment mode.
play. After selecting each mode, rotate
RADIO AM, Details. Press the [ENTER]
the Audio control knob clockwise or
button to the HD RADIO setup and can
• Variable EQ(CD Changer : PA760YF)
counterclockwise.
be turned ON/OFF through the [
Pressing the [ FOLDER
] button
FOLDER
] button.
to Select the sound the following order
Press the [ENTER] button to complete
BASS Control
: Sound Setup, Variable EQ Select the
and exit HD RADIO setup mode.
To increase the BASS, rotate the knob
Variable EQ and press the [ENTER]
clockwise, while to decrease the BASS,
button to set.
rotate the knob counterclockwise.
4 112
Features of your vehicle
MIDDLE Control
10. Manual Channel Selector
To increase the MIDDLE, rotate the knob
CD Player : PA710YF
clockwise, while to decrease the MID-
Press the [ FOLDER
] button while
DLE, rotate the knob counterclockwise.
listening to a radio channel to manually
adjust frequency.
TREBLE Control
To increase the TREBLE, rotate the knob
11. Automatic Channel Selection
clockwise, while to decrease the TRE-
Button
BLE, rotate the knob counterclockwise.
CD Changer : PA760YF
FADER Control
•
When the
[SEEK
]
button is
Turn the control knob clockwise to
pressed, it increases the band frequen-
emphasize rear speaker sound(front
cy to automatically select channel.
speaker sound will be attenuated).
Stops at the previous frequency if no
channel is found.
When the control knob is turned counter-
clockwise, front speaker sound will be
•
When the [TRACK
] button is press-
emphasized(rear speaker sound will be
ed, it reduces the band frequency to
attenuated).
automatically select channel. Stops at
the previous frequency if no channel is
found.
BALANCE Control
Rotate the knob clockwise to emphasize
right speaker sound(left speaker sound
will be attenuated).
When the control knob is turned counter
clockwise, left speaker sound will be
emphasized(right speaker sound will be
attenuated).
4 113
