CP-2

CORROSION PROTECTION

ZINC-PHOSPHATE COAT & CATIONIC ELECTRODEPOSITION PRIMER

In order to improve the adhesion of the paint coat on the steel panel, and also to improve the corrosion resistance, the entire
body is coated with a film of Zinc-phosphate and a cationic electrodeposition primer.

BMCCP6020

Cationic electrodeposition primer

Zinc-phosphate film

Body steel panel

CORROSION PROTECTION

CP-3

ANTIVIBRATION PADS-LOCATION & SECTION

BHDCP6104

BHDCP6101

BCMCP6103

BCMCP6102

C

C

D

D

E

E

H

H

B

B

F

F

G

G

A

A

Dash panel

Center floor

Dash panel

A - A

B - B

C - C

43mm

A

B

C

CP-4

CORROSION PROTECTION

BHDCP6209

BHDCP6206

BHDCP6205

BHDCP6208

BHDCP6207

H - H

D - D

E - E

F - F

G - G

Center floor

Center floor panel

Center floor side member

Front seat mounting member

Rear floor

side member

Rear floor front panel

13 mm

33 mm

Rear floor

side member

Rear floor rear panel

D

E

F

G

H

CORROSION PROTECTION

CP-5

BHDCP6202

BHDCP6201

K - K

5 mm

Fender panel

K

K

K
