WG9716240008 [Operator] |
Operator |
- |
|
WG9719240028 [Operator] |
Operator |
- |
|
WG9725240009 [Gear shift lever] |
Gear shift lever |
- |
|
WG9725240009 [Gear shift lever] |
Gear shift lever |
1 |
|
AZ9100240060 [Gear shift knob] |
Gear shift knob |
1 |
|
AZ9100240061 [Gear shift knob] |
Gear shift knob |
1 |
|
AZ9123240211 [Gear shift knob] |
Gear shift knob |
1 |
|
AZ9123240214 [Gear shift knob] |
Gear shift knob |
1 |
|
AZ9716240001 [Gear shift knob] |
Gear shift knob |
2 |
|
179200240075 [Cable sleeve] |
Cable sleeve |
3 |
|
AZ9719240002 [Siphon] |
Siphon |
4 |
|
190003989318 [Circlip] |
Circlip |
5 |
|
Q218B0825 [Screw] |
Screw |
6 |
|
Q40308 [Spring washer] |
Spring washer |
7 |
|
Q150B0850 [Screw] |
Screw |
8 |
|
Q150B0835 [Screw] |
Screw |
9 |
|
Q40308 [Spring washer] |
Spring washer |
10 |
|
AZ9719240032 [Connecting block] |
Connecting block |
11 |
|
WG9716240010 [Operator assembly] |
Operator assembly |
11 |
|
WG9719240031 [Operator assembly] |
Operator assembly |
12 |
|
WG9716240011 [Positioning cable] |
Positioning cable |
12 |
|
WG9719240007 [Positioning cable] |
Positioning cable |
12 |
|
WG9719240111 [Positioning cable] |
Positioning cable |
13 |
|
WG9716240013 [Gear shift cable] |
Gear shift cable |
13 |
|
WG9719240112 [Gear shift cable] |
Gear shift cable |
13 |
|
WG9725240008 [Gear shift cable] |
Gear shift cable |
14 |
|
1397 350169 [Angle] |
Angle |
15 |
|
Q150B0840 [Screw] |
Screw |
16 |
|
Q40308 [Spring washer] |
Spring washer |
17 |
|
Q340B08 [Nut] |
Nut |
18 |
|
1188 730187 [Clamp] |
Clamp |
19 |
|
AZ9719240017 [Sleeve] |
Sleeve |
20 |
|
WG9719240008 [Clamp] |
Clamp |
21 |
|
Q150B0835 [Screw] |
Screw |
22 |
|
Q40108 [Washer] |
Washer |
23 |
|
AZ9717240027 [Bracket for gear shift cable] |
Bracket for gear shift cable |
23 |
|
AZ9719240026 [Bracket for gear shift cable] |
Bracket for gear shift cable |
23 |
|
AZ9725240024 [Bracket for gear shift cable] |
Bracket for gear shift cable |
24 |
|
AZ9719240025 [Bracket for positioning cable] |
Bracket for positioning cable |
24 |
|
AZ9719240029 [Bracket for positioning cable] |
Bracket for positioning cable |
25 |
|
AZ9719240023 [Positioning lever] |
Positioning lever |
26 |
|
WG9719240117 [Support bar] |
Support bar |
27 |
|
WG9719240116 [Positioning bar] |
Positioning bar |
28 |
|
WG9719240118 [Gear shift bar] |
Gear shift bar |
29 |
|
AZ9725240026 [Protect sleeve for cable] |
Protect sleeve for cable |
