Honda Civic (2022 year). Manual in english - page 16





Continued

259

uu

Audio System Basic Operation

u

Android Auto

Features

Maps

Display Google Maps and use the navigation function just as you would with your
Android phone. When the vehicle is in motion, it is not possible to make keyboard
entries. Stop the vehicle in a safe location to undertake a search or provide other
inputs.

Phone

Make and receive phone calls as well as listen to voicemail.

Exit

Operate Android Auto with your voice.

Android Auto Menu

1

Android Auto

For details on countries and regions where Android
Auto is available, as well as information pertaining to
function, refer to the Android Auto homepage.

Screens may differ depending on the version of the
Android Auto app you are using.

Android Auto Operating Requirements &
Limitations

Android Auto requires a compatible Android phone
with an active mobile connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Android
Auto functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Android Auto functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Android Auto performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Android Auto. Refer to the Android
Auto homepage for information on compatible apps.

To adjust the ring tone volume, the guidance volume
of the navigation or voice recognition, or the audio
volume, turn the

VOL

/



AUDIO

 (Volume/Power)

knob while the sound you want to adjust is playing.

Go back to the
audio screen

CONNECT

 Button

Press to display Android Auto screen

Android Auto menu screen

Go back to the Android
Auto menu screen

uu

Audio System Basic Operation

u

Android Auto

260

Features

You can check Android notifications.

 (Android Auto Home)

Display useful information organized by Android Auto into simple cards that
appear just when they’re needed.

When you connect an Android phone to the unit via the USB port, Android Auto is
automatically initiated.

To enable Android Auto after connecting an Android phone to the system, select

Yes

 on the screen.

You may change the consent settings under the

Smartphone Settings

 menu.

Auto Pairing Connection

Connecting Android Auto Using the USB Cable to the USB Port

1

Connecting Android Auto Using the USB Cable to the USB Port

Only initialize Android Auto when you are safely
parked. When Android Auto first detects your phone,
you will need to set up your phone so that auto
pairing is possible. Refer to the instruction manual
that came with your phone.

You can use the following procedure to disconnect or
delete the devices connecting Android Auto after you
have completed the initial setup:
Press the

MENU

 button



Select Smartphone Settings

 Android Auto



Select device

Use of user and vehicle information

The use and handling of user and vehicle information
transmitted to/from your phone by Android Auto is
governed by the Google’s Privacy Policy.

261

uu

Audio System Basic Operation

u

Android Auto

Features

Press the

 (talk) button to operate Android Auto with your voice.

Operating Android Auto with Voice Recognition

1

Operating Android Auto with Voice Recognition

Below are examples of commands you can give with
voice recognition:

Reply to text.

Call my wife.

Navigate to Honda.

Play my music.

Send a text message to my wife.

Call flower shop.

For more information, please refer to the Android
Auto homepage.

You can also activate the voice recognition function

by selecting the

 icon in the lower-right corner of

the screen.

To adjust the guidance volume of voice recognition,
turn the

VOL

/



AUDIO

 (Volume/Power) knob while

the guidance is playing.

 (Talk) button:

Press to operate
Android Auto with your
voice.
Press again to deactivate
voice recognition.

262

Features

Audio System Basic Operation

To use the audio system function, the power mode must be in ACCESSORY or ON.

 (Home) button:

Press to go to the home

screen.

2

Using the audio/information screen



P. 264

 (Back) button:

Press to go back to the

previous screen.

/

 (Seek/Track) buttons:

 Press to

change songs.

Models with Display Audio

 (Home) Button

 (Back) Button

/

 (Seek/Track) Buttons

263

uu

Audio System Basic Operation

u

Start Up

Features

Start Up

The Display Audio starts automatically when you set the power mode to
ACCESSORY or ON. At start-up, the following screen about the data upload will be
displayed.

Select

OK

.

u

If you want to change the settings for
data upload, select

Data Sharing

, then

select the ON/OFF settings on the

Data

Sharing Setting

 screen.

u

If you do not select

OK

, the system will

automatically be switched the home
screen after a certain period of time.

u

If there is no registered device, select

OK



and the

Bluetooth

®

 pairing screen will be

displayed.

u

If you check the box with

Do not show

this again

, this screen will not be

displayed.

To pair a cell phone (when there is no
phone paired to the system)

1.

Make sure your phone is in search or
discoverable mode.

2.

Select

Honda CIVIC

 from your phone.

u

If you want to pair a phone from this
Display Audio, select

Search for

Devices

, and then select your phone

when it appears on the list.

1

Start Up

Data Sharing Setting
ON

: Available the data communication.

OFF

: Not available the data communication.

264

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Audio/Information Screen

Displays the audio status and wallpaper. From this display, you can go to various
setup options.

Using the audio/information screen

Press the

 button to go to the home screen.

Select the following icons on the home screen or after selecting



All Apps

.

Phone

Displays the HFL information.

2

Bluetooth

®

 HandsFreeLink

®

 P. 409

FM/AM/SiriusXM/USB/Bluetooth Audio

Displays information for each audio format.

Switching the Display

1

Using the audio/information screen

Touchscreen operation

Use simple gestures - including touching, swiping
and scrolling - to operate certain audio functions.

Some items may be grayed out during driving to
reduce the potential for distraction.

You can select them when the vehicle is stopped or
use voice commands.

Wearing gloves may limit or prevent touchscreen
response.

You can change the touchscreen sensitivity setting.

2

Customized Features

 P. 363

Home Screen

 Button

 All Apps

265

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

General Settings

Enters the customizing menu screen.

2

Customized Features

 P. 363

Navigation

Displays the navigation screen.

2

Refer to the Navigation System Manual

HondaLink

®

Displays the HondaLink screen.

2

HondaLink

®

 P. 310

Apple CarPlay/Android Auto

Displays the Apple CarPlay or Android Auto.

2

Apple CarPlay

 P. 319

2

Android Auto

 P. 326

Vehicle Settings

Displays the vehicle settings screen.

2

Customized Features

 P. 363

266

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Trip Computer

Displays the trip computer information.

Current Drive

 tab: Displays the current trip information.

Trip A

/

Trip B

 tab: Displays information for the current and three previous drives.

The information is stored every time you reset Trip A/B.
To reset the Trip A/B, select

Settings

, then select

Delete Trip History

.

To change the setting of how to reset Trip A/B, select

Settings

, then select

“Trip A”

Reset Timing

 or

“Trip B” Reset Timing

System Updates

Updates the software version of the audio system.

2

System Updates

 P. 275

Clock

Displays the clock.

Smart Shortcuts

Displays the

Smart Shortcuts

 screen.

2

Smart Shortcuts

 P. 314

Display Mode

Displays the brightness bar.

Continued

267

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

Import wallpaper

You can import up to 11 images, one at a time, for wallpaper from a USB flash drive.

1.

Connect the USB flash drive to the USB
port.

2

USB Port(s)

 P. 231

2.

Press the

 button.

3.

Select

Clock

.

4.

Select

Settings

.

5.

Select

Clock Faces

.

6.

Select

Add More

.

u

The image of the pictures stored in the
USB flash drive are displayed on the list.

7.

Select a desired picture to import.

u

Multiple pictures can be selected at the
same time.

8.

Select

OK

.

u

The selected pictures are displayed.

9.

Select

Transfer

.

u

It will return to the clock wallpaper
setting screen.

Wallpaper Setup

1

Wallpaper Setup

The wallpaper you set up on

Clock Faces

 cannot be

displayed on the driver information interface.

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

The file name must be less than 64 bytes.

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

The individual file size limit is 10 MB.

The maximum image size is 4,096 × 2,304 pixels. If
the image size is less than 1,280 × 720 pixels, the
image is displayed in the middle of the screen with
the extra area appearing in black.

If the USB flash drive does not have any pictures,
the

No files detected

 message appears.

uu

Audio System Basic Operation

u

Audio/Information Screen

268

Features

Select wallpaper

1.

Press the

 button.

2.

Select

Clock

.

3.

Select

Settings

.

4.

Select

Clock Faces

.

5.

Select a desired picture to set.

u

The preview is displayed on the screen.

6.

Select

Save

.

u

The clock screen which the wallpaper has been set is displayed.

To view wallpaper once it is set

1.

Press the

 button.

2.

Select

Clock

.

Delete wallpaper

1.

Press the

 button.

2.

Select

Clock

.

3.

Select

Settings

.

4.

Select

Clock Faces

.

5.

Select

Delete Photos

.

6.

Select a desired picture to delete.

u

Multiple pictures can be selected at the same time.

7.

Select

OK

.

u

The selected pictures are displayed.

8.

Select

Delete

.

u

It will return to the clock wallpaper setting screen.

1

Wallpaper Setup

You cannot delete the initial imported wallpapers.

Continued

269

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To move to the next screen

Selecting

 or

, or swiping the screen left or right changes to the next screen.

Home Screen

1

Home Screen

The home screen has 3 pages. You can add up to 6
pages.

Press the

 button to go directly back to the first

page of the home screen from any page.

Swipe

 Icon

>

 Icon

<

Current page position

<

>

uu

Audio System Basic Operation

u

Audio/Information Screen

270

Features

To add app icons on the home screen

App icons can be added on the home screen.

1.

Press the

 button.

2.

Select

All Apps

.

3.

Select the box checked on the desired apps.

1

To add app icons on the home screen

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2

Defaulting All the Settings

 P. 385

If you perform

Factory Data Reset

, it may reset all

the settings to their factory default.

2

Defaulting All the Settings

 P. 385

In case those apps still do not startup normally even
after

Factory Data Reset

, contact your dealer.

Continued

271

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To move icons on the home screen

You can change location on the home screen.

1.

Press the

 button.

2.

Select and hold an icon.

u

The screen switches to the customization
screen.

3.

Drag and drop the icon to where you want
it to be.

4.

Select

Done

.

u

The screen will return to the home
screen.

1

To move icons on the home screen

Select

Tips

 to show tips. To hide them, select it again.

Select and hold.

Drag and drop.

uu

Audio System Basic Operation

u

Audio/Information Screen

272

Features

To remove icons on the home screen

You can delete the icons on the home screen.

1.

Press the

 button.

2.

Select and hold an icon.

u

The screen switches to the customization
screen.

3.

Drag and drop the icon you want to remove
to the header area.

u

The icon is removed from the home
screen.

4.

Select

Done

.

u

The screen will return to the home
screen.

1

To remove icons on the home screen

You cannot delete the

All Apps

 icon.

Apps will not be deleted by deleting the icon on the
home screen.

Select

Tips

 to show tips. To hide them, select it again.

Select and
hold.

Drag and drop to
the header area.

Continued

273

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To shortcut icons on the home screen

You can store up to six icons on the bottom of the home screen.

1.

Press the

 button.

2.

Select and hold an icon.

u

The screen switches to the customization
screen.

3.

Drag and drop the icon you want to store to
the bottom of the home screen.

u

The icon is shortcut.

4.

Select

Done

.

u

The screen will return to the home
screen.

1

To shortcut icons on the home screen

Select

Tips

 to show tips. To hide them, select it again.

Select and hold.

Drag and drop
to shortcut
icon.

Shortcut
Icons

274

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

1.

Select the system status icon.

u

The status area appears.

2.

Select an item to see the details.

3.

Press the

 button or select the system

status icon to close the area.

Status Area

Status Area

System Status
Icon















Content      ..     14      15      16      17     ..
