Hummer H1 (2006+). Manual - part 394





12-252

Electrical System

______________________________________________________

C76/ 72 WAY ECM J2 (BLACK) LOCATION: DRIVERSIDE COWL TOP UNDER ECM

PIN

CKT

COLOR

DESCRIPTION

1

2

507

OR/BK

Fuel rail pressure signal

3

--

--

--

4

--

--

--

5

232

BR

CAN shield

6

--

--

--

7

784

DB

T-case range switch input to the ECM (-)

8

107

BK

EGR stepper motor

9

--

--

--

10

--

--

--

11

--

--

--

12

--

--

--

13

--

--

--

14

624

GY

Coolant temperature sensor

15

--

--

--

16

--

--

--

17

--

--

--

18

--

--

--

19

718

DB

APP sensor 1 signal

20

--

--

--

21

661

GN

Transmission control module MIL request

22

--

--

--

23

615

LG

MAP sensor signal

24

724

DG

APP sensor 3 signal

25

619

TN/WH

Oil pressure sensor signal

_____________________________________________________

 Electrical System  12-253

26

27

324

YL

Fuel temperature sensor signal

28

257

LG

Crank shaft sensor signal

29

251

BK

MAF sensor ground

30

616

OR/BK

MAP

31

368

WH

VNT valve position

32

--

--

--

33

108

OR/BK

EGR valve high control

34

244

BK

Ground

35

109

LG/BK

EGR valve low control

36

244

BK

Ground

37

--

--

--

38

--

--

--

39

618

BK

Engine oil pressure

40

719

BR

APP 1

41

--

--

--

42

509

YL

Fuel pressure regulator sensor signal

43

--

--

--

44

369

BR

VNT position sensor

45

46

613

GY/BK

Baro sensor signal

47

--

--

--

48

--

--

--

49

362

DB

Turbocharger vane position control solenoid valve high

50

363

WH

Turbocharger vane position control solenoid valve low

51

--

--

--

52

632

PK/BK

Injector 3 request

53

110

OR/BK

EGR valve, high control

54

722

PP

APP 2

55

111

LG/BK

EGR valve, low control

56

725

GY

APP 3

PIN

CKT

COLOR

DESCRIPTION

12-254

Electrical System

______________________________________________________

C77/ 56 WAY ECM (GRAY) LOCATION: DRIVERSIDE COWL TOP UNDER ECM

PIN

CKT

COLOR

DESCRIPTION

1

--

--

--

2

--

--

--

3

--

--

--

4

--

--

--

5

--

--

--

6

--

--

--

7

--

--

--

8

243

PK

+12v Ignition input

9

--

--

--

10

514

PK

Ignition 1 Voltage

11

--

--

--

12

497

YL

Vehicle speed sensor high

13

--

--

--

14

514

PK

Ignition 1 Voltage

15

--

--

--

16

--

--

--

17

--

--

--

18

331

WH

Crank request

19

152

DB

Cruise control SET/COAST switch signal

20

439

YL

A\C request

21

--

--

--

22

153

LG

Cruise RESUME\ACCELERATE

23

498

DG

Vehicle speed sensor low

24

653

YL

Intake air temperature signal

25

--

--

--

26

--

--

--

_____________________________________________________

 Electrical System  12-255

27

--

--

--

28

714

DB

Check throttle lamp activation

29

30

151

GY

Cruise control “ON” switch signal

31

330

PP

PRNDL switch

32

--

--

--

33

--

--

--

34

--

--

--

35

332

BK

Starter relay

36

--

--

--

37

644

YL

Tach signal

38

--

--

--

39

--

--

--

40

658

BR

Malfunction indicator lamp

41

410

LG

A\C clutch relay

42

43

258

YL/BK

Crank sensor

44

244

BK

Ground

45

140

OR

Transmission reverse switch

46

--

--

--

47

--

--

--

48

252

BR

Fuel temperature sensor

49

--

--

--

50

--

--

--

51

253

BR/WH

Cam sensor signal

52

266

DB/WH

Crank sensor signal

53

--

--

--

54

--

--

--

55

--

--

--

56

--

--

--

PIN

CKT

COLOR

DESCRIPTION
