Honda Civic (2024 year). Manual in english - page 3





103

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models without drive mode switch
*2:Models with drive mode switch

Indicator

Name

On/Blinking

Explanation

ECON

 Mode

Indicator

*

Comes on when the ECON mode is on.

Comes on when you set the drive mode to

ECON

.

2

ECON Button

*

 P. 467

2

Drive Mode System

*

 P. 479

NORMAL

 Mode

Indicator

*

Comes on when you set the drive mode to

NORMAL

.

2

Drive Mode System

*

 P. 479, 483

SPORT

 Mode

Indicator

*

Comes on when you set the drive mode to

SPORT

.

The ambient meter remains light up in red as long
as

SPORT

 mode is selected.

The ambient meter

*

 goes off and gauges in the

instrument panel lit up in red as long as

SPORT



mode is selected.

2

Drive Mode System

*

 P. 479, 483

INDIVIDUAL



Mode Indicator

*

Comes on when you set the drive mode to

INDIVIDUAL

.

2

Drive Mode System

*

 P. 483

Low Temperature
Indicator

*

Comes on when the engine coolant
temperature is low.

If the indicator stays on after the engine has
reached normal operating temperature, there may
be a problem with the temperature sensors. Have
your vehicle inspected by a dealer.

*1

*2

Models without drive mode switch

Models with drive mode switch

Models with A-type meter

Models with B-type meter

* Not available on all models

104

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Immobilizer System
Indicator

Blinks if the immobilizer system cannot
recognize the key information.

Blinks

 - You cannot start the engine. Set the

power mode to VEHICLE OFF, then select the ON
mode again.

Depress and hold the brake pedal before setting
the power mode to ON.

Repeatedly blinks

- The system may be

malfunctioning. Have your vehicle checked by a
dealer.

Do not attempt to alter this system or add other
devices to it. Electrical problems can occur.

Security System
Alarm Indicator

Blinks when the security system alarm has
been set.

2

Security System Alarm

 P. 190

Indicator

Models with
A-type meter

Indicator

Models with
B-type meter

Canadian models

Indicator

Models with
A-type meter

Indicator

Models with
B-type meter

105

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop

OFF



Indicator

Comes on when the Auto Idle Stop system
has been turned off by the Auto Idle Stop

OFF

 button.

2

Auto Idle Stop System ON/OFF

 P. 469, 475

Auto Idle Stop
System Indicator
(Amber)

Blinks if there is a problem with the Auto
Idle Stop system.

Blinks

- Have your vehicle checked by a dealer.

Auto Idle Stop
Indicator (Green)

Comes on when Auto Idle Stop is in
operation. The engine automatically shuts
off.

2

Auto Idle Stop

 P. 468, 474

106

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Auto Idle Stop
Suspend Indicator

Comes on while Auto Idle Stop is
temporarily suspended in the following
situations.

-

Brake pedal is not fully pressed

Depress the brake pedal firmly.

-

The transmission is in a position other than

(

D

2

Auto Idle Stop

 P. 468, 474

-

System charging is prioritized

-

Climate control system is prioritized

-

Engine coolant temperature is not in
operating range

-

SPORT

 mode

*

 is selected.

2

Auto Idle Stop

 P. 468, 474

2

Drive Mode System

*

 P. 479, 483

-

The battery temperature is too low.

-

Auto Idle Stop does not activate for some
reason.

If you press and hold the Auto Idle Stop

OFF



button, you can select whether to display the status
messages or not.

Continuously variable transmission models

Continuously variable transmission models

* Not available on all models

107

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Adaptive Cruise
Control (ACC) with
Low Speed Follow

*



Indicator (Amber)

Comes on if there is a problem with ACC
with Low Speed Follow

*

.

Comes on while driving

- Have your vehicle

checked by a dealer.

Comes on if the ACC with Low Speed
Follow

*

 is deactivated temporarily after the

battery has been disconnected, then re-
connected.

Drive a short distance at more than 12 mph (20 km/h).
The indicator should go off. If it does not, have your
vehicle checked by a dealer.

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

ACC with Low Speed Follow

*

 has been

automatically canceled.

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 445

Stays on constantly

- Have your vehicle checked

by a dealer.

Adaptive Cruise
Control (ACC) with
Low Speed Follow

*



Indicator
(White/Green)

Lights up in white when you press the



button.

Lights up in green when you press the

RES/

+

/

SET/−

 switch up or down.

2

Adaptive Cruise Control (ACC) with Low
Speed Follow

*

 P. 536

2

Adaptive Cruise Control (ACC)

*

 P. 557

* Not available on all models

108

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

Comes on if there is a problem with the
LKAS.

Stays on constantly

- Have your vehicle checked

by a dealer.

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 445

Stays on constantly

 - Have your vehicle checked

by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(White/Green)

Lights up in white when you press the LKAS
button.

Lights up in green when the LKAS is in
operation.

2

Lane Keeping Assist System (LKAS)

 P. 576

Cruise Mode
Indicator
(White/Green)

Lights up in white when you change to
cruise mode.

Lights up in green when you have set a
speed for cruise control.

2

To Switch ACC with Low Speed Follow to
Cruise Control

 P. 554

2

To Switch ACC to Cruise Control

 P. 573

Adaptive Cruise
Control (ACC) with
Low Speed Follow

*



Interval Indicator

*

Comes on when Adaptive Cruise Control
(ACC) with Low Speed Follow

*

 indicator

comes on.

Each time you press the Interval button, the
following interval (the interval behind a vehicle
detected ahead of you) setting cycles through extra
long, long, middle, and short following intervals.

2

To Set or Change Following-interval

 P. 550,

569

* Not available on all models

109

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

Comes on if there is a problem with Road
Departure Mitigation system, CMBS

TM

, Low

Speed Braking Control

*

 or blind spot

information system

*

.

Stays on constantly

 - Have your vehicle checked

by a dealer.

Indicator may come on temporarily when
the Maximum Load Limit is exceeded.

Make sure the total load is within the Maximum
Load Limit.

2

Maximum Load Limit

 P. 445

Stays on constantly

 - Have your vehicle checked

by a dealer.

Comes on if the Road Departure Mitigation
system, CMBS

TM

 and Low Speed Braking

Control

*

 are deactivated temporarily after

the battery has been disconnected and
then re-connected.

Drive a short distance at more than 12 mph (20
km/h). The indicator should go off. If it does not,
have your vehicle checked by a dealer.

* Not available on all models

110

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

Comes on when the Road Departure
Mitigation system and/or CMBS

TM

 shuts

itself off.

Stays on

 - The temperature inside the camera is

too high.
Use the climate control system to cool down the
camera.
The system activates when the temperature inside
the camera cools down.

2

Front Wide View Camera

 P. 603

Stays on

 - The area around the camera is blocked

by dirt, mud, etc. Stop your vehicle in a safe place
and wipe the debris off with a soft cloth.

Have your vehicle checked by a dealer if the
indicator and message are still displayed even after
you have cleaned the area around the camera.

2

Front Wide View Camera

 P. 603

It may come on when the ambient conditions are
dark, such as when driving in a tunnel, or at night,
dawn, or dusk.

111

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Safety Support
Indicator (Amber)

Comes on when mud, snow, or ice
accumulates in the vicinity of the sonar
sensor.

Remove the obstacle in the vicinity of the sonar
sensor.

2

Low Speed Braking Control

*

 P. 517, 523

Comes on when mud, snow, or ice
accumulates in the vicinity of the blind spot
information system sensor.

Comes on when the temperature of the
blind spot information system sensor is
high.

Comes on while driving

 - Something may be

interfering with the blind spot information system
sensor. Check the vicinity of the blind spot
information system sensor and remove any
obstacles.

The system will return to normal when the
temperature cools down.

2

Blind Spot Information System

*

 P. 498

Safety Support
Indicator (Green/
Gray)

Lights up in green when Road Departure
Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

 and blind spot

information system

*

 are on.

Lights up in green and gray when Road
Departure Mitigation system, CMBS

TM

, Low

Speed Braking Control

*

, blind spot

information system

*

 or any two or three of

these systems are off.

Lights up in gray when Road Departure
Mitigation system, CMBS

TM

, Low Speed

Braking Control

*

 and blind spot

information system

*

 are off.

2

Road Departure Mitigation system On and Off



P. 531

2

CMBS

TM

 On and Off

 P. 509

2

Blind Spot Information System On and Off



P. 500

2

System On and Off

 P. 520, 525

Models with Low Speed Braking Control

Models with blind spot information system

* Not available on all models

112

In

strum

e

nt Pa

nel

Gauges and Driver Information Interface

Gauges

Gauges include the speedometer, fuel gauge, and other related indicators.
They are displayed when the power mode is in ON.

Displays your driving speed in mph or km/h.

Speedometer

1

Speedometer

You can set the speedometer and the displayed
measurements to read in either km/h or mph.

2

Speed/Distance Units

 P. 135, 166

2

Settings

*

 P. 136

2

Customized Features

 P. 380

If you change the unit from miles and mph to km and
km/h, the current vehicle speed in mph appears next
to the digital speedometer.

U.S. models with B-type meter

Vehicle Speed in mph

* Not available on all models

Continued

113

uu

Gauges and Driver Information Interface

u

Gauges

In

strum

e

nt Pa

nel

Shows the number of engine revolutions per minute.

Displays the amount of fuel left in the fuel tank.

Tachometer

Fuel Gauge

1

Tachometer

The tachometer can be turned on and off using the
driver information interface or audio/information
screen.

2

Settings

*

 P. 136

2

Customized Features

 P. 380

Even if you have turned off the tachometer on the
driver information interface or audio/information
screen, if

No content

 is selected on the driver

information interface, it will change to a tachometer-
only display.

The shift up alarm sounds when the tachometer
reading approaches the red zone.
You can turn the shift up alarm feature on and off.

2

Customized Features

 P. 380

Models with A-type meter

Manual transmission models with B-type meter

1

Fuel Gauge

NOTICE

You should refuel when the reading approaches

.

Running out of fuel can cause the engine to misfire,
damaging the catalytic converter.

The actual amount of remaining fuel may differ from
the fuel gauge reading.

E

* Not available on all models

uu

Gauges and Driver Information Interface

u

Gauges

114

In

strum

e

nt Pa

nel

Displays the temperature of the engine coolant.

Shows the total number of miles or kilometers that your vehicle has accumulated.

Shows the outside temperature in Fahrenheit (U.S.) or Celsius (Canada).

Adjusting the outside temperature display

Adjust the temperature reading by up to ±5°F or ±3°C if the temperature reading
seems incorrect.

Temperature Gauge

Odometer

Outside Temperature

Models with B-type meter

1

Temperature Gauge

NOTICE

Driving with the temperature gauge reading in the
upper zone can cause serious engine damage. Pull
safely to the side of the road and allow engine
temperature to return to normal.

2

Overheating

 P. 726

1

Outside Temperature

The temperature sensor is in the front bumper.
Road heat and exhaust from another vehicle can
affect the temperature reading when your vehicle
speed is less than 19 mph (30 km/h).

It may take several minutes for the display to be
updated after the temperature reading has stabilized.

You can adjust the temperature reading.

2

Settings

*

 P. 136

2

Customized Features

 P. 380

* Not available on all models

115

uu

Gauges and Driver Information Interface

u

Gauges

Continued

In

strum

e

nt Pa

nel

Shows certain detected traffic signs while driving.
The indicator blinks when the maximum speed of the traffic sign detected by the
Traffic Sign Recognition System is exceeded.

2

Traffic Sign Recognition System

 P. 597

Traffic Sign Recognition System

Models with A-type meter

Models with B-type meter

uu

Gauges and Driver Information Interface

u

Gauges

116

In

strum

e

nt Pa

nel

Shows the current mode for ACC with Low Speed Follow

*

, LKAS, and Traffic Jam

Assist

*

.

2

Adaptive Cruise Control (ACC) with Low Speed Follow

*

 P. 536

2

Adaptive Cruise Control (ACC)

*

 P. 557

2

Lane Keeping Assist System (LKAS)

 P. 576

2

Traffic Jam Assist

*

 P. 588

Shows the clock.
You can adjust the time manually and change the clock display to show the 12 hour
clock or 24 hour clock.

2

Clock

 P. 170

Light up from outside to center according to engine speed.

Current Mode for ACC with Low Speed Follow

*

, the LKAS, and

Traffic Jam Assist

*

Clock

Rev Indicators

*

1

Current Mode for ACC with Low Speed Follow

*

, the LKAS, and

Traffic Jam Assist

*

When you set speed for ACC with Low Speed Follow

*



or cruise control, a set speed mark will be displayed
on the speedometer.

Models with B-type meter

Set
Speed

Models with A-type meter

1

Rev Indicators

*

You can turn the rev indicators on and off.

2

Customized Features

 P. 380

* Not available on all models

117

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

Continued

In

strum

e

nt Pa

nel

Driver Information Interface (A-type Meter)

The driver information interface shows information such as the estimated travelable
distance and fuel economy of the vehicle. It also displays messages such as warnings
and other helpful information.
When a warning message displays, please check the message and contact a dealer
to have the vehicle inspected if necessary. Please refer to the pages below if the

Engine oil pressure low

 or

Engine temperature too hot

 message is displayed.

2

If the Engine oil pressure low Warning Appears

 P. 728

2

Overheating

 P. 726

Accessing contents in the display

Press the

 (home) button, then roll the left selector wheel to scroll to the content

you want to see. Press the left selector wheel to see detailed information.

Switching the Display

1

Switching the Display

You can add or delete the meter contents.

2

Customize Display

 P. 134

118

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Continuously variable transmission models

Customize
display

 P. 134

Left Selector
Wheel

 (home) Button

Roll the left
selector wheel.

No content

 P. 135

Speed & time

 P. 122

Warnings

 P. 135

Range & fuel

 P. 120

Settings

 P. 136

Driver
attention

 P. 125

Seat belts

 P. 132

Safety
Support

 P. 132

Maintenance

 P. 132

119

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

Continued

In

strum

e

nt Pa

nel

Manual transmission models

Customize
display

 P. 134

Left Selector
Wheel

 (home) Button

Roll the left
selector wheel.

No content

 P. 135

Speed & time

 P. 122

Warnings

 P. 135

Range & fuel

 P. 120

Driver
attention

 P. 125

Seat belts

 P. 132

Safety
Support

 P. 132

Maintenance

 P. 132

Phone

 P. 123

Audio

 P. 123

Navigation

 P. 124

Turbo gauge

 P. 124

Throttle &
brake

 P. 128

G-Meter

 P. 129

Stopwatch

 P. 130

120

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Roll the left selector wheel to switch between trip meter A and trip meter B.

Range / Fuel / Trip Meter

Average Fuel Economy

Range

Trip Meter B

Instant Fuel Economy

Trip Meter A

Continued

121

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Trip meter

Shows the total number of miles or kilometers driven since the last reset. Meters A
and B can be used to measure two separate trips.

Resetting a trip meter

To reset the trip meter, display it, press the left selector wheel, and then select

Reset

u

The trip meter is reset to 0.0.

Average Fuel Economy

Shows the estimated average fuel economy of each trip meter in mpg or l/100 km.
The display is updated at set intervals. When a trip meter is reset, the average fuel
economy is also reset.

Instant Fuel Economy

Shows the instant fuel economy as a bar graph in mpg or l/100 km.

Range

Shows the estimated distance you can travel on the remaining fuel. This estimated
distance is based on the vehicle’s current fuel economy.

1

Average Fuel Economy

You can change when to reset the average fuel
economy.

2

Settings

*

 P. 136

2

Customized Features

 P. 380

1

Range

The driving range displayed is only an estimate and
may differ from the actual distance the vehicle can
travel.

* Not available on all models

122

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Roll the left selector wheel to switch between trip meter A and trip meter B.

Speed / Time / Trip Meter

Trip Meter B

Average Speed

Trip Meter A

Elapsed Time

Continued

123

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Trip meter

2

Trip meter

 P. 121

Elapsed time

Shows the time elapsed since Trip A or Trip B was reset.

Average speed

Shows the average speed in mph or km/h since Trip A or Trip B was reset.

Shows the current audio information.

2

Audio System Basic Operation

 P. 282

Shows the current phone information.

2

Bluetooth

®

 HandsFreeLink

®

 P. 420

Audio

*

Phone

*

1

Elapsed time

You can change when to reset the elapsed time.

2

Settings

*

 P. 136

2

Customized Features

 P. 380

1

Average speed

You can change when to reset the average speed.

2

Settings

*

 P. 136

2

Customized Features

 P. 380

* Not available on all models

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

124

In

strum

e

nt Pa

nel

When the turbo is producing boost, this gauge indicates a rise in boost pressure.

Compass

Shows the compass screen.

Turn-by-Turn Directions

When driving guidance is provided by the Android Auto or Apple CarPlay, turn-by-
turn directions to your destination appear.

2

Android Auto

TM

 P. 346

2

Apple CarPlay

 P. 339

Turbo Gauge

*

Navigation

*

1

Navigation

*

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

2

Customized Features

 P. 380

Turn-by-turn directions may not be available for all
apps.

* Not available on all models

Continued

125

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is
being driven in a manner consistent with drowsy or inattentive driving. If it
determines that the vehicle is being driven in such a manner, it will display the
degree of the driver’s attention on the driver information interface.

When you select

Driver attention

 on the

driver information interface, bars on it light up
in white to indicate the degree of the driver’s
attention.

2

Accessing contents in the display

 P. 117

Driver Attention Monitor

1

Driver Attention Monitor

The Driver Attention Monitor cannot always detect if
the driver is tired or inattentive.
Regardless of the system’s feedback, if you are
feeling tired, stop in a safe location and rest for as
long as needed.

Driver Information
Interface

Left Selector
Wheel

 (home) Button

Level

126

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

If two bars light up, the

Driver attention

level low

 message will appear.

If one bar lights up, the

Driver attention

level low. Time for a break.

 message will

appear, a beep will sound, and the steering
wheel will vibrate.
If this message appears, stop in a safe location
and rest for as long as needed.
The message will disappear when the left
selector wheel is pressed or when the system
has determined that the driver is driving
normally.
If the driver does not take a break and the
monitor continues to detect that the driver is
very tired, the message will appear again after
approximately 15 minutes, accompanied by a
beep and steering wheel vibrations.
The message does not appear when the
traveling time is 30 minutes or less.

Continued

127

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

The Driver Attention Monitor resets when:

The engine is turned off.

The driver unfastens the seat belt and opens the door while the vehicle is stopped.

For the Driver Attention Monitor to function:

The vehicle must be traveling above 25 mph (40 km/h).

The electric power steering (EPS) system indicator must be off.

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

The steering assist function of the Lane Keeping Assist System (LKAS) is active.

2

Lane Keeping Assist System (LKAS)

 P. 576

The condition of the road is poor; e.g., the surface is unpaved or bumpy.

It is windy.

The driver is frequently operating the vehicle in an assertive manner, such as
changing lanes or accelerating.

Customizing

You can change the Driver Attention Monitor settings. Select

Tactile and audible

alert

*1

/

Tactile And Audible Alert

*2

Tactile alert

*1

/

Tactile Alert

*2

, or

OFF

.

2

Settings

*

 P. 136

2

Customized Features

 P. 380

*1 : Models with 7-in. Color Touchscreen
*2 : Models with 9-in. Color Touchscreen

1

For the Driver Attention Monitor to function:

The bars on the driver information interface remain
grayed-out unless the Driver Attention Monitor is
functioning.

* Not available on all models

128

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Accelerator Position Meter

Displays the accelerator position in degrees of
%.

Braking Pressure Meter

Displays the brake pressure in psi when the
brake is applied.

Throttle & Brake

*

Accelerator Position Meter

Braking Pressure Meter

* Not available on all models

Continued

129

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

In

strum

e

nt Pa

nel

Displays the strength (G) and direction of the load that is applied to the vehicle
during driving.

G-Meter

*

1

G-Meter

*

The meter does not display a lateral force larger than
1.2 G.

Lateral forces of the
past three seconds
(white)

When steering to
the right

When accelerated while moving forward
When decelerated while reversing

When decelerated while moving forward
When accelerated while reversing

When steering to
the left

Real-time lateral
force (red)

* Not available on all models

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

130

In

strum

e

nt Pa

nel

Measures the lap time, and displays the previously measured times and the fastest
lap time.

Measuring LAP Time

1.

Roll the left selector wheel, then select and
press

Start/Stop

 to display the lap time

measurement screen.

2.

Press the left selector wheel to start
measurement.

3.

Press the left selector wheel to stop
measurement.

u

To measure the time per lap, roll the left
selector wheel at the end of each lap.

u

To return to the stopwatch menu screen,
press and hold the left selector wheel.

Stopwatch

*

1

Stopwatch

*

Be sure to use this measurement function only where
and when it is safe to do so.

Lap time is displayed from 00:00.00 to 9:59:59.99.

A maximum of 20 lap times can be stored at a time.

* Not available on all models

131

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

Continued

In

strum

e

nt Pa

nel

Checking/Clearing history

To check or clear the history, roll the left
selector wheel, then select

History/Reset

 and

press it.

u

To scroll through the lap times, roll the
left selector wheel.

u

To clear the history, press the left selector
wheel on the stopwatch history screen
while the lap time is not being measured,
then select and press

Reset

.

u

To return to the stopwatch menu screen,
press and hold the left selector wheel.

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

132

In

strum

e

nt Pa

nel

Occurs, under specified conditions, when seat belts are latched or unlatched.

2

Seat Belt Reminder

 P. 46

Shows the remaining oil life and Maintenance Minder

TM

.

2

Maintenance Minder

TM

 P. 641

Indicates the status of the Road Departure Mitigation system, CMBS

TM

, and blind

spot information system

*

 such as On, Off, or Failure, by color and letters.

The following colors indicate the status of any of the above-mentioned systems:

Green: The system is on.

Gray: The system is off.

Amber: There is a problem with the system.

Seat Belts

Maintenance

Safety Support

1

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn each system on or off, first rotate the left
selector wheel to switch displays. From the next
display, you can select which system to turn on or off.

2

Road Departure Mitigation system On and
Off

 P. 531

2

Blind Spot Information System On and Off



P. 500

2

CMBS

TM

 On and Off

 P. 509

You can also confirm the status of each function by
the color of the safety support indicator.

2

Safety Support Indicator (Amber)

 P. 109

2

Safety Support Indicator (Green/Gray)



P. 111

* Not available on all models

133

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

Continued

In

strum

e

nt Pa

nel

Area Info for
CMBS

TM

Area Info for
Road
Departure
Mitigation
System

Area Info for
Blind Spot
Information
System

*

Road
Departure
Mitigation
System Icon
and Status
Info

Blind Spot
Information
System Icon
and Status
Info

*

CMBS

TM

 Icon

and Status
Info

* Not available on all models

uu

Gauges and Driver Information Interface

u

Driver Information Interface (A-type Meter)

134

In

strum

e

nt Pa

nel

Change the settings to your liking.

Arrange content

You can choose which icons to display on the home screen.

1.

Roll the left selector wheel to scroll to select

Customize display

, then press the left

selector wheel.

2.

Roll the left selector wheel.

3.

Roll the left selector wheel to scroll
between icons, then press the left selector
wheel to check or uncheck them.

Customize Display

1

Customize Display

Icons that are gray cannot be removed from the
home screen.

When you customize settings, shift to

(

P

.

When you customize settings, set the parking brake.

Continuously variable transmission models

Manual transmission models

















Content      ..     1      2      3      4      ..
