Hyundai Matrix (2007 year). Instruction - part 25

IN CASE OF EMERGENCY

SD070E1-E

SD070F1-F

SD070G1-E

3. Loosen Wheel Nuts

4. Put the Jack in Place

5. Raising the Vehicle

Wrench bar

Wheel nut wrench

D060D02FC

D060E02FC

HFC4022

The wheel nuts should be loosened

The base of the jack should be placed

After inserting a wrench bar into the

slightly before raising the car. To loosen

on firm, level ground. The jack should

wheel nut wrench, install the wrench bar

the nuts, turn the wheel brace counter-

be positioned as shown in the drawing.

into the jack as shown in the drawing.

clockwise. Ensure that the wheel brace

To raise the vehicle, turn the wheel nut

socket is seated properly on the nut and

wrench clockwise. As the jack begins

that it cannot slip. Do not remove the

to raise the vehicle, double check that

nuts at this stage.

it is properly positioned and will not slip.

If the jack is on soft ground or sand, it

may be necessary to place a stout

piece of timber under the base of the

jack to prevent it from sinking.

Raise the car high enough so that the

fully inflated spare wheel can be in-

stalled.

fcuk-3.p65

12/27/2006, 10:15 AM

3 IN CASE OF EMERGENCY

SD070H1-E

6. Changing Wheels

WARNING:

Do not get under the car when it is

supported by the jack! The jack is

solely designed for wheel changing

and is not intended to support the

vehicle for other purposes. The use

of purpose designed supports is nec-

essary whilst the vehicle is raised

and the operator is required to get

underneath.

D060G02E

D060G02FC

Using the wheel brace, remove the nuts

WARNING:

and slide the wheel off the hub and

It is important that the faces of the

wheel studs. Lie the wheel flat to pre-

wheel and hub are clean prior to

vent it from rolling. Ensure that the

installing the wheel. The prescence

faces of the wheel and hub are clean.

of dirt or other matter in the wheel or

Position the spare wheel over the studs

hub faces could result in the wheel

and slide it up to the hub.

nuts becoming loose whilst the vehi-

cle is being driven.

fcuk-3.p65

12/27/2006, 10:15 AM

IN CASE OF EMERGENCY

SD070I1-E

SD070J1-E

SD070K1-E

7. Re-install Wheel Nuts

8. Lower Vehicle and Tighten

After changing wheels

Nuts

D060H02FC

D060B01FC

D060I02FC

Fit the wheel nuts onto the studs and

The pressure of the spare tyre should

tighten with the wheel brace.

Lower the car to the ground turning the

be checked at the first available oppor-

wheel nut wrench counterclockwise.

tunity. If any doubt exists as to the tyre

When the vehicle is firmly on the ground,

pressure, the vehicle should be driven

remove the jack and tighten the wheel

slowly to the nearest service station

nuts securely. At the first available

and the tyre pressure checked and

opportunity, the wheel nut torque should

adjusted as required.

be checked with a suitable torque

wrench.

Wheel nut tightening torque

Steel wheel & aluminium alloy wheel:

90-110 Nm (65-80 lb.ft)

fcuk-3.p65

12/27/2006, 10:15 AM

3 IN CASE OF EMERGENCY

IF YOUR VEHICLE MUST BE

TOWED

If the valve cap is lost from any of the

D080A01O-GAT

D080B01O-GAT

valves, a replacement should be ob-

If your vehicle has to be towed, it should

Towing the Vehicle

tained and fitted at the first available

be done by your Hyundai authorised

opportunity. The valve cap prevents

repairer or a commercial tow truck ser-

the ingress of dirt which may cause the

vice. This will help assure that your

valve to stick and therefore leak and is

vehicle is not damaged in towing. Also,

part of the valve sealing function.

professionals are generally aware of

local laws governing towing. In any

Ensure that the spare wheel, jack and

case, rather than risk damage to your

wheel nut wrench as well tools are

car, it is suggested that you show this

correctly located in the boot of the

information to the tow truck operator.

vehicle to prevent damage and noise.

Be sure that a safety chain system is

used and that all local laws are ob-

served.

It is recommended that your vehicle be

dolly

towed with a wheel lift and dollies or

flatbed equipment with all the wheels

off the ground.

CAUTION:

o Your vehicle can be damaged if

HFC005

towed incorrectly!

Your vehicle can be towed by wheel lift

o Be sure the transaxle is in neutral.

type truck (1), (2) or flatbed equipment (3).

o When the engine will not start, be

sure the steering is unlocked by

placing the key in the "ACC" posi-

tion.

fcuk-3.p65

12/27/2006, 10:15 AM

IN CASE OF EMERGENCY

NOTE:

Before towing, check the level of the

CAUTION:

automatic transaxle fluid. If it is be-

CAUTION:

o When towing the vehicle, take care

low the "HOT" range on the dipstick,

not to cause damage to the bumper

add fluid. If you cannot add fluid, a

or underbody of the vehicle.

towing dolly must be used.

2) If any of the loaded wheels or sus-

pension components are damaged

or the vehicle is being towed with the

front wheels on the ground, use a

towing dolly under the front wheels.

o Manual Transaxle:

If you do not use a towing dolly, place

HFC006

the ignition key in the "ACC" position

and put the transaxle in "N (Neutral)".

A vehicle with an automatic transaxle

should never be towed from the rear

HFC004

with the front wheels on the ground.

This can cause serious damage to

o Do not tow with sling type truck as

CAUTION:

the transaxle.

this may cause damage to the

Do not tow with the key removed or

bumper or underbody of the ve-

in the "LOCK" position when towing

hicle.

from the rear without a towing dolly.

3) It is recommended that your vehicle

be towed with all the wheels off the

1) If the vehicle is being towed with the

o Automatic Transaxle:

ground.

rear wheels on the ground, be sure

Be sure to use a towing dolly under

the parking brake is released.

the front wheels.

fcuk-3.p65

12/27/2006, 10:15 AM

3 IN CASE OF EMERGENCY

EMERGENCY TOWING

IF YOU LOSE YOUR KEYS

D080D05A-EAT

D120A01A-EAT

NOTE:

Before towing, check the level of the

Information about the key of immobiliser

automatic transaxle fluid. If it is be-

system will be found on page 1-4.

low the "HOT" range on the dipstick,

add fluid. If you cannot add fluid, a

towing dolly must be used.

Front

CAUTION:

Rear

If the car is being towed with all four

D080D04FC

wheels on the ground, it can be

towed only from the front. Be sure

For emergency towing when no com-

that the transaxle is in neutral. Do not

mercial tow vehicle is available, attach

tow at speeds greater than 30 mph

a tow cable, chain or strap to one of the

(50 km/h) and for more than 15 miles

towing hooks under the front/rear of

(25 km).

your vehicle. Do not attempt to tow your

Be sure the steering is unlocked by

vehicle in this manner on any unpaved

placing the key in the "ACC" posi-

surface. This could result in serious

tion.

damage to your vehicle.

Nor should towing be attempted if the

wheels, drive train, axles, steering or

brakes are damaged. Before towing, be

sure the transaxle is in neutral and the

key is in "ACC" (with the engine off) or

in the "ON" position (with the engine

running). A driver must be in the towed

vehicle to steer it and operate the brakes.

fcuk-3.p65

12/27/2006, 10:15 AM

APPEARANCE CARE

Corrosion Protection

4-2

Underbody Coatings

4-2

Valeting

4-3

Interior

4-5

fcuk-4.p65

12/27/2006, 10:15 AM

4APPEARANCE CARE

CORROSION PROTECTION

SE020A1-E

SE030A1-E

NOTE:

Protecting Your Hyundai

Underbody Coatings

The underbody should never be

From Corrosion

Every Hyundai passenger car receives

steam cleaned since the underbody

By using the most advanced design

a full underbody and cavity injection

coating may be removed by this pro-

and construction practices, every

treatment during production. In order

cess.

that this treatment may retain maxi-

During the interim period between

Hyundai is built to retain the original

factory finish for many years. However,

mum effectiveness it is recommended

power washing the underbody, the

long term durability is also greatly de-

that the underbody receives a power

more vulnerable areas such as wheel

wash and a thorough inspection after

arches should be hosed off particu-

pendant upon maintaining the various

protection systems and coatings used

each winter season. In doing so any

larly during the winter season to

in manufacture since constant, expo-

accumulations of mud, which act as

prevent prolonged contact with road

moisture traps and combine with road

salts.

sure to the elements will result in a

breakdown and loss of effectiveness.

salts to accelerate corrosion will be

Ensure that the various drain points

The following suggestions are made to

removed. In order to maintain the Anti

located at the bottom of the door

Perforation Warranty, the requirements

panels and sills are kept clear to

assist in the maintenance of the vehicle

bodywork.

regarding the retreatment programme

prevent water from becoming trapped

must be observed in accordance with

within the cavities. Wherever pos-

the Terms and Conditions outlined in

sible, the parking of the vehicle in a

the separate Anti Perforation Warranty

confined, poorly ventilated location

Booklet.

(a garage for example) should be

avoided when the vehicle is wet or is

covered with snow or ice. Under

these conditions, the internal cavi-

ties of the vehicle will remain damp

for prolonged periods of time which

will encourage corrosion. Parking

the vehicle where good ventilation

exists (outside for example) is pref-

erable.

fcuk-4.p65

12/27/2006, 10:15 AM

CORROSION PREVENTION ANDAPPEARANCE CARE

VALETING

SE040A2-E

After removing the dirt film with a soft

Regular cleaning of the exterior

sponge, the body work should be thor-

oughly rinsed and then dried with a good

CAUTION:

paintwork serves two important func-

tions. Firstly, the removal of abrasive

quality chamois leather to prevent streak-

dirt and contaminants will maintain the

ing or spotting of the paint work.

lustre of the paintwork and will prevent

Household detergents, solvents and abra-

discolouration and dulling due to pro-

sive cleaning materials should not be used

longed contact.

in order to avoid damaging the paint film.

Secondly, the presence of damage

Plastic wheel covers should be cleaned

through impact or abrasion will be ap-

using a sponge and water. Cast alloy

parent allowing early rectification to be

wheels should be cleaned using a mild

made thus preventing corrosion from

soap or neutral detergent. Abrasive

becoming established and spreading

compounds must not be used since in

beneath the paint film. To avoid "water

the event of these damaging the lac-

OJB037800

spotting" the vehicle should not be

quer coating, oxidization of the aluminium

washed in direct sunlight particularly in

wheel will occur, spoiling the appearance.

o Water washing in the engine com-

the case of vehicles having dark body

The use of a toothbrush will facilitate

partment including high pressure

colours. The heat from the sun rays is

cleaning between the wheel "spokes".

water washing may cause the fail-

absorbed by the paint film increasing

ure of electrical circuits located in

the surface temperature. This action

the engine compartment.

causes water used for washing to

o Never allow water or other liquids

evaporate quickly leaving behind the

to come in contact with electrical/

deposits from the water and the sham-

electronic components inside the

poo used.

vehicle as this may damage them.

Use only a shampoo intended for the

purpose and ensure that the body work

is thoroughly wet to soften the dirt film

prior to attempting to remove this.

fcuk-4.p65

12/27/2006, 10:15 AM

4APPEARANCE CARE

BUMPER MAINTENANCE

BODY WORK REPAIRS

SE040B1-E

SE040E1-E

SE040F1-E

Stain/Spot Removal

The special material from which the

In the event of the body work sustaining

Should tree sap, dead insects or tar

bumpers are manufactured warrants

damage, the following points should be

prove to be difficult to remove from the

special attention to preserve the ap-

noted prior to repairs being undertaken.

paint film, turpentine or a proprietary

pearance of the bumpers. Avoid con-

If body panels are replaced or repaired,

paint cutting compound may be used.

tact with battery electrolyte or brake

anti corrosion treatment must be ap-

Ensure that the area to be cleaned is

fluid and ensure that accidental spill-

plied to the repair area. The product

not rubbed intensively to prevent break-

ages are immediately flushed with wa-

used must be compatible with those

ing through the colour coat and expos-

ter.

used in manufacture. It is recommended

ing the under coat.

Do not use abrasive cleaning materials

that repairs are entrusted to a Hyundai

which may damage the bumpers.

authorised repairer to ensure that re-

Avoid subjecting the bumpers to high

placement parts used are of the same

temperatures E.g encountered in high

high quality as those used in manufac-

bake paint ovens.

ture of the vehicle and that the correct

SE040C1-E

repair methods and materials will en-

sure adequate levels of corrosion pro-

Polishing

tection and the continued validity of the

The exterior paint work should be pol-

Anti Perforation Warranty.

ished with a proprietary wax polish when

water no longer collects in bead form on

the paint work. The instructions of the

product manufacturer should be ad-

hered to.

fcuk-4.p65

12/27/2006, 10:15 AM

CORROSION PREVENTION ANDAPPEARANCE CARE

INTERIOR

SE050A1-E

SE050D1-E

Seat Belts

During the winter period, it is possible

that the passenger compartment floor-

Seat belts should be cleaned only with

ing may become wet from damp foot-

a mild soap solution. Strong detergents,

wear or quantities of snow adhering to

solvents or bleaches may damage the

footwear. The carpet should not be

belt webbing and therefore reduce the

allowed to remain in this condition since

effectiveness of the belt. Belts which

the carpet may begin to create musty

display signs of fraying, wear or cuts

smells and will promote corrosion of the

should be replaced.

floor pan in addition to the carpet and

under felt beginning to rot.

SE050E1-E

Windows

SE050C1-E

Interior Valeting

A proprietary glass cleaner should be

used to clean the inside of the windows.

The soft trim and carpets should be

However, the rear heated windshield

maintained with the regular use of a

must only be cleaned using a light

vacuum cleaner. Heavy soiling should

horizontal cleaning action. Care should

be removed with a dry cleaning agent

be exercised to avoid the use of abra-

recommended for this purpose follow-

sive cleaners or contact with items of

ing the instructions of the product manu-

jewellery which may damage the heat-

facturer. Paint thinner, solvents or other

ing elements.

such cleaning materials should not be

used since damage to the upholstery

may result.

fcuk-4.p65

12/27/2006, 10:15 AM

VEHICLE MAINTENANCE REQUIREMENTS

Maintenance and Servicing Requirements

5-2

Scheduled Maintenance

5-3

Maintenance Under Severe Usage Conditions

5-6

Explanation of Scheduled Maintenance Items

5-7

fcuk-5.p65

12/27/2006, 10:15 AM

5 VEHICLE MAINTENANCE REQUIREMENTS

MAINTENANCE AND

SERVICING REQUIREMENTS

SF020A1-E

NOTE:

performed by the factory-trained or

To ensure the continued reliability and

The inspection and testing of cer-

distributor-trained technicians at your

safety of the vehicle, certain routine

tain electronic fuel injection/engine

Hyundai authorised repairer because

maintenance operations are required

management and automatic trans-

of the need for specialised knowledge

at specific mileage or time intervals.

mission control systems require

and tooling and to ensure that no

It is the responsibility of the vehicle

specialised electronic equipment

possibility of invalidating the manufac-

owner to ensure that the maintenance

specifically designed for Hyundai

turers warranty exists.

schedules shown in both this Owners

vehicles. The use of general pur-

The maintenance schedules relate to

Manual and the Warranty and Service

pose electrical test equipment may

vehicles operated under normal condi-

Passport are adhered to.

result in damage to the control unit

tions, vehicles which are operated

The new vehicle warranty may be

microprocessors.

under adverse conditions will require

invalidated if the routine maintenance

more frequent maintenance which is

operations are not performed in line

described at page 5-6.

SF020C2-E

with the recommendations outlined and

Specified Scheduled Procedures

NOTE:

the safety and durability of the vehicle

adversely affected.

Service schedules may change de-

The Specified scheduled procedures

It is recommended that all mainte-

pending on individual country

are listed in the maintenance charts

nance operations with the exception of

needs. Please ask your local

beginning at page 5-3. The operations

the daily operating checks are en-

Hyundai authorised repairer for a

specified must be performed at the

trusted to a Hyundai authorised re-

copy of the service schedule that

time or mileage intervals shown irre-

pairer to ensure that the latest repair

relates to that country.

spective of whether the mileage inter-

and maintenance procedures and

val has been reached before the speci-

specialised servicing tools are em-

fied time interval.

SF030B1-E

ployed.

Certain lubricants and components

SERVICE HISTORY

In addition, the use of genuine Hyundai

degrade with both time and mileage

replacement parts will ensure that the

(e.g. engine oil and brake fluid) and

It is important that all scheduled main-

vehicle safety and performance will

therefore it is not permissable to base

tenance services are recorded in the

not be compromised.

the maintenance schedule upon mile-

warranty and service passport to en-

age alone. It is strongly recommended

sure that proof of maintenance is avail-

that the maintenance operations are

able when warranty service is required.

fcuk-5.p65

12/27/2006, 10:15 AM

VEHICLE MAINTENANCE REQUIREMENTS

SCHEDULED MAINTENANCE

YF010A2-E

In order to ensure continued reliability, safety and longevity, regular maintenance performed at the intervals specified is

essential. The maintenance intervals specified are based both on time elapsed and mileage covered since the previous

maintenance service was performed. However, under severe operating conditions, certain scheduled operations should be

performed at shorter intervals. Regular maintenance should be entrusted to Hyundai authorised repairer who is best able to

provide the expertise required to ensure optimum operational performance.

In addition the use of Hyundai replacement parts and service consumables will ensure that the original build quality,

operational performance and safety are maintained.

F030B03FC-EAT

R : Replace

I : Inspect and, after inspection, clean, adjust, repair or replace if necessary

MILES X 1,000

NO.

DESCRIPTION

MONTHS

ENGINE CONTROL SYSTEM MAINTENANCE (PETROL)

ENGINE OIL & FILTER

DRIVE BELT (WATER PUMP, ALTERNATOR & A/CON)

FUEL FILTER (MFI)

FLUID LEAKS

TIMING BELT

VENTILATION HOSES

AIR CLEANER FILTER

SPARK PLUGS

VALVE CLEARANCE (1.8 DOHC)

See Note (1)

Note :

(1) INSPECT AND ADJUST EVERY 60,000 MILE OR 48 MONTHS.

fcuk-5.p65

12/27/2006, 10:15 AM

5 VEHICLE MAINTENANCE REQUIREMENTS

F030D02FC-EAT

R : Replace

I : Inspect and, after inspection, clean, adjust, repair or replace if necessary.

MILES X 1,000

NO.

DESCRIPTION

MONTHS

ENGINE CONTROL SYSTEM MAINTENANCE (DIESEL)

ENGINE OIL & FILTER

(API Class : CH-4 or ABOVE)

See Note(1)

(ACEA Class : B-4 or ABOVE)

AIR CLEANER FILTER

FUEL FILTER CARTRIDGE

TIMING BELT

DRIVE BELT (FOR P/STR'G PUMP, ALTERNATOR & A/CON)

VACUUM PUMP & VACUUM HOSE

VACUUM PUMP OIL HOSE

FUEL LINES, FUEL HOSE & CONNECTIONS

Note : (1) ON A DAILY BASIS, WHENEVER THE VEHICLE IS REFUELLED OR BEFORE STARTING A LONG TRIP :"I"

fcuk-5.p65

12/27/2006, 10:15 AM

VEHICLE MAINTENANCE REQUIREMENTS

F030C02FC-EAT

R : Replace

I : Inspect and, after inspection, clean, adjust, repair or replace if necessary

MILES X 1,000

NO.

DESCRIPTION

MONTHS

GENERAL MAINTENANCE

COOLING SYSTEM

COOLANT

See Note (1)

ENGINE COOLANT SPECIFIC GRAVITY

MANUAL TRANSAXLE OIL

AUTOMATIC TRANSAXLE FLUID

BRAKE PIPES, HOSES, AND CONNECTIONS

BRAKE FLUID

CLUTCH FLUID

REAR BRAKE LININGS AND CYLINDERS

BRAKE PADS

SUSPENSION AND STEERING SYSTEM

FRONT SUSPENSION BALL JOINTS

POLLEN FILTER (IN FRONT OF BLOWER UNIT)

REAR WHEEL BEARINGS

TYRE CONDITION AND PRESSURE (incl. Spare)

LUBRICATE LOCKS AND HINGES

CHECK ALL ELECTRICAL SYSTEMS

ROAD TEST

CHECK ALL SYSTEMS WITH HI-SCAN

Note :(1) FOR THE FIRST TIME, REPLACE THE COOLANT AT 60,000 MILES OR 60 MONTHS.

AFTER THAT, REPLACE IT EVERY 30,000 MILES OR 24 MONTHS.

fcuk-5.p65

12/27/2006, 10:15 AM

5 VEHICLE MAINTENANCE REQUIREMENTS

MAINTENANCE UNDER SEVERE USAGE CONDITIONS

F040A02FC-EAT

The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the

chart below for the appropriate maintenance intervals.

R : Replace

I : Inspect and, after inspection, clean, adjust, repair or replace if necessary

MAINTENANCE

DRIVING

MAINTENANCE ITEM

MAINTENANCE INTERVALS

OPERATION

CONDITION

ENGINE OIL AND FILTER

PETROL ENGINE

A, B,C, D, E, F, G, H, I, K

EVERY 4,500 MILES OR 6 MONTHS

DIESEL ENGINE

A, B, C, D, F, H, I, J

AIR CLEANER FILTER

MORE FREQUENTLY

C, E

SPARK PLUGS

MORE FREQUENTLY

B, H

TIMING BELT

EVERY 37,000 MILES OR 48 MONTHS

D, E, F, G

BRAKE PADS

MORE FREQUENTLY

C, D, G, H

REAR BRAKE LININGS AND CYLINDERS

MORE FREQUENTLY

C, D, G, H

SUSPENSION AND STEERING SYSTEM

MORE FREQUENTLY

C, D, E, F

MANUAL TRANSAXLE OIL

EVERY 60,000 MILES

A, C, D, E, F, G, H, I, J

AUTOMATIC TRANSAXLE FLUID

EVERY 27,000 MILES

A, C, E, F, G, H, I

POLLEN FILTER(IN FRONT OF BLOWER UNIT)

MORE FREQUENTLY

C,E

SEVERE DRIVING CONDITIONS

E - Driving in sandy areas

A - Repeatly driving short distance of less than 5miles(8km) in

F - Driving in heavy traffic area over 90°F(32°C)

normal tempera ture or less than 10miles(16km) in freezing

G - Driving on uphill, downhill, or mountain road

temperature

H - Towing a Trailer, or using a camper, or roof rack

B - Extensive engine idling or low speed driving for long distances

- Driving as a patrol car, taxi, other commercial use or

C - Driving on rough, dusty, muddy, unpaved, graveled or salt-

vehicle towing

spread roads

- Driving over 100 MPH(170 Km/h)

D - Driving in areas using salt or other corrosive materials or in

K - Frequently driving in stop-and-go conditions

very cold weather

fcuk-5.p65

12/27/2006, 10:15 AM

Content .. 23 24 25 26 ..
