Fig. 59: Installing J 45755-2, J 45755-1, Forcing Screw, Bearing & Washers Over Differential 2. Install the J 45755-2 (2), J 45755-1 (3), and the forcing screw, bearing and washers (1) over the differential carrier assembly bushing as shown. 3. Press the bushing into the differential carrier assembly bushing bore using the J 45755 . See Special Tools and Equipment . 4. Install the differential carrier assembly. Once the differential carrier assembly is installed, remove the piece of tape in order to connect the vent hose. Refer to Differential Carrier Assembly Replacement . DIFFERENTIAL CARRIER ASSEMBLY BUSHING REPLACEMENT (INNER AXLE SHAFT
2004 Hummer H2 2004 DRIVELINE/AXLE Front Drive Axle - Hummer H2
|
