Hummer H2. Manual - part 1214

Cigar Lighter Terminal Identification

Splice Pack Terminal Identification SP410 (Indexing May Vary)

C

BK

1450

Ground

Connector Part Information

z

12176445

z

3-Way F Metri-Pack 280 Series Flexlock (WH)

Pin

Wire Color

Circuit No.

Function

A

OG

640

Battery Positive Voltage

B

-

-

Not Used

C

BK

1050

Ground

Connector Part Information

z

12176491

z

6-Way F Metri-Pack 280 Splice Saver (BK)

Pin

Wire Color

Circuit No.

Function



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



Trailer Terminal Identification Connector

INLINE HARNESS CONNECTOR END VIEWS

C100 Terminal Identification I/P Harness to Engine Harness

A

-

-

Not Used

B

BK

1450

Ground

C

BK

1450

Ground

D

BK

1450

Ground

E

-

-

Not Used

F

BK

1450

Ground

Connector Part Information

z

15354653

z

7-Way F Metri-Pack 280 Sealed (BK)

Pin

Wire Color

Circuit No.

Function

A

L-GN

1624

Trailer Backup Lamps Supply Voltage

B

BK

1750

Ground

C

D-BU

47

Trailer Auxiliary Supply Voltage

D

D-GN

1619

Trailer Right Rear Turn/Stop Lamp Supply Voltage

E

RD

742

Battery Positive Voltage

F

BN

2109

Trailer Park Lamps Supply Voltage

G

YE

1618

Trailer Left Rear Turn/Stop Lamp Supply Voltage



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C101 Terminal Identification I/P Harness to Chassis Harness

Connector

Part

Information

z

15326084

z

16-Way F GT 150 280 Sealed
4.0 5.8 (BK)

Connector

Part

Information

z

15326085

z

16-Way M GT 150 280 Sealed
4.0 5.8 (BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

-

-

Not Used

A

-

-

Not Used

B

GY/BK

87

Cruise Control
Resume/Accel Switch Signal

B

GY/BK

87

Cruise Control
Resume/Accel Switch Signal

C

D-BU

84

Cruise Control Set/Coast
Switch Signal

C

D-BU

84

Cruise Control Set/Coast
Switch Signal

D

D-

GN/WH

817

Vehicle Speed Signal

D

D-

GN/WH

817

Vehicle Speed Signal

E

GY

397

Cruise Control On Switch
Signal

E

GY

397

Cruise Control On Switch
Signal

F

-

-

Not Used

F

-

-

Not Used

G

BN/WH

419

MIL Control

G

BN/WH

419

MIL Control

H

GY/BK

1694

4WD Low Signal

H

GY/BK

1694

4WD Low Signal

J

-

-

Not Used

J

-

-

Not Used

K

WH

121

Engine Speed Signal

K

WH

121

Engine Speed Signal

L-

N

-

-

Not Used

L-

N

-

-

Not Used

P

D-BU

204

Battery Positive Voltage

P

D-BU

204

Battery Positive Voltage

R

YE

710

Class 2 Serial Data

R

YE

710

Class 2 Serial Data

S

D-GN

1049

PCM Class 2 Serial Data

S

D-GN

1049

PCM Class 2 Serial Data



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2



C102 Terminal Identification Chassis Harness to I/P Harness

Connector

Part

Information

z

15326660

z

10-Way F GT 280 Sealed 5.8
(BK)

Connector

Part

Information

z

15326661

z

10-Way M GT 280 Sealed 5.8
(BK)

Pin

Wire

Color

Circuit

No.

Function

Pin

Wire

Color

Circuit

No.

Function

A

D-GN

2087

Longitudinal Accelerometer 5-
Volt Reference

A

D-GN

2087

Longitudinal Accelerometer 5
Volt Reference

B

OG

2340

Battery Positive Voltage

B

OG

2340

Battery Positive Voltage

C

L-BU

1122

ABS/TCS Class 2 Serial Data

C

L-BU

1122

ABS/TCS Class 2 Serial Data

D

-

-

Not Used

D

-

-

Not Used

E

OG

2554

Traction Control Preference
Switch Indicator

E

OG

2554

Traction Control Preference
Switch Indicator

F

L-BU

2088

Longitudinal Accelerometer
Low Reference

F

L-BU

2088

Longitudinal Accelerometer
Low Reference

G

D-BU

716

Longitudinal Accelerometer
Rate Sensor Signal

G

D-BU

716

Longitudinal Accelerometer
Rate Sensor Signal

H

BK

1550

Ground

H

BK

1550

Ground

J

L-BU

2206

Traction Control Preference
Switch Signal

J

L-BU

2206

Traction Control Preference
Switch Signal

K

-

-

Not Used

K

-

-

Not Used



2004 Hummer H2

2004 ACCESSORIES & EQUIPMENT Wiring Systems (Connector End Views) - Hummer H2
