10

BODY
CONSTRUCTION

11

BODY CONSTRUCTION - Body components

BODY COMPONENTS

Body construction will sometimes differ depending on specifications and country of destination. Therefore, please keep
in mind that the information contained herein is based on vehicles for general destination.

AAAC0050

28

27

26

25

23

29

21

35

24

58

59

62

1

60

41

42

32

36

15

22

33

31

30

52

19

51

14

4

5

17

6

34

2

7

8

18

9

10

11

12

16

54

56

55

57

13

20

46

3

38

43

63

65

64

45

47

44

50

37

40

39

48

49

66

67

53

61

12

BODY CONSTRUCTION - Body components

No.

PART NAME

Front end crossmember.

Front sidemember.

Rear side member.

Crossmember No.1.

Crossmember No.2.

Crossmember No.3.

Crossmember No.4.

Crossmember No.5.

Crossmember No.6.

Crossmember No.7.

Crossmember No.8.

Crossmember No.9-1.

Rear end crossmember.

Radiator support panel.

Center floor panel.

Rear floor panel.

Front step panel.

Rear step panel.

Rear wheel house panel.

Quarter inner lower panel.

Dash panel.

Cowl panel.

Front apron inner panel.

Front wheel house panel.

Front apron outer panel.

Front pillar panel.

Quarter outer panel (LH).

Roof side outer panel (LH).

Fuel filler neck bracket.

Quarter outer rear extension.

Gusset panel (LH).

Quarter inner panel (LH).

Quarter inner upper panel (LH).

"D" inner pillar (LH).

Quarter inner lower panel (LH).

Wheel house outer rear panel (LH).

Quarter outer panel (RH).

Roof side outer panel (RH).

Quarter outer rear extension (RH).

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

No.

PART NAME

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

Gusset panel (RH).

"B" outer pillar (RH).

Rear door side outer rail.

"C" pillar lower reinforcement (RH).

Quarter inner panel (RH).

Roof side inner reinforcement (RH).

"B" inner pillar (RH).

"C" inner pillar (RH).

"D" inner pillar (RH).

"D" pillar upper reinforcement.

Wheel house outer rear panel (RH).

Roof panel.

Roof front rail.

Roof rear rail.

Roof bow (A).

Roof bow (B).

Roof bow (C).

Roof bow (D).

Hood outer panel.

Hood inner panel.

Rear door outer panel.

Rear door inner panel.

Front door hinge face reinforcement.

Front door outer panel.

Front door inner panel.

Front door reinforcement beam.

Tail gate outer panel.

Tail gate inner panel.

13

BODY CONSTRUCTION - Front body

FRONT BODY RADIATOR SUPPORT COMPLETE

CRAR 1100

2

3

1

6

4

9

5

8

7

10

No.

PART NAME

Radiator support upper member center.

Radiator support upper member (LH).

Radiator upper mounting reinforcement.

Radiator support center member.

Head lamp support reinforcement.

Head lamp support panel.

Head lamp support cover (A) extension.

Head lamp support lower (B) extension.

Head lamp support upper reinforcement.

Radiator lower mounting reinforcement.

1

2

3

4

5

6

7

8

9

10
