Honda Civic (2022 year). Manual in english - page 23





371

uu

Customized Features

u

Continued

Features

Smartphone Connection

Customizable Features

Description

Selectable Settings

Apple CarPlay

+ Connect New Device

Pairs a new phone to Apple CarPlay.

2

Phone Setup

 P. 414

(Saved Devices)

Connects, disconnects, or deletes a paired phone.

2

Phone Setup

 P. 414

Android Auto

+ Connect New Device

Pairs a new phone to Android Auto.

2

Phone Setup

 P. 414

(Saved Devices)

Connects, disconnects, or deletes a paired phone.

2

Phone Setup

 P. 414

372

uu

Customized Features

u

Features

Connections

*1:Default Setting
*2:Appears only when Apple CarPlay or Android Auto is connected wirelessly.

Customizable Features

Description

Selectable Settings

Wi-Fi

Change Mode

Changes the Wi-Fi mode.

Network

*1

/

Smartphone

*2

/

OFF

(Available Networks/Connected
Devices)

Displays the available network(s) or current connected
device(s).

Options

Add Network

Adds a new network to connect Wi-Fi.

Saved Networks

Saves the connected network.

Setup

Network SSID

Sets the network name.

Security

Displays the network security.

Password

Sets password for require entering password when
connecting Wi-Fi device to the network.

Wi-Fi Band

Displays the Wi-Fi band.

Bluetooth

Options

Bluetooth

Turns the

Bluetooth

®

 on and off.

ON

*1

/

OFF

Priority Device

Displays the priority device.

+ Connect New Device

Pairs a new phone to HFL.

2

Phone Setup

 P. 414

(Saved Devices)

Connects, disconnects, or deletes a paired phone.

2

Phone Setup

 P. 414

373

uu

Customized Features

u

Continued

Features

Display

Sound

Customizable Features

Description

Selectable Settings

Brightness

Changes the brightness of the audio/information screen.

Contrast

Changes the contrast of the audio/information screen.

Black Level

Changes the black level of the audio/information screen.

Default

Resets all customized settings for the brightness,
contrast, and black level.

Customizable Features

Description

Selectable Settings

Bass / Treble

Treble

Adjusts the settings of the audio speakers’ sound.

2

Adjusting the Sound

 P. 280

Midrange

Bass

Audio Zones & Balance / Fader

Bose Centerpoint

Bose Dynamic Speed Compensation

374

uu

Customized Features

u

Features

Camera

*1:Default Setting

Voice Control

*1:Default Setting

Customizable Features

Description

Selectable Settings

Rear Camera

Fixed Guideline

Shows the guideline that does not move with the
steering wheel.

2

Multi-View Rear Camera

 P. 573

ON

*1

/

OFF

Dynamic Guideline

Shows the guideline that moves with the steering
wheel.

2

Multi-View Rear Camera

 P. 573

ON

*1

/

OFF

Cross Traffic Monitor

Shows arrows on the rear camera image to indicate
vehicles approaching from the sides.

2

Cross Traffic Monitor

*

 P. 569

ON

*1

/

OFF

Customizable Features

Description

Selectable Settings

Voice Control Mode

Selects a mode of the voice portal screen.

2

Voice Control Operation

 P. 283

Assist

/

Normal

*1

* Not available on all models

375

uu

Customized Features

u

Continued

Features

With the power mode in ON, press the

 button, and then select

Vehicle Settings



and select a setting item.

How to Customize the Vehicle Settings

Audio/Information Screen

376

uu

Customized Features

u

Features

Customization flow

Press the

 button.

Forward Collision Warning Distance

ACC Forward Vehicle Detect Beep

Traffic Sign Recognition System Display Setting

Road Departure Mitigation Setting

Lane Keeping Assist Suspend Beep

Blind Spot Info

Traffic Sign Recognition System Speed Limit Warning

Speed Limit Warning Threshold Setting

Driver Attention Monitor

Driver Assist System Setup

TPMS Calibration

*

Select

Vehicle Settings

.

* Not available on all models

377

uu

Customized Features

u

Continued

Features

Turn By Turn Auto Display

Speed/Distance Units

Smart Entry Light Flash

Rear Seat Reminder

Door Unlock Mode

Smart Entry Beep

Remote Start System ON/OFF

Lockout Protection

Keyless Access Setup

Meter Setup

Adjust Outside Temp. Display

"Trip A" Reset Timing

"Trip B" Reset Timing

Adjust Alarm Volume

Fuel Efficiency Backlight

378

uu

Customized Features

u

Features

Auto Door Unlock

Auto Door Lock

Key And Remote Unlock Mode

Walk Away Auto Lock

Keyless Lock Answer Back

Door/Window Setup

Lighting Setup

Auto High Beam

Interior Light Dimming Time

Headlight Auto OFF Timer

Auto Light Sensitivity

*

Auto Headlight On with Wiper On

Select Reset Items

Maintenance Info.

Remote Window Control

* Not available on all models

379

uu

Customized Features

u

Continued

Features

TPMS Calibration

*

Driver Assist System Setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

TPMS Calibration

Cancels/Calibrates the tire pressure monitoring system (TPMS).

2

Tire Pressure Monitoring System (TPMS)

 P. 462

Calibrate

/

Cancel

Customizable Features

Description

Selectable Settings

Forward Collision Warning
Distance

Selects distance for Forward Collision Warning audible and visual
alerts.

2

Collision Mitigation Braking System

TM

 (CMBS

TM

)

 P. 476

Long

/

Normal

*1

/

Short

ACC Forward Vehicle Detect
Beep

Turns On/Off audible notification when vehicle has moved in/out of
adaptive cruise control range.

2

Adaptive Cruise Control (ACC) with Low Speed Follow

 P. 494

ON

/

OFF

*1

Road Departure Mitigation
Setting

Selects operating mode of the Road Departure Mitigation system.

2

Road Departure Mitigation System

 P. 537

Narrow

/

Normal

*1

/

Wide

/

Warning Only

Lane Keeping Assist
Suspend Beep

Selects On/Off the LKAS alert for not detecting road lines.

2

Lane Keeping Assist System (LKAS)

 P. 516

ON

/

OFF

*1

* Not available on all models

380

uu

Customized Features

u

Features

*1:Default Setting

Customizable Features

Description

Selectable Settings

Blind Spot Info

Selects On/Off the blind spot information system audible alert.

2

Blind Spot Information System

*

 P. 469

Audible And Visual Alert

*1

/

Visual Alert

Traffic Sign Recognition
System Display Setting

Displays the traffic sign recognition system on the instrument panel.

2

Traffic Sign Recognition System

 P. 545

Display

*1

/

None

Traffic Sign Recognition
System Speed Limit
Warning

Enables over speed limit warning when speed limit is exceeded.

2

Traffic Sign Recognition System

 P. 545

ON

*1

/

OFF

Speed Limit Warning
Threshold Setting

Changes the setting speed the traffic sign recognition system over
speed warning is activated.

2

Traffic Sign Recognition System

 P. 545

Speed Limit

*1

/

Speed Limit



+3mph

/

Speed Limit

+5mph

/

Speed Limit

+10mph

(When mph is selected)

Speed Limit

*1

/

Speed Limit

+5km/h

/

Speed Limit

+10km/h

/

Speed Limit

+15km/h

(When km/h is selected)

Driver Attention Monitor

Changes the setting for the driver attention monitor.

2

Driver Attention Monitor

 P. 144

OFF

/

Tactile Alert

/

Tactile

And Audible Alert

*1

* Not available on all models

381

uu

Customized Features

u

Continued

Features

Meter Setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

Adjust Outside Temp.
Display

Selects to adjust outside temperature reading by a few degrees.

2

Outside Temperature

 P. 111

-5°F

 ~

±0°F

*1

 ~

+5°F

 (U.S.)

-3°C

 ~

±0°C

*1

 ~

+3°C

 (Canada)

"Trip A" Reset Timing

Selects the timing to reset Trip A.

2

Range / Fuel / Trip Meter

 P. 140

2

Speed & Time

 P. 142

When Fully Refueled

/

IGN OFF

/

Manually Reset

*1

"Trip B" Reset Timing

Selects the timing to reset Trip B.

2

Range / Fuel / Trip Meter

 P. 140

2

Speed & Time

 P. 142

When Fully Refueled

/

IGN OFF

/

Manually Reset

*1

Adjust Alarm Volume

Changes volume level of all system warnings, door opening
warning and indicator.

High

/

Mid

*1

/

Low

Fuel Efficiency Backlight

Turns the ambient meter feature on and off.

ON

*1

/

OFF

Turn By Turn Auto Display

Turns on/off the pop-up warning in the turn-by-turn navigation
in the driver information interface.

2

Turn-by-Turn Directions

 P. 143

ON

*1

/

OFF

Speed/Distance Units

Selects the trip computer units.

2

Speed/Distance Units

 P. 150

km/h · km

/

mph · miles

*1



(U.S.)

km/h · km

*1

/

mph · miles



(Canada)

Rear Seat Reminder

Turns the Rear Seat Reminder feature on and off.

ON

*1

/

OFF

382

uu

Customized Features

u

Features

Keyless Access Setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

Door Unlock Mode

Changes which doors unlock when you grab the driver’s door
handle.

Driver Door Only

*1

/

All

Doors

Smart Entry Light Flash

Causes some exterior lights to flash when you unlock/lock the
doors.

ON

*1

/

OFF

Smart Entry Beep

Causes the beeper to sound when you unlock/lock the doors.

ON

*1

/

OFF

Remote Start System ON/
OFF

Turns the remote engine start feature on and off.

ON

*1

/

OFF

Lockout Protection

Changes the settings for the lockout protection function.

ON

*1

/

OFF

383

uu

Customized Features

u

Continued

Features

Lighting Setup

*1:Default Setting

Customizable Features

Description

Selectable Settings

Auto High Beam

Turns on/off auto high beam function.

ON

*1

/

OFF

Interior Light Dimming Time

Selects the length of time the interior lights stay on after doors are
closed.

2

Interior Lights

 P. 207

60sec

/

30sec

*1

/

15sec

Headlight Auto OFF Timer

Selects the length of time the exterior lights stay on after you close
the driver's door.

2

Automatic Lighting Off Feature

 P. 185

60sec

/

30sec

/

15sec

*1

/

0sec

Auto Light Sensitivity

*

Changes the timing for the headlights to come on.

Min

/

Low

/

Mid

*1

/

High

/

Max

Auto Headlight On with
Wiper On

Selects On/Off headlight function and wiper operation when the
headlight is in

AUTO

 setting.

2

Headlight Integration with Wipers

 P. 185

ON

*1

/

OFF

* Not available on all models

384

uu

Customized Features

u

Features

Door/Window Setup

*1:Default Setting

Maintenance Info.

Customizable Features

Description

Selectable Settings

Auto Door Lock

Changes the setting for the automatic locking feature.

OFF

/

With Vehicle Speed

*1

/

Shift From P

Auto Door Unlock

Changes the setting for when the doors unlock automatically.

OFF

/

All Doors When

Driver’s Door Opens

*1

/

All

Doors When Shifted to
Park

/

All Doors With IGN

OFF

Key And Remote Unlock
Mode

Sets up either the driver’s door or all doors to unlock on the first
push of the remote key or built-in key.

Driver Door Only

*1

/

All

Doors

Walk Away Auto Lock

Changes the settings for the auto lock function when you walk
away from the vehicle.

ON

/

OFF

*1

Keyless Lock Answer Back

Turns on/off flash of exterior lights when doors are locked/unlocked
by remote key.

2

Using the Remote Transmitter

 P. 163

ON

*1

/

OFF

Remote Window Control

Turns the remote window control on and off.

ON

*1

/

OFF

Customizable Features

Description

Selectable Settings

Maintenance Info.

Resets the maintenance information.

2

Maintenance Minder

TM

 P. 585

Select Reset Items

385

uu

Customized Features

u

Defaulting All the Settings

Features

Defaulting All the Settings

Reset all the menu and customized settings as the factory defaults.

1.

Press the

 button.

2.

Select

General Settings

.

3.

Select

System

.

4.

Select

Factory Data Reset

.

u

A confirmation message appears on the
screen.

5.

Select

Continue

 to reset the settings.

6.

Select

Continue

 again to reset the settings.

u

The system will reboot.

1.

Press the

 button.

2.

Select

Vehicle Settings

.

3.

Select

Default

.

4.

Select

Yes

.

Defaulting General Settings

1

Defaulting All the Settings

When you transfer the vehicle to a third party, reset
all settings to default and delete all personal data.

If you perform

Factory Data Reset

, it will reset the

preinstalled apps to their factory default.

If you perform

Factory Data Reset

, you cannot use

the HondaLink

®

 because it becomes off line.

2

HondaLink

®

 P. 310

Defaulting Vehicle Settings

386

Features

HomeLink

®

 Universal Transceiver

*

The HomeLink

®

 Universal Transceiver can be programmed to operate up to three

remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

Important Safety Precautions

1

HomeLink

®

 Universal Transceiver

*

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models















Content      ..     21      22      23      24     ..
