Hyundai Elantra Coupe (2016 year). Instruction - part 25
What to do in an emergency
Technical Data
CAUTION - Tire pressure
System voltage: DC 12 V
sensor
Working voltage: DC 10 - 15 V
When you use the Tire Mobility
Amperage rating: max. 15 A
Kit including sealant not
approved by HYUNDAI, the tire
Suitable for use at temperatures:
pressure sensors may be dam-
-30 ~ +70°C (-22 ~ +158°F)
aged by sealant. The sealant on
Max. working pressure:
the tire pressure sensor and
wheel should be removed when
6 bar (87 psi)
you replace the tire with a new
Size
one and inspect the tire pres-
Compressor: 170 x 150 x 60 mm
sure sensors at an authorized
(6.7 x 5.9 x 2.4 in.)
dealer.
Sealant bottle: 85 x 77 ø mm
(3.3 x 3.0 ø in.)
Compressor weight:
0.8 kg (1.8 lbs)
Sealant volume:
200 ml (12.2 cu. in.)
6 27
What to do in an emergency
TOWING
Towing service
It is acceptable to tow the vehicle
with the rear wheels on the ground
(without dollies) and the front wheels
off the ground. If any of the loaded
wheels or suspension components
are damaged or the vehicle is being
towed with the front wheels on the
ground, use a towing dolly under the
front wheels.
HXD03
When being towed by a commercial
tow truck and wheel dollies are not
used, the front of the vehicle should
always be lifted, not the rear.
dolly
HXD02
OMC045012
CAUTION
If emergency towing is necessary,
• Do not tow the vehicle with the
we recommend having it done by an
front wheels on the ground as
authorized HYUNDAI dealer or a
this may cause damage to the
commercial tow-truck service.
vehicle.
Proper lifting and towing procedures
• Do not tow with sling-type
are necessary to prevent damage to
equipment. Use a wheel lift or
the vehicle. The use of wheel dollies
flatbed equipment.
or flatbed is recommended.
6 28
What to do in an emergency
When towing your vehicle in an
Removable towing hook
Emergency towing
emergency without wheel dollies:
(if equipped)
■ Front
1.Place the ignition switch in the
ACC position.
2.Place the shift lever in N (Neutral).
3.Release the parking brake.
CAUTION
Failure to place the shift lever in
N (Neutral) when being towed
OMD060011
with the front wheels on the
■ Rear
ground can cause internal dam-
age to the transaxle.
OMD060010
1.Open the trunk, and remove the
towing hook from the tool case.
2.Remove the hole cover pressing
the lower part of the cover on the
front bumper.
3.Install the towing hook by turning it
clockwise into the hole until it is
OMD060007
fully secured.
If towing is necessary, we recom-
4.Remove the towing hook and
mend you have it done by an author-
install the cover after use.
ized HYUNDAI dealer or a commer-
cial tow truck service.
6 29
What to do in an emergency
If towing service is not available in an
Always follow these emergency tow-
emergency, your vehicle may be
ing precautions:
temporarily towed using a cable or
•
Place the ignition switch in the
chain secured to the emergency tow-
ACC position so the steering
ing hook at the front (or rear) of the
wheel is not locked. (if equipped)
vehicle.
•
Place the shift lever in N (Neutral).
Use extreme caution when towing
•
Release the parking brake.
the vehicle with a cable or chain. A
driver must be in the vehicle to steer
•
Depress the brake pedal with more
it and operate the brakes.
force than normal since you will
have reduced braking perform-
Towing in this manner may be done
ance.
OTD069011
only on hard-surfaced roads for a
•
More steering effort will be
short distance and at low speeds.
•
Use a towing cable or chain less
Also, the wheels, axles, power train,
required because the power steer-
than 5 m (16 feet) long. Attach a
steering and brakes must all be in
ing system will be disabled.
white or red cloth (about 30 cm (12
good condition.
•
Use a vehicle heavier than your
inches) wide) in the middle of the
own to tow your vehicle.
cable or chain for easy visibility.
•
The drivers of both vehicles should
•
Drive carefully so the towing cable
communicate with each other fre-
or chain remains tight during tow-
quently.
ing.
•
Before emergency towing, check
•
Before towing, check the automat-
that the hook is not broken or dam-
ic transaxle for fluid leaks under
aged.
your vehicle. If the automatic
transaxle fluid is leaking, flatbed
•
Fasten the towing cable or chain
securely to the hook.
equipment or a towing dolly must
be used.
•
Do not jerk the hook. Apply steady
and even force.
6 30
What to do in an emergency
CAUTION
To avoid damage to your vehicle
and vehicle components when
towing:
• Always pull straight ahead
when using the towing hooks.
Do not pull from the side or at
a vertical angle.
• Do not use the towing hooks
to pull a vehicle out of mud,
sand or other conditions from
which the vehicle cannot be
driven out under its own
power.
• Limit the vehicle speed to
15 km/h (10 mph) and drive
less than 1.5 km (1 mile) when
towing to avoid serious dam-
age to the automatic transaxle.
6 31
What to do in an emergency
BASIC TROUBLESHOOTING GUIDE
SYMPTOM
PROBABLE CAUSE
Engine overheating
O
Low fuel level
O
O
Fuel lines clogged
O
O
Fuel pump defective
O
O
Strainer clogged
O
O
Rich mixture
O
O
O
Water intrusion into fuel
O
O
O
Coolant leakage
O
High idle speed
O
Engine oil insufficient or defective
O
O
Battery fluid shortage
O
O
Battery discharged
O
O
O
Battery terminal poor contact
O
O
Starter or ignition switch malfunction
O
Ignition timing incorrect
O
O
O
Spark plugs deteriorated
O
O
Spark plugs defective
O
6 32
What to do in an emergency
SYMPTOM
PROBABLE CAUSE
Ignition circuit faulty
O
O
Ignition coil or condensor faulty
O
O
O
Distributor faulty
O
Alternator belt loose
O
O
O
O
O
Check fuses, bulbs or wiring
O
Clutch slip
O
Clutch pedal not depressed fully
O
Brake dragging
O
O
Shift lever not positioned in "P" or "N" range (auto T/A)
O
Frequent driving in lower gear
O
Air intrusion into brake lines
O
Brake fluid insufficient
O
Brake drum and pads wet
O
O
Brake pad/lining wear
O
O
Wheel alignment incorrect
O
O
O
O
O
O
Wheel balance incorrect
O
O
Tire pressure incorrect (too low or high)
O
O
O
O
Tire size incorrect
O
6
33
Maintenance
Engine compartment
7-3
Wiper blades
7-35
Maintenance services
7-4
• Blade inspection
7-35
• Owner’s responsibility
7-4
• Blade replacement
7-35
• Owner maintenance precautions
7-4
Battery
7-37
Owner maintenance
7-6
• For best battery service
7-38
• Owner maintenance schedule
7-7
• Battery recharging
7-39
• Reset features
7-40
Scheduled maintenance services
7-8
Tires and wheels
7-41
Explanation of scheduled maintenance items . . . 7-20
• Tire care
7-41
Engine oil
7-24
• Recommended cold tire inflation pressures
7-42
• Checking the engine oil level
7-24
• Check tire inflation pressure
7-43
• Checking the engine oil and filter
7-25
• Tire rotation
7-44
Engine coolant
7-26
• Wheel alignment and tire balance
7-45
• Checking the engine coolant level
7-26
• Tire replacement
7-45
• Changing engine coolant
7-28
• Wheel replacement
7-46
Brake/clutch fluid
7-29
• Tire traction
7-46
• Checking the brake/clutch fluid level
7-29
• Tire maintenance
7-47
Washer fluid
7-30
• Tire sidewall labeling
7-47
• Checking the washer fluid level
7-30
• Tire terminology and definitions
7-51
7
Parking brake
7-30
• All season tires
7-54
• Checking the parking brake
7-30
• Summer tires
7-54
Air cleaner
7-31
• Snow tires
7-54
• Filter replacement
7-31
• Radial-ply tires
7-55
Climate control air cleaner
7-32
• Low aspect ratio tires
7-55
• Filter inspection
7-32
Fuses
7-57
• Instrument panel fuse replacement
7-58
• Memory fuse
7-59
• Engine compartment panel fuse replacement
7-60
• Fuse/relay panel description
7-62
Light bulbs
7-70
• Headlight, parking light, turn signal light,
side marker and front fog light bulb
replacement
7-70
• Side repeater light replacement
7-74
• Rear combination light bulb replacement
7-75
• High mounted stop light replacement
7-78
• License plate light bulb replacement
7-79
• Interior light bulb replacement
7-79
Appearance care
7-81
• Exterior care
7-81
• Interior care
7-86
Emission control system
7-88
• Crankcase emission control system
7-88
7
• Evaporative emission control system including
onboard refueling vapor recovery (ORVR)
7-88
• Exhaust emission control system
7-89
California perchlorate notice
7-92
Maintenance
ENGINE COMPARTMENT
1. Engine oil filler cap
2. Engine oil dipstick
3. Brake/clutch* fluid reservoir
4. Positive battery terminal
5. Negative battery terminal
6. Fuse box
7. Air cleaner
8. Radiator cap
9. Engine coolant reservoir
10. Windshield washer fluid reservoir
* : if equipped
❈ The actual engine room in the vehicle may differ from the illustration.
OMD070047N
7 3
Maintenance
MAINTENANCE SERVICES
You should exercise the utmost care
Owner’s responsibility
Owner maintenance precau-
to prevent damage to your vehicle
tions
Maintenance service and record
and injury to yourself whenever per-
retention are the owner’s responsibil-
Inadequate, incomplete or insuffi-
forming any maintenance or inspec-
ity.
cient servicing may result in opera-
tion procedures.
You should retain documents that
tional problems with your vehicle that
We recommend you have your vehi-
could lead to vehicle damage, an
show proper maintenance has been
cle maintained and repaired by an
performed on your vehicle in accor-
accident, or personal injury. This
authorized HYUNDAI dealer. An
chapter provides instructions only for
dance with the scheduled mainte-
authorized HYUNDAI dealer meets
nance service charts shown on the
the maintenance items that are easy
HYUNDAI’s high service quality
to perform. Several procedures can
following pages. You need this infor-
standards and receives technical
mation to establish your compliance
be done only by an authorized
support from HYUNDAI in order to
HYUNDAI dealer with special tools.
with the servicing and maintenance
provide you with a high level of serv-
requirements of your vehicle war-
Your vehicle should not be modified
ice satisfaction.
ranties. Detailed warranty information
in any way. Such modifications may
is provided in your Service Passport.
adversely affect the performance,
safety or durability of your vehicle
Repairs and adjustments required as
a result of improper maintenance or
and may, in addition, violate condi-
tions of the limited warranties cover-
a lack of required maintenance are
not covered.
ing the vehicle.
7 4
Maintenance
✽ NOTICE
Improper owner maintenance dur-
ing the warranty period may affect
warranty coverage. For details, read
the separate Service Passport pro-
vided with the vehicle. If you're
unsure about any servicing or main-
tenance procedure, have it done by
an authorized HYUNDAI dealer.
7 5
Maintenance
OWNER MAINTENANCE
The following lists are vehicle checks
(Continued)
WARNING
and inspections that should be per-
•
If you must run the engine
formed by the owner or an authorized
Performing maintenance work
during maintenance, do so
HYUNDAI dealer at the frequencies
on a vehicle can be dangerous.
outdoors or in an area with
indicated to help ensure safe,
If you lack sufficient knowledge
plenty of ventilation.
dependable operation of your vehicle.
and experience or the proper
tools and equipment to do the
•
Keep flames, sparks, or smok-
Any adverse conditions should be
work, have it done by an author-
ing materials away from the
brought to the attention of your deal-
ized HYUNDAI dealer. ALWAYS
battery and fuel-related parts.
er as soon as possible.
follow these precautions for
These Owner Maintenance vehicle
performing maintenance work:
checks are generally not covered by
•
Park your vehicle on level
warranties and you may be charged
ground, move the shift lever
for labor, parts and lubricants used.
into the P (Park, for automatic
transaxle vehicle) position or
neutral (for manual transaxle
vehicle, apply the parking
brake, place the ignition
switch in the OFF position.
•
Block the tires
(front and
back) to prevent the vehicle
from moving.
Remove loose clothing or jew-
elry that can become entan-
gled in moving parts.
(Continued)
7 6
Maintenance
Owner maintenance schedule
While operating your vehicle:
At least monthly:
When you stop for fuel:
•
Note any changes in the sound of
•
Check coolant level in the engine
the exhaust or any smell of
coolant reservoir.
• Check the engine oil level.
exhaust fumes in the vehicle.
•
Check the operation of all exterior
• Check coolant level in the engine
•
Check for vibrations in the steering
lights, including the stoplights, turn
coolant reservoir.
wheel. Notice if there is any
signals and hazard warning flash-
• Check the windshield washer fluid
increased steering effort or loose-
ers.
level.
ness in the steering wheel, or
•
Check the inflation pressures of all
• Check for low or under-inflated
change in its straight-ahead posi-
tires including the spare for tires
tires
tion.
that are worn, show uneven wear,
•
Notice if your vehicle constantly
or are damaged.
turns slightly or “pulls” to one side
•
Check for loose wheel lug nuts.
WARNING
when traveling on smooth, level
Be careful when checking your
road.
engine coolant level when the
•
When stopping, listen and check
engine is hot. This may result in
for unusual sounds, pulling to one
coolant being blown out of the
side, increased brake pedal travel
opening and cause serious
or “hard-to-push” brake pedal.
burns and other injuries.
•
If any slipping or changes in the
operation of your transaxle occurs,
check the transaxle fluid level.
•
Check the automatic transaxle P
(Park) function.
•
Check the parking brake.
•
Check for fluid leaks under your
vehicle (water dripping from the air
conditioning system during or after
use is normal).
7 7
Maintenance
SCHEDULED MAINTENANCE
At least twice a year:
At least once a year:
SERVICES
(i.e., every Spring and Fall):
•
Clean body and door drain holes.
Follow
Normal
Maintenance
•
Check radiator, heater and air con-
•
Lubricate door hinges and hood
Schedule if the vehicle is usually
ditioning hoses for leaks or dam-
operated where none of the following
hinges.
age.
conditions apply. If any of the follow-
•
Lubricate door and hood locks and
•
Check windshield washer spray
ing conditions apply, you must follow
latches.
and wiper operation. Clean wiper
the Maintenance Under Severe
•
Lubricate door rubber weather
blades with clean cloth dampened
Usage Conditions.
strips.
with washer fluid.
•
Repeated short distance driving.
•
Check the air conditioning system.
•
Check headlight alignment.
•
Driving in dusty conditions or
•
Inspect and lubricate automatic
•
Check muffler, exhaust pipes,
sandy areas.
transaxle linkage and controls.
shields and clamps.
•
Extensive use of brakes.
•
Clean the battery and terminals.
•
Check the seat belts for wear and
•
Driving in areas where salt or other
•
Check the brake/clutch fluid level.
function.
corrosive materials are used.
•
Driving on rough or muddy roads.
•
Driving in mountainous areas.
•
Extended periods of idling or low
speed operation.
•
Driving for a prolonged period in
cold temperatures and/or extreme-
ly humid climates.
•
More than 50% driving in heavy
city traffic during hot weather
above 32°C (90°F).
For additional information or assis-
tance see your authorized HYUNDAI
dealer.
7 8
Maintenance
NORMAL MAINTENANCE SCHEDULE
The following maintenance services must be performed to ensure good emission control and performance. Keep
receipts for all vehicle emission services to protect your warranty. Where both kilometrage and time are shown, the
12,000 km or 6 months
(Continued)
❑ Inspect suspension mounting bolts
❑ Rotate tire
❑ Inspect battery condition
❑ Inspect cooling system hose and connections
❑ Inspect brake/clutch (if equipped) pedal free play
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect brake lines and connections (including booster)
❑ Inspect all latch, hinges and locks
❑ Inspect cooling system hose and connections
❑ Inspect brake/clutch (if equipped) pedal free play
❑ Replace climate control air filter (for evaporator and blower unit)
❑ Replace engine oil and filter (24,000 km or 24 months)
❑ Replace engine oil and filter (12,000 km or 12 months)
❑ Add fuel additive *3 (12,000 km or 12 months)
❑ Add fuel additive *3 (24,000 km or 24 months)
36,000 km or 18 months
24,000 km or 12 months
❑ Rotate tire
❑ Rotate tire
❑ Inspect battery condition
❑ Inspect battery condition
❑ Inspect air cleaner filter
❑ Inspect air cleaner filter
❑ Inspect vacuum hose
❑ Inspect vacuum hose
❑ Inspect cooling system hose and connections
❑ Inspect air conditioning refrigerant
❑ Inspect brake/clutch (if equipped) pedal free play
❑ Inspect drive shafts and boots
❑ Replace engine oil and filter (36,000 km or 36 months)
❑ Inspect exhaust pipe and muffler
❑ Add fuel additive *3 (36,000 km or 36 months)
❑ Inspect front brake disc/pads, calipers
❑ Inspect rear brake disc/pads (if equipped)
❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
*3 :If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec-
❑ Inspect rear brake drums/linings (if equipped)
ommended. Additives are available from your authorized HYUNDAI dealer
❑ Inspect steering gear box, linkage &
along with information on how to use them. Do not mix other additives.
boots/lower arm ball joint, upper arm ball joint
NOTE : Inspect wheel alignment when abnormal condition noted.
(Continued)
7 9
Maintenance
NORMAL MAINTENANCE SCHEDULE (CONT.)
48,000 km or 24 months
(Continued)
❑ Rotate tire
❑ Replace climate control air filter (for evaporator and blower unit)
❑ Replace air cleaner filter
❑ Inspect battery condition
❑ Inspect vacuum hose
❑ Replace engine oil and filter (48,000 km or 48 months)
❑ Inspect air conditioning refrigerant
❑ Add fuel additive *3 (48,000 km or 48 months)
❑ Inspect drive shafts and boots
60,000 km or 30 months
❑ Inspect exhaust pipe and muffler
❑ Rotate tire
❑ Inspect front brake disc/pads, calipers
❑ Inspect battery condition
❑ Inspect rear brake disc/pads (if equipped)
❑ Inspect air cleaner filter
❑ Inspect rear brake drums/linings (if equipped)
❑ Inspect vacuum hose
❑ Inspect steering gear box, linkage &
❑ Inspect manual transaxle fluid (if equipped)
boots/lower arm ball joint, upper arm ball joint
❑ Inspect cooling system hose and connections
❑ Inspect suspension mounting bolts
❑ Inspect brake/clutch (if equipped) pedal free play
❑ Inspect brake/clutch (if equipped) fluid
❑ Replace engine oil and filter (60,000 km or 60 months)
❑ Inspect fuel filter *1
❑ Add fuel additive *3 (60,000 km or 60 months)
❑ Inspect fuel tank, fuel filler cap, canister, vapor hose, fuel line,
fuel hoses and connections of each part
❈ Inspect : Inspect and if necessary, adjust, correct, clean or replace.
*1 :Fuel filter & Fuel tank air filter are considered to be maintenance free but peri-
❑ Inspect fuel tank air filter (if equipped) *1
odic inspection is recommended for this maintenance schedule depends on
❑ Inspect parking brake
fuel quality. If there are some important safety matters like fuel flow restric-
❑ Inspect cooling system hose and connections
tion, surging, loss of power, hard starting problem, etc. replace the fuel filter
immediately regardless of maintenance schedule and consult an authorized
❑ Inspect brake/clutch (if equipped) pedal free play
HYUNDAI dealer for details.
❑ Inspect brake lines and connections (including booster)
*3 :If TOP TIER Detergent Gasoline is not available, one bottle of additive is rec-
❑ Inspect all latch, hinges and locks
ommended. Additives are available from your authorized HYUNDAI dealer
along with information on how to use them. Do not mix other additives.
(Continued)
NOTE : Inspect wheel alignment when abnormal condition noted.
7 10
