Safety features of your vehicle
OYF039006
OYF039008
OMG038400
Seatback angle (if equipped)
Lumbar support (for driver’s seat)
Headrest
Push the upper part of the switch forward
(if equipped)
The driver's and front passenger's seats
or rearward to move the seatback to the
The lumbar support can be adjusted by
are equipped with a headrest for the
desired angle. Release the switch once
pressing the lumbar support switch on
occupant's safety and comfort.
the seat reaches the desired position.
the side of the drivers seat. Press the
The headrest not only provides comfort
front portion of the switch to increase
for the driver and front passenger, but
support, or the rear portion of the switch,
also helps to protect the head and neck
to decrease support.
in the event of a collision.
3 7
Safety features of your vehicle
WARNING
•
For maximum effectiveness in
case of an accident, the headrest
should be adjusted so the middle
of the headrest is at the same
height of the center of gravity of
an occupant's head. Generally,
the center of gravity of most peo-
ple's head is similar with the
height of the top of their eyes.
Also, adjust the headrest as close
to your head as possible. For this
OYF039010
OYF039012
reason, the use of a cushion that
Adjusting the height up and down
Removal
holds the body away from the
To raise the headrest, pull it up to the
To remove the headrest, raise it as far as
seatback is not recommended.
desired position (1). To lower the head-
it can go then press the release button (1)
•
Do not operate the vehicle with
rest, push and hold the release button (2)
while pulling upward (2).
the headrests removed as severe
on the headrest support and lower the
To reinstall the headrest, put the head-
injury to the occupants may
headrest to the desired position (3).
rest poles (3) into the holes while press-
occur in the event of an accident.
ing the release button (1). Then adjust it
Headrests may provide protec-
to the appropriate height.
tion against neck injuries when
properly adjusted.
•
Do not adjust the headrest posi-
WARNING
tion of the driver's seat while the
Make sure the headrest locks in
vehicle is in motion.
position after adjusting it to proper-
ly protect the occupants.
3 8
Safety features of your vehicle
Type A
During mild weather or under conditions
where the operation of the seat warmer
is not needed, keep the switches in the
"OFF" position.
• The temperature setting of the seat is
changed as follows :
Switch
LO
Center
HI
position
Temperature
LOW
OFF
HIGH
OYF039013N
Type B
HNF2041-1
✽ NOTICE
Active headrest (if equipped)
With the seat warmer switch in the LO
The active headrest is designed to move
or HI position, the heating system in the
forward and upward during a rear impact.
seat turns off or on automatically
This helps to prevent the driver's and
depending on the seat temperature.
front passenger’s head from moving
rearward and thus helps prevent neck
injuries.
WARNING
OYF039014
A gap between the seat and the
Seat warmer (if equipped)
headrest release button may
The seat warmer is provided to warm the
appear when seating on the seat or
front seats during cold weather. With the
when you push or pull the seat. Be
ignition switch in the ON position, push
careful not to get your finger, etc.
either of the switches to warm the driver's
caught in the gap.
seat or the front passenger's seat.
3 9
Safety features of your vehicle
CAUTION
WARNING - Seat warmer
•
When cleaning the seats, do not
burns
use an organic solvent such as
Passengers should use extreme
thinner, benzene, alcohol and
caution when using seat warmers
gasoline. Doing so may damage
due to the possibility of excess
the surface of the heater or seats.
heating or burns. The occupants
•
To prevent overheating the seat
must be able to feel if the seat is
warmer, do not place blankets,
becoming too warm and to turn the
cushions or seat covers on the
seat warmer off. In particular, the
seats while the seat warmer is in
driver must exercise extreme care
operation.
for the following types of passen-
•
Do not place heavy or sharp
gers:
OYF039015
objects on seats equipped with
1. Infants, children, elderly or dis-
Seatback pocket
seat warmers. Damage to the seat
abled persons, or hospital outpa-
The seatback pocket is provided on the
warming components could occur.
tients
back of the front passenger’s and driver’s
2. Persons with sensitive skin or
seatbacks.
those that burn easily
3. Fatigued individuals
WARNING - Seatback
4. Intoxicated individuals
pockets
5. Individuals taking medication
Do not put heavy or sharp objects
that can cause drowsiness or
in the seatback pockets. In an acci-
sleepiness
(sleeping pills, cold
dent they could come loose from
tablets, etc.)
the pocket and injure vehicle occu-
pants.
3 10
Safety features of your vehicle
WARNING
WARNING
For proper operation of the occu-
•
For maximum effectiveness in
pant classification system:
case of an accident, the headrest
•
Do not place any items cumula-
should be adjusted so the middle
tively weighing over 2.2 lbs (1 kg)
of the headrest is at the same
in the seatback pocket or on the
height of the center of gravity of
seat.
an occupant's head. Generally,
the center of gravity of most peo-
•
Do not hang onto the front pas-
ple's head is similar with the
senger seat.
height of the top of their eyes.
Also adjust the headrest as close
ONF039401
to your head as possible. For this
reason, the use of a cushion that
Rear seat
holds the body away from the
Headrest
seatback is not recommended.
The rear seat(s) is equipped with head-
•
Do not operate the vehicle with
rests in all the seating positions for the
the headrests removed as severe
occupant's safety and comfort.
injury to an occupant may occur
The headrest not only provides comfort
in the event of an accident.
for passengers, but also helps to protect
Headrests may provide protec-
the head and neck in the event of a colli-
tion against severe neck injuries
sion.
when properly adjusted.
3 11
Safety features of your vehicle
OYF039047
OYF039048
OYF039018
Adjusting the height up and down
Removal
Seat warmer (if equipped)
To raise the headrest, pull it up (1). To
To remove the headrest, raise it as far as
The seat warmer is provided to warm the
lower the headrest, push and hold the
it can go then press the release button
rear seats during cold weather. With the
release button (2) on the headrest sup-
(1) while pulling upward (2).
ignition switch in the ON position, push
port and lower the headrest (3).
To reinstall the headrest, put the head-
either switch to warm the seat.
rest poles (3) into the holes while press-
During mild weather or under conditions
ing the release button (1). Then adjust it
where the operation of the seat warmer
to the appropriate height.
is not needed, keep the switches in the
"OFF" position.
WARNING
Make sure the headrest locks in
✽ NOTICE
position after adjusting it to proper-
With the seat warmer switch in ON
ly protect the occupants.
position, the heating system in the seat
turns off or on automatically depending
on the seat temperature.
3 12
Safety features of your vehicle
CAUTION
WARNING - Seat warmer
•
When cleaning the seats, do not
burns
use an organic solvent such as
Passengers should use extreme
thinner, benzene, alcohol or gaso-
caution when using seat warmers
line. Doing so may damage the
due to the possibility of excess
surface of the heater or seats.
heating or burns. In particular, the
•
To prevent overheating the seat
driver must exercise extreme care
warmer, do not place blankets,
for the following types of passen-
cushions or seat covers on the
gers:
seats while the seat warmer is in
1. Infants, children, elderly or hand-
operation.
icapped persons, or hospital out-
•
Do not place heavy or sharp
patients
OYF039019N
objects on seats equipped with
2. Persons with sensitive skin or
Armrest
seat warmers. Damage to the seat
those that burn easily
The armrest is located in the center of
warming components could occur.
3. Fatigued individuals
the rear seat. Pull the armrest down and
4. Intoxicated individuals
you will find the cup holders.
5. Individuals taking medication
that can cause drowsiness or
sleepiness
(sleeping pills, cold
tablets, etc.)
3 13
Safety features of your vehicle
Folding the rear seat
The rear seatbacks can be folded to facil-
itate carrying long items or to increase
the luggage capacity of the vehicle.
WARNING
The purpose of the fold-down rear
seatbacks is to allow you to carry
longer objects that could not be
accommodated in the cargo area.
Never allow passengers sit on top
of the folded down seatback while
OYF039021N
OYF039061N
the vehicle is moving. This is not a
To fold down the rear seatback:
2. Make sure the rear seat belt webbing
proper seating position and no seat
1. Insert the rear seat belt buckle in the
is in the guide to prevent the seat belt
belts are available for use.
from being damaged.
pocket (if equipped) between the rear
This could result in serious injury
seatback and cushion.
3. Set the front seatback to the upright
or death in case of an accident or
position and if necessary, slide the
sudden stop. Objects carried on the
front seat forward.
folded down seatback should not
4. Lower the rear headrests to the lowest
extend higher than the top of the
position.
front seatbacks. Doing this could
allow cargo to slide forward and
cause injury or damage during sud-
den stops.
3 14
Safety features of your vehicle
6. To use the rear seat, lift and pull the
seatback rearward by pulling on the
WARNING
folding lever. Pull the seatback firmly
When you return the rear seatback
until it clicks into place. Make sure the
to its upright position after being
seatback is locked in place.
folded down:
When you return the seatback to its
Be careful not to damage the seat
upright position, always be sure it has
belt webbing or buckle. Do not
locked into position by pushing on the
allow the seat belt webbing or
top of the seatback.
buckle to get caught or pinched in
7. Return the rear seat belt to the proper
the rear seat. Ensure that the seat-
position.
back is completely locked into its
OYF039052N
upright position by pushing on the
top of the seatback. Otherwise, in
an accident or sudden stop, the
seat could fold down and allow
cargo to enter the passenger com-
partment, which could result in
serious injury or death.
WARNING - Uprighting
seat
OYF039051N
When you return the seatback to its
5. Pull on the seatback folding lever locat-
upright position, hold the seatback
ed in the trunk, then fold the seat
and return it slowly. If the seatback
toward the front of the vehicle.
is returned without holding it, the
back of the seat could spring for-
ward resulting in injury caused by
being struck by the seatback.
3 15
Safety features of your vehicle
CAUTION - Damaging rear
WARNING - Cargo
seat belt buckles
Cargo should always be secured to
When you fold the rear seatback,
prevent it from being thrown about
insert the buckle in the pocket
the vehicle in a collision and caus-
between the rear seatback and
ing injury to the vehicle occupants.
cushion. Doing so can prevent the
Do not place objects in the rear
buckle from being damaged by the
seats, since they cannot be proper-
rear seatback.
ly secured and may hit the front
seat occupants in a collision.
CAUTION - Rear seat belts
When returning the rear seatbacks
WARNING - Cargo loading
to the upright position, remember
Make sure the engine is off, the
to return the rear shoulder belts to
automatic transaxle is in P (Park)
their proper position. Routing the
and the parking brake is securely
seat belt webbing through the rear
applied whenever loading or
seat belt guides will help keep the
unloading cargo. Failure to take
belts from being trapped behind or
these steps may allow the vehicle
under the seats.
to move if the shift lever is inadver-
tently moved to another position.
3 16
Safety features of your vehicle
SEAT BELTS
Seat belt restraint system
(Continued)
(Continued)
• Avoid wearing twisted seat belts.
Care should be taken to avoid con-
WARNING
A twisted belt can't do its job as
tamination of the webbing with pol-
•
For maximum restraint system
well. In a collision, it could even
ishes, oils and chemicals and par-
protection, the seat belts must
cut into you. Be sure the belt
ticularly battery acid. Cleaning may
always be used whenever the car
webbing is straight and not twist-
safely be carried out using mild
is moving.
ed.
soap and water. The belt should be
•
Seat belts are most effective
• Be careful not to damage the belt
replaced if webbing becomes
when seatbacks are in the
webbing or hardware. If the belt
frayed, contaminated or damaged.
upright position.
webbing or hardware is dam-
It is essential to replace the entire
aged, replace it.
assembly after it has been worn in
•
Children age
12 and younger
a severe impact even if damage to
must always be properly
the assembly is not obvious. Belts
restrained in the rear seat. Never
should not be worn with straps
allow children to ride in the front
WARNING
twisted. Each seat belt assembly
passenger seat. If a child over 12
Seat belts are designed to bear
must only be used by one occu-
must be seated in the front seat,
upon the bony structure of the
pant; it is dangerous to put a belt
he/she must be properly belted
body, and should be worn low
around a child being carried on the
and the seat should be moved as
across the front of the pelvis, chest
occupant's lap.
far back as possible.
and shoulders, as applicable; wear-
•
Never wear the shoulder belt
ing the lap section of the belt
under your arm or behind your
across the abdominal area must be
back. An improperly positioned
WARNING
avoided.
shoulder belt can cause serious
No modifications or additions
Seat belts should be adjusted as
injuries in a crash. The shoulder
should be made by the user which
firmly as possible, consistent with
belt should be positioned midway
comfort, to provide the protection
will either prevent the seat belt
over your shoulder across your
for which they have been designed.
adjusting devices from operating to
collarbone.
remove slack, or prevent the seat
A slack belt will greatly reduce the
(Continued)
belt assembly from being adjusted
protection afforded to the occu-
to remove slack.
pant.
(Continued)
3 17
Safety features of your vehicle
Conditions
Warning Pattern
Type A
Vehicle
Chime-
Seat Belt
Light-Blink
Speed
Sound
Unbuckled
6 seconds
Buckled
6 seconds
None
Below 3 mph
6 seconds
None
(5 km/h)
Buckled →
3 mph~
6 seconds
Unbuckled
6 mph
OYF039060N
Above 6 mph
6 sec. on / 24 sec. off
Type B
(10 km/h)
(11 times)
1GQA2083
Seat belt warning (for driver’s seat)
Above 6 mph
(10 km/h)
6 seconds *1
The driver's seat belt warning light and
chime will activate to the following table
Unbuckled
↓
↓
when the ignition switch is in "ON" posi-
Below 3 mph
Stop *2
tion.
(5 km/h)
*1 Warning pattern repeats 11 times with
an interval of 24 seconds. If the driver's
seat belt is buckled, the light will stop
OYF039054N
within 6 seconds and chime will stop
Seat belt warning (for front passen-
immediately.
ger’s seat)
*2 The light will stop within 6 seconds and
The front passenger's seat belt warning
chime will stop immediately.
light will activate to the following table
when the ignition switch is in "ON" posi-
tion.
3 18
Safety features of your vehicle
Conditions
Warning Pattern
✽ NOTICE
Vehicle
•
You can find the front passenger's seat
Seat Belt
Light-Blink
Speed
belt warning light on the center fascia
panel.
Unbuckled
6 seconds
•
Although the front passenger seat is
Above 6mph
Unbuckled
Continuously
not occupied, the seat belt warning
(10 km/h)
light will blink for 6 seconds.
Buckled
6 seconds
•
The seat belt warning light can blink
Above 6mph
when a briefcase or purse is placed on
Continuously *1
(10 km/h)
the front passenger seat.
Buckled →
Unbuckled
Below 6mph
None
(10 km/h)
B180A01NF-1
Seat belt - Driver's 3-point system
*1 The seat belt warning light will go off if
with emergency locking retractor
the vehicle speed decreases below 3
To fasten your seat belt:
mph (5 km/h). If the vehicle speed
To fasten your seat belt, pull it out of the
increases above 3 mph (5 km/h), the
retractor and insert the metal tab (1) into
warning light will blink again.
the buckle (2). There will be an audible
"click" when the tab locks into the buckle.
The seat belt automatically adjusts to the
proper length only after the lap belt por-
tion is adjusted manually so that it fits
snugly around your hips. If you lean for-
ward in a slow, easy motion, the belt will
extend and let you move around. If there
is a sudden stop or impact, however, the
belt will lock into position. It will also lock
if you try to lean forward too quickly.
3 19
Safety features of your vehicle
Front seat
To raise the height adjuster, pull it up (1).
To lower it, push it down (3) while press-
WARNING
ing the height adjuster button (2).
•
Verify the shoulder belt anchor is
Release the button to lock the anchor
locked into position at the appro-
into position. Try sliding the height
priate height. Never position the
adjuster to make sure that it has locked
shoulder belt across your neck or
into position.
face. Improperly positioned seat
belts can cause serious injuries
in an accident.
•
Failure to replace seat belts after
an accident could leave you with
damaged seat belts that will not
OHD036019
provide protection in the event of
Height adjustment
another collision leading to per-
sonal injury or death. Replace
You can adjust the height of the shoulder
your seat belts after being in an
belt anchor to one of 4 positions for max-
imum comfort and safety.
accident as soon as possible.
The height of the adjusting seat belt
should not be too near your neck. The
shoulder portion should be adjusted so
that it lies across your chest and midway
over your shoulder nearest the door and
not your neck.
To adjust the height of the seat belt
anchor, lower or raise the height adjuster
into an appropriate position.
3 20
Safety features of your vehicle
Seat belts - Front passenger and rear
When the seat belt is fully extended from
seat 3-point system with combination
the retractor to allow the installation of a
locking retractor
child restraint system, the seat belt oper-
To fasten your seat belt:
ation changes to allow the belt to retract,
but not to extend
(Automatic Locking
Combination retractor type seat belts are
Retractor Type). Refer to “Using a child
installed in the rear seat positions to help
restraint system” in this section.
accommodate the installation of child
restraint systems. Although a combina-
tion retractor is also installed in the front
✽ NOTICE
passenger seat position, it is strongly
Although the combination retractor
recommended that children always be
provides the same level of protection for
seated in the rear seat. NEVER place
seated passengers in either emergency
B200A02NF
any infant restraint system in the front
or automatic locking modes, it is recom-
seat of the vehicle.
mended that seated passengers use the
This type of seat belt combines the fea-
emergency locking feature for improved
WARNING
tures of both an emergency locking
convenience. The automatic locking
You should place the lap belt por-
retractor seat belt and an automatic lock-
function is intended to facilitate child
tion as low as possible and snugly
ing retractor seat belt. To fasten your seat
restraint installation. To convert from
across your hips, not on your waist.
belt, pull it out of the retractor and insert
the automatic locking feature to the
If the lap belt is located too high on
the metal tab into the buckle. There will
emergency locking operation mode,
your waist, it may increase the
be an audible "click" when the tab locks
allow the unbuckled seat belt to fully
chance of injury in the event of a
into the buckle. When not securing a
retract.
collision. Both arms should not be
child restraint, the seat belt operates in
under or over the belt. Rather, one
the same way as the driver's seat belt
should be over and the other under,
(Emergency Locking Retractor Type). It
as shown in the illustration.
automatically adjusts to the proper length
Never wear the seat belt under the
only after the lap belt portion of the seat
arm nearest the door.
belt is adjusted manually so that it fits
snugly around your hips.
3 21
Safety features of your vehicle
OYF039022N
B210A01NF-1
OYF039021N
When using the rear center seat belt, the
To release the seat belt:
Stowing the rear seat belt
buckle with the “CENTER” mark must be
The seat belt is released by pressing the
The rear seat belt buckles can be stowed
used.
release button (1) in the locking buckle.
in the pocket between the rear seatback
When it is released, the belt should auto-
and cushion when not in use.
matically draw back into the retractor.
If this does not happen, check the belt to
be sure it is not twisted, then try again.
3 22
Safety features of your vehicle
When the vehicle stops suddenly, or if
the occupant tries to lean forward too
quickly, the seat belt retractor will lock
into position. In certain frontal collisions
(or side collisions), the pre-tensioner will
activate and pull the seat belt into tighter
contact against the occupant's body.
If the system senses excessive tension
on the driver or passenger's seat belt
when the pre-tensioner activates, the
load limiter inside the pre-tensioner will
release some of the pressure on the
OED030300
affected seat belt.
OBH038100
Pre-tensioner seat belt
The seat belt pre-tensioner system con-
✽ NOTICE
sists mainly of the following components.
Your vehicle is equipped with driver's and
The pre-tensioner will activate not only
Their locations are shown in the illustra-
front passenger's pre-tensioner seat
in a frontal collision but also in a side
tion:
belts. The purpose of the pre-tensioner is
to make sure that the seat belts fit tightly
collision, if the vehicle is equipped with
1. SRS air bag warning light
against the occupant's body in certain
a side or curtain air bag.
2. Retractor pre-tensioner assembly
frontal collisions (or side collisions). The
3. SRS control module
pre-tensioner seat belts may be activated
WARNING
in crashes where the frontal collision (or
side collisions) is severe enough.
Do not put anything near the buck-
le. Placing objects near the buckle
can adversely affect the buckle pre-
tensioner and may increase the risk
of personal injury in the event of a
collision.
3 23
