Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Seat Belt
Reminder
Indicator

•

Comes on and the beeper sounds
if you are not wearing a seat belt
when you set the power mode to
ON.

•

If the front passenger is not
wearing a seat belt, the indicator
comes on a few seconds later.

•

Blinks while driving if either you
and/or the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

•

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

•

Stays on after you and/or the front
passenger has fastened the seat
belt(s)

- A detection error may have

occurred in the sensor. Have your vehicle
checked by a dealer.

Seat Belt Reminder

P. 41

Low Fuel
Indicator

•

Comes on when the fuel reserve is
running low (approximately 2.9
U.S. gal/11.0 Liter left).

•

Blinks if there is a problem with
the fuel gauge.

•

Comes on

- Refuel your vehicle as soon

as possible.

•

Blinks

- Have your vehicle checked by a

dealer.

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Anti-lock Brake
System (

ABS

)

Indicator

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

If it comes on at any other time,
there is a problem with the ABS.

•

Stays on constantly

- Have your

vehicle checked by a dealer. With this
indicator on, your vehicle still has normal
braking ability but no anti-lock function.

Anti-lock Brake System (ABS)

P. 567

Supplemental
Restraint System
Indicator

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Comes on if a problem with any of
the following is detected:

Supplemental Restraint System

Knee airbag system

Side airbag system

Side curtain airbag system

Seat belt tensioner

•

Stays on constantly or does not
come on at all

- Have your vehicle

checked by a dealer.

Auto High-Beam
Indicator

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Comes on when all the operating
conditions of the Auto high-beam
are met.

Auto High-Beam

P. 197

—

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist

(VSA

)

System Indicator

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Blinks when VSA

is active.

•

Comes on if there is a problem
with the VSA

, hill start assist,

brake assist or brake lighting
system.

•

Stays on constantly

- Have your

vehicle checked by a dealer.

Vehicle Stability Assist

(VSA

aka Electronic Stability Control
(ESC), System

P. 499

Hill start assist system

P. 481

Vehicle Stability
Assist

(VSA

)

OFF

Indicator

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Comes on when you partially
disable VSA

VSA

On and Off

P. 500

—

Electric Power
Steering (EPS)
System Indicator

•

Comes on when you set the
power mode to ON, and goes off
when the engine starts.

•

Comes on if there is a problem
with the EPS system.

•

Stays on constantly

- Have your

vehicle checked by a dealer.

If the Electric Power Steering (EPS)
System Indicator Comes On

P. 667

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Low Tire
Pressure/TPMS
Indicator

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Comes on if the tire pressure of
any of the tires becomes
significantly low.

•

Comes on while driving

- Stop in a

safe place, check tire pressures, and
inflate the tire(s) if necessary.

•

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS with Tire Fill Assist,
or when a compact spare tire is
temporarily installed.

•

Blinks and remains on

- Have your

vehicle checked by a dealer. If the vehicle
is fitted with a compact spare, get your
regular tire repaired or replaced and put
back on your vehicle as soon as you can.

Turn Signal and
Hazard Warning
Indicators

•

Blinks when you operate the turn
signal lever.

•

Blinks along with all turn signals
when you press the hazard
warning button.

•

Does not blink or blinks rapidly

Replacing Light Bulbs

P. 611, 613

—

High Beam
Indicator

•

Comes on when the high beam
headlights are on.

—

Indicators

strum

nt Pa

nel

*1:Canadian models only: Apply and hold the brake pedal before selecting the ON mode.

Indicator

Name

On/Blinking

Explanation

Message

Lights On
Indicator

•

Comes on whenever the light
switch is on, or in

AUTO

when the

exterior lights are on.

•

If you set the power mode to
ACCESSORY or VEHICLE OFF while the
exterior lights are on, a chime sounds
when the driver’s door is opened.

—

Fog Light
Indicator

•

Comes on when the fog lights are
on.

Fog Lights

P. 195

—

Immobilizer
System Indicator

•

Comes on briefly when you set the
power mode to ON, then goes off.

•

Comes on if the immobilizer
system cannot recognize the key
information.

•

Blinks

- You cannot start the engine. Set

the power mode to VEHICLE OFF

, then

select the ON mode again.

•

Repeatedly blinks

- The system may be

malfunctioning. Have your vehicle
checked by a dealer.

•

Do not attempt to alter this system or
add other devices to it. Electrical
problems can occur.

Security System
Alarm Indicator

•

Comes on briefly when you set the
power mode to ON, then goes off.

•

Blinks when the security system
alarm has been set.

Security System Alarm

P. 181

—

Indicator

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

System Message
Indicator

•

Comes on along with a beep
when a problem is detected. A
system message on the driver
information interface appears at
the same time.

•

While the indicator is on, press the

(home) button, select

Warnings

, then

press the

ENTER

button to see the

message again.

•

Refer to the Indicators information in this
chapter when a system message appears
on the driver information interface. Take
the appropriate action for the message.

•

The driver information interface does not
return to the normal screen unless the
warning is canceled, or the

ENTER

button is pressed repeatedly.

—

Econ Mode
Indicator

•

Comes on when you press the

ECON

button.

ECON Button

P. 497

Snow

Mode

Indicator

•

Comes on when you press the

SNOW

button and snow mode is

selected.

Intelligent Traction Management

P. 498

Normal

Mode

Indicator

•

Comes on for a few seconds when

Snow

mode is selected, and the

vehicle is powered off, then
restarted.

Intelligent Traction Management

P. 498

—

100

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Auto Idle Stop
Indicator (Green)

•

Comes on when Auto Idle Stop is
in operation. The engine
automatically shuts off.

Auto Idle Stop

P. 492

—

Auto Idle Stop

OFF

Indicator

•

Comes on when the Auto Idle
Stop system has been turned off
by the Auto Idle Stop

OFF

Button.

Auto Idle Stop System ON/OFF

P. 493

Auto Idle Stop
System Indicator
(Amber)

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

—

•

Blinks if there is a problem with
the Auto Idle Stop system.

•

Blinks

- Have your vehicle checked by a

dealer.

101

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Auto Idle Stop
Suspend
Indicator

•

Comes on while Auto Idle Stop is
temporarily suspended in the
following situations.

—

Brake pedal is not fully pressed.

•

Depress the brake pedal firmly.

The transmission is in a position
other than

(

Auto Idle Stop

P. 492

System charging is prioritized.

Climate control system is
prioritized.

Engine coolant temperature is
not in operating range.

The Intelligent Traction
Management is set to

Snow

The battery temperature is too low.

Auto Idle Stop does not activate
for some reason.

102

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Auto Idle Stop
Suspend
Indicator

—

•

If you press and hold the Auto Idle Stop

OFF

button, you can select whether to

display the status messages or not.

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Comes on if there is a problem
with the LKAS.

•

Stays on constantly

- Have your

vehicle checked by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(White/Green)

•

Lights up in white when you press
the LKAS button.

•

Lights up in green when the LKAS
is in operation.

Lane Keeping Assist System (LKAS)

P. 539

—

103

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(Amber)

•

Comes on for a few seconds when
you set the power mode to ON,
then goes off.

•

Comes on if there is a problem
with ACC with Low Speed Follow.

•

Comes on while driving

- Have your

vehicle checked by a dealer.

•

Indicator may come on
temporarily when the Maximum
Load Limit is exceeded.

•

ACC with Low Speed Follow has
been automatically canceled.

•

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit

P. 467

•

Stays on constantly

- Have your

vehicle checked by a dealer.

—

Adaptive Cruise
Control (ACC)
with Low Speed
Follow Indicator
(White/Green)

•

Lights up in white when you press
the

button.

•

Lights up in green when you press
the

RES/+

button or

-/SET

button.

Adaptive Cruise Control (ACC) with
Low Speed Follow

P. 523

—

104

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Cruise Mode
Indicator
(White/Green)

•

Lights up in white when you
change to cruise mode.

•

Lights up in green when you have
set a speed for cruise control.

To Switch ACC with Low Speed
Follow to Cruise Control

P. 537

—

Safety Support
Indicator
(Amber)

•

Comes on if there is a problem
with RDM, CMBS

, or blind spot

information system.

•

Stays on constantly

- Have your

vehicle checked by a dealer.

•

Indicator may come on
temporarily when the Maximum
Load Limit is exceeded.

•

Make sure the total load is within the
Maximum Load Limit.

Maximum Load Limit

P. 467

105

Indicators

Continued

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Safety Support
Indicator
(Amber)

•

Comes on when RDM and/or
CMBS

shuts itself off.

•

Indicator may come on temporarily
when passing through an enclosed
space, such as a tunnel.

•

The area around the radar sensor is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the
debris off with a soft cloth. Indicator may
take some time to go off after the radar
sensor is cleaned.

•

Have your vehicle checked by a dealer if
the indicator does not go off even after
you have cleaned the radar sensor.

Radar Sensor

P. 560

•

Stays on

- The temperature inside the

camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

Front Sensor Camera

P. 558

106

Indicators

strum

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Safety Support
Indicator
(Amber)

•

Comes on when RDM and/or
CMBS

shuts itself off.

•

Stays on

- The area around the camera

is blocked by dirt, mud, etc. Stop your
vehicle in a safe place and wipe the
debris off with a soft cloth.

•

Have your vehicle checked by a dealer if
the indicator and message are still
displayed even after you have cleaned
the area around the camera.

Front Sensor Camera

P. 558

•

Comes on when mud, snow, or ice
has accumulated in the vicinity of
the blind spot information system
sensor.

•

Comes on while driving

- Something

may be interfering with the blind spot
information system sensor. Check the
vicinity of the blind spot information
system sensor and remove any obstacles.

Blind spot information System

P. 506
