Continued

531

uu

Honda Sensing

®

u

Traffic Jam Assist

Driving

Keep your vehicle near the center of the lane
while driving.

u

The LKAS indicator changes from white
to green, and white lines change to
green once the system starts operating
after detecting the left and right lane
markings.

How Traffic Jam Assist Works

1

How Traffic Jam Assist Works

If your vehicle veers too far to the right or the left of
the white (or yellow) traffic lane lines while Traffic
Jam Assist is active, deactivate Traffic Jam Assist and
have your vehicle inspected by an authorized Honda
dealer.

In some cases the system cannot properly detect the
traffic lane lines and, as a result, will not provide
steering assistance.

2

Traffic Jam Assist: Conditions and
Limitations

 P. 533

If the driver takes their hands off the steering wheel
or does not adequately maintain control of steering,
the warning below will appear.

If the driver does not grip the steering wheel after the
warning above has repeatedly appeared, a warning
buzzer will sound and Traffic Jam Assist will be
canceled.

Models with A-type meter

Green lines

LKAS indicator (green)

Models with B-type meter

LKAS indicator (green)

Green lines

uu

Honda Sensing

®

u

Traffic Jam Assist

532

Driving

Press the LKAS button to cancel Traffic Jam Assist.

Traffic Jam Assist may be automatically suspended when:

The system is automatically temporarily canceled under the following circumstances.

The system fails to detect lane lines.

The steering wheel is turned sharply.

You fail to steer the vehicle.

You are driving through a sharp curve.

The brake pedal is depressed.

Once these conditions no longer exist, Traffic Jam Assist automatically resumes.

Traffic Jam Assist may be automatically canceled when:

The traffic lane lines will disappear from the screen, the beeper may sound, and
Traffic Jam Assist will be canceled under the following circumstances:

The temperature of the camera is too high.

The camera behind the rearview mirror, or the area around the camera, including
the windshield, is dirty.

Canceling Traffic Jam Assist

1

Traffic Jam Assist may be automatically suspended when:

You are traveling over 45mph (72km/h).

u

When the speed of the vehicle reaches 45mph

(72km/h), Traffic Jam Assist is deactivated and LKAS
is activated instead. Once the speed of the vehicle
drops to under 42mph (68km/h), Traffic Jam Assist
is reactivated.

533

uu

Honda Sensing

®

u

Traffic Jam Assist

Continued

Driving

The system may not detect lane markings and therefore may not keep the vehicle in
the middle of the lane under certain conditions, including the following:

Environmental conditions

There is little contrast between lane lines and the roadway surface.

Driving in bad weather (rain, fog, snow, etc.).

Driving on a snowy or wet roadway.

Driving into low sunlight (e.g., at dawn or dusk).

Shadows of adjacent objects (trees, buildings, guard rails, vehicles, etc.) are
parallel to white (or yellow) lines.

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
lane lines or the road surface may not be illuminated).

When the lane lines or road surface are not visible, such as when the distance to
the vehicle in front of you is extremely short or when at an intersection.

Strong light is reflected onto the roadway.

Traffic Jam Assist: Conditions and Limitations

534

uu

Honda Sensing

®

u

Traffic Jam Assist

Driving

Roadway conditions

Driving on a road with temporary lane markings.

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

The roadway has merging, split, or crossing lines, such as at an intersection or
crosswalk.

The lane markings are extremely narrow, wide, or changing.

Part of the lane markings are hidden by an object, such as a vehicle.

The road is hilly or the vehicle is approaching the crest of a hill.

Your vehicle is strongly shaken on uneven road surfaces.

Faded lines

Duplicate lines

Tire tracks

Very wide or narrow traffic lane

535

uu

Honda Sensing

®

u

Traffic Jam Assist

Continued

Driving

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
(or yellow) lines.

Driving on rough or unpaved roads, or over bumpy surfaces.

Driving on roads with double lane lines.

Driving on snowy or slippery roads.

The pavement is only partially visible due to snow or puddles on the road.

There is a film of water or puddles on the road surface.

White (or yellow) lines are not recognized correctly due to road conditions such as
curves, twists, or hills.

Driving on unpaved or rutted roads.

Passing through an exit or an intersection.

Lane void of lines at exit or
intersection

536

uu

Honda Sensing

®

u

Traffic Jam Assist

Driving

Vehicle conditions

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

There is residue on the windshield from the windshield wipers.

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

The vehicle is tilted due to a heavy load in the trunk or rear seats.

The suspension has been modified.

Tire chains are installed.

537

uu

Honda Sensing

®

u

Road Departure Mitigation System

Continued

Driving

Road Departure Mitigation System

Alerts and helps assist you when the system detects a possibility of your vehicle
crossing over detected lane markings, or approaching the outer edge of the
pavement (into grass or gravel border) or a detected oncoming vehicle.

The front camera behind the rearview mirror
monitors left and right lane markings in white
or yellow, the outer edge of the pavement
(bordered by grass or gravel) or a detected
oncoming vehicles.
If your vehicle approaches any detected lane
markings, the outer edge of the pavement
(bordered by grass or gravel) or a detected
oncoming vehicles when the turn signals have
not been engaged, the system activates.

u

If the system cannot detect lane markings
(in white or yellow), no assistance will be
provided to avoid approaching oncoming
vehicles. In addition to a visual alert, the
system assists with steering and alerts you
with rapid steering wheel vibrations to
help you remain within the detected lane.

2

Settings

 P. 126

2

Customized Features

 P. 363

As a visual alert, the

Lane departure



message appears on the driver information
interface.

*1 : Models with A-type meter
*2 : Models with B-type meter

How the System Works

1

Road Departure Mitigation System

Important Safety Reminder

Like all assistance systems, the Road Departure
Mitigation system has limitations.
Over-reliance on the Road Departure Mitigation
system may result in a collision. It is always your
responsibility to keep the vehicle within your driving
lane.

The Road Departure Mitigation system alerts you
when the system detects that you are approaching
the outer edge of the pavement (into grass or gravel
border), an oncoming vehicle, or drifting into another
lane without using a turn signal.
The Road Departure Mitigation system may not detect
all lane markings or every instance of lane drift.
The Road Departure Mitigation system may not
detect that you are approaching the outer edge of
the pavement (bordered by grass or gravel) or an
oncoming vehicle.
The Road Departure Mitigation system may not be
able to assist you depending on weather, speed or
road conditions.

The Road Departure Mitigation system is not activated
for about 15 seconds after the engine starts.

You can read about handling information for the
camera equipped with this system.

2

Front Wide View Camera

 P. 551

The Road Departure Mitigation system may not work
properly or may work improperly under the certain
conditions:

2

Road Departure Mitigation system
Conditions and Limitations

 P. 541

Amber line

*1

*2

uu

Honda Sensing

®

u

Road Departure Mitigation System

538

Driving

The system cancels assisting operations when you turn the steering wheel to avoid
crossing over detected lane markings or approaching the outer edge of the
pavement (into grass or gravel border) or an oncoming vehicle.

If the system operates several times without detecting driver response, the system
beeps to alert you.

1

Road Departure Mitigation System

There are times when you may not notice the Road
Departure Mitigation system functions due to your
operation of the vehicle, or road surface conditions.

If LKAS is off and you have selected

Narrow

 from the

customized options using the driver information
interface

*

 or audio/information screen

*

, the message

below will appear if the system has determined that
there is a possibility of your vehicle crossing over
detected lane markings, the outer edge of the
pavement (into grass or gravel border) or oncoming
vehicle. If you have selected

Normal

 or

Wide

however, the message will only appear if the vehicle
is about to cross over the outer edge of the pavement
or oncoming vehicle.

2

Settings

 P. 126

2

Customized Features

 P. 363

* Not available on all models

Continued

539

uu

Honda Sensing

®

u

Road Departure Mitigation System

Driving

The system activates when all of the following conditions are met:

The vehicle is traveling between about 45 and 90 mph (72 and 145 km/h).

The vehicle is on a straight or slightly curved road.

The turn signals are off.

The system makes a determination that the driver is not actively accelerating,
braking or steering.

How the System Activates

1

How the System Activates

The Road Departure Mitigation system may
automatically shut off and the safety support
indicator (amber) comes and stays on.

2

Indicators

 P. 88

The Road Departure Mitigation system function can
be impacted when the vehicle is:

Driven on the inside edge of a curve, or outside of
a lane.

Driven in a narrow lane.

uu

Honda Sensing

®

u

Road Departure Mitigation System

540

Driving

When you turn the Road Departure Mitigation
system on and off, do the following.

1.

Press the safety support switch.

2.

Roll the left selector wheel to the



symbol and push it.

2.

Roll the right selector wheel to the



symbol and push it.

u

A message appears on the driver
information interface when the system
turns on or off.

u

A check mark appears in the box and the
color of the

 symbol changes to green

when the system is on. The check mark
disappears and the color of the



symbol changes to gray when the system
is off.

The Road Departure Mitigation system is in
the previously selected on (checked) or off
(unchecked) setting each time you start the
engine.

*1 : Models with A-type meter
*2 : Models with B-type meter

Road Departure Mitigation system On and Off

1

Road Departure Mitigation system On and Off

You can also select safety support content from the
driver information interface.

2

Driver Information Interface

 P. 113

2

Driver Information Interface (Right Side
Area)

 P. 138

When you have selected

Warning only

*1

/

Warning

Only

*2

 from the customized options using the driver

information interface

*

 or audio/information screen

*

the system does not operate the steering wheel.

2

Settings

 P. 126

2

Customized Features

 P. 363

The Vehicle Stability Assist

TM

 (VSA

®

) system, Vehicle

Stability Assist

TM

 (VSA

®

OFF

, Adaptive Cruise Control

(ACC) with Low Speed Follow, low tire pressure/
TPMS

*

 and safety support indicators may come on in

amber along with a message in the gauge when you
set the power mode to ON after reconnecting the
battery.
Drive a short distance at more than 12 mph (20 km/h).
Each indicator should go off. If any do not, have your
vehicle checked by a dealer.

Safety Support Switch

Left Selector
Wheel

Models with A-type meter

Models with A-type meter

Models with B-type meter

Right
Selector
Wheel

Safety Support Switch

Models with B-type meter

* Not available on all models

541

uu

Honda Sensing

®

u

Road Departure Mitigation System

Continued

Driving

The system may not properly detect lane markings (in white or yellow), the outer
edge of the pavement (into grass or gravel border) or an oncoming vehicle under
certain conditions. Some examples of these conditions are listed below.

Environmental conditions

There is little contrast between lane lines and the roadway surface.

Driving in bad weather (rain, fog, snow, etc.).

Driving on a snowy or wet roadway.

Driving into low sunlight (e.g., at dawn or dusk).

Shadows of adjacent objects (trees, buildings, guard rails, vehicles, etc.) are
parallel to white (or yellow) lines.

Sudden changes between light and dark, such as the entrance or exit of a tunnel
or the shadows of trees, buildings, etc.

Strong light is reflected onto the roadway.

Driving at night or in a dark place such as a tunnel (due to low-light conditions,
lane lines, the road surface, or oncoming vehicles may not be illuminated).

The distance between your vehicle and the vehicle ahead of you is too short, and
lane lines and the road surface are not visible.

The outer edge of the road is bordered by objects, materials, etc. other than grass
or gravel.

Road Departure Mitigation system Conditions and Limitations

542

uu

Honda Sensing

®

u

Road Departure Mitigation System

Driving

Roadway conditions

Driving on a road with temporary lane markings.

Faint, multiple, or varied lane markings are visible on the roadway due to road
repairs or old lane markings.

The roadway has merging, split, or crossing lines, such as at an intersection or
crosswalk.

The lane markings are extremely narrow, wide, or changing.

Part of the lane markings are hidden by an object, such as a vehicle.

The road is hilly or the vehicle is approaching the crest of a hill.

Your vehicle is strongly shaken on uneven road surfaces.

When objects on the road (curb, guard rail, pylons, etc.) are recognized as white
(or yellow) lines.

Driving on rough or unpaved roads, or over bumpy surfaces.

Driving on roads with double lane lines.

Driving on snowy or slippery roads.

Passing through an exit or an intersection.

The pavement is only partially visible due to snow or puddles on the road.

Driving on unpaved or rutted roads.

White (or yellow) lines are not recognized correctly due to road conditions such as
curves, twists, or hills.

543

uu

Honda Sensing

®

u

Road Departure Mitigation System

Continued

Driving

Vehicle conditions

When lighting is weak due to dirt covering the headlight lenses, or there is poor
visibility in a dark place due to the headlights being improperly adjusted.

The front of the camera is covered by dirt, fog, rain, mud, wet snow, seals,
accessories, stickers, or film on the windshield.

Driving at night or in a dark place (e.g., a tunnel) with the headlights off.

When the driver operates the brake pedal and steering wheel.

There is residue on the windshield from the windshield wipers.

An abnormal tire or wheel condition (incorrect sizes, varied sizes or construction,
improperly inflated, compact spare tire, etc.).

The vehicle is tilted due to heavy load in the trunk or rear seats.

Tire chains are installed.

The suspension has been modified.

Examples of limitations on detection due to the condition of oncoming
vehicles

The oncoming vehicle or vehicle ahead of you is sideways.

The oncoming vehicle jumps out in front of you.

When the oncoming vehicle blends in with the background, preventing the
system from recognizing it.

The headlights of a oncoming vehicle are lit on one side or not lit on either side in
a dark place.

The distance between your vehicle and the oncoming vehicle is too short.

Part of the oncoming vehicle is not visible due to the vehicle ahead of you.

There are multiple oncoming lanes or turning lanes.

The vehicle in the adjacent lane is parked or moving at an extremely slow speed.

544

uu

Honda Sensing

®

u

Road Departure Mitigation System

Driving

Examples of other limitations on detection or system operation

When the oncoming vehicle is specially-shaped.

When the camera cannot correctly identify the shape of the oncoming vehicle.

With Little Chance of a Collision

The Road Departure Mitigation system may activate in the below conditions.

When driving through curves, your vehicle comes to a point where an oncoming
vehicle is right in front of you.

545

uu

Honda Sensing

®

u

Traffic Sign Recognition System

Continued

Driving

Traffic Sign Recognition System

Reminds you of road sign information, such as the current speed limit your vehicle
has just passed through, showing it on the gauge.

When the camera located behind the rearview mirror captures traffic signs while
driving, the system displays the ones that are recognized as designated for your
vehicle. The sign icon will be displayed until the vehicle reaches a predetermined
time and distance.
If the system does not detect any traffic signs while you are driving, the sign icon will
not be displayed.

The sign icon also may switch to another one, or disappear when:

The end of speed limit or other designated limit is detected.

You make a turn with a turn signal at an intersection.

How the System Works

1

Traffic Sign Recognition System

Not all signs may be displayed, but any signs posted
on roadsides should not be ignored. The system does
not work on the designated traffic signs of all the
countries you travel, nor in all situations.
Do not rely too much on the system. Always drive at
speeds appropriate for the road conditions.

Never apply a film or attach any objects to the
windshield that could obstruct the camera’s field of
vision and cause the system to operate abnormally.
Scratches, nicks, and other damage to the windshield
within the camera’s field of vision can cause the
system to operate abnormally. If this occurs, we
recommend that you replace the windshield with a
genuine Honda replacement windshield. Making even
minor repairs within the camera’s field of vision or
installing an aftermarket replacement windshield may
also cause the system to operate abnormally. After
replacing the windshield, have a dealer recalibrate the
camera. Proper calibration of the camera is necessary
for the system to operate properly.

The traffic sign recognition system is not activated for
about 15 seconds after the engine starts.

You can read about handling information for the
camera equipped with this system.

2

Front Wide View Camera

 P. 551

You can turn the traffic sign recognition system on
and off.

2

Settings

 P. 126

2

Customized Features

 P. 363

Models with A-type meter

Models with B-type meter

Speed Limit
Sign

uu

Honda Sensing

®

u

Traffic Sign Recognition System

546

Driving

1

Traffic Sign Recognition System

To help reduce the likelihood that high interior
temperatures will cause the camera’s sensing system
to shut off, when parking, find a shady area or face
the front of the vehicle away from the sun. If you use
a reflective sun shade, do not allow it to cover the
camera housing.
Covering the camera can concentrate heat on it.

If your vehicle exceeds the detected speed limit, an
icon representing the speed limit sign for the current
area will blink in the display.

2

Settings

 P. 126

2

Customized Features

 P. 363

The system’s ability to accurately notify the driver of
the speed limit is dependent on certain conditions
such as the units displayed on the traffic sign as well
as the speed and direction of travel of the vehicle. In
some cases, the system may display false warnings or
other inaccurate information.

2

Traffic Sign Recognition System Conditions
and Limitations

 P. 547

The unit for speed limits (mph or km/h) varies from
country to country. Just after entering a country
whose unit differs to the one of the country from
which you came, Traffic Sign Recognition System
may not work correctly.

2

Settings

 P. 126

2

Speed/Distance Units

 P. 125, 150

2

Customized Features

 P. 363















Content      ..     31      32      33      34     ..
