Honda Insight (2022 year). Manual in english - page 15





Continued

237

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

You can change, store, and delete the wallpaper on the audio/information screen.

Import wallpaper

1.

Connect the USB flash drive to the USB
port.

2

USB Ports

 P. 225

2.

Select

Clock

.

3.

Select

Settings

.

4.

Select

Clock Faces

.

5.

Select

Add New Wallpaper

.

u

The

Searching...

 screen is displayed.

6.

Import a desired picture.

u

Multiple pictures can be imported at the
same time.

7.

Select

Start Import

.

u

The display will return to the

Clock Faces



screen.

Wallpaper Setup

1

Wallpaper Setup

The wallpaper you set up on

Clock Faces

 cannot be

displayed on the driver information interface.

When importing wallpaper files, the image must be
in the USB flash drive’s root directory.
Images in a folder cannot be imported.

The file name must be fewer than 64 characters.

The file format of the image that can be imported
is BMP (bmp) or JPEG (jpg).

The individual file size limit is less than 2 MB.

If the USB flash drive does not have any pictures,
the

No files detected

 message appears.

Up to five pictures can be imported.

The maximum image size is 1,920 × 936 pixels. If
the image size is less the image is displayed in the
middle of the screen with the extra area appearing
in black.

uu

Audio System Basic Operation

u

Audio/Information Screen

238

Features

Select wallpaper

1.

Select

Clock

.

2.

Select

Settings

.

3.

Select

Clock Faces

.

4.

Select a desired wallpaper.

5.

Select

Set

.

u

The display will return to the

Clock Faces

 screen.

To view wallpaper once it is set

1.

Press the

 button.

2.

Select

Clock

.

Delete wallpaper

1.

Select

Clock

.

2.

Select

Settings

.

3.

Select

Clock Faces

.

4.

Select a desired wallpaper.

5.

Select

Delete

.

6.

Select

Yes

.

u

The display will return to the

Clock Faces

 screen.

1

Wallpaper Setup

You cannot delete the initial imported wallpapers.

Continued

239

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To change to a next screen

Selecting

 or

, or swiping the screen left or right changes to the next screen.

Home Screen

1

Home Screen

The home screen has 2 or 3 pages. You can add up
to 7 pages.

Press the

 button to go directly back to the first

page of the home screen from any page.

Swipe

 Icon

>

 Icon

<

Current page position

<

>

uu

Audio System Basic Operation

u

Audio/Information Screen

240

Features

To add app icons on the home screen

App icons can be added on the home screen.

1.

Press the

 button.

2.

Select and hold the home screen.

3.

Select

Add

.

4.

Drag and drop the icon to where you want
it to be.

5.

Select

Done

.

u

The screen will return to the home
screen.

1

To add app icons on the home screen

You can add app icons by the following procedure.
1. Press the

 button.

2. Select

All Apps

.

3. Select

Customize

.

4. Select

Add

.

5. Drag and drop the icon to where you want it to

be.

6. Select

Done

.

u

The screen will return to the home screen.

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

2

Defaulting All the Settings

 P. 345

If you perform

Factory Data Reset

, it may reset all

the settings to their factory default.

2

Defaulting All the Settings

 P. 345

In case those apps still do not startup normally even
after

Factory Data Reset

, contact your dealer.

If a browser shuts down mid-use, the screen will
return to the screen viewed prior to the browser
startup.

Continued

241

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To move icons on the home screen

You can change location on the home screen.

1.

Select and hold an icon.

u

The screen switches to the customization
screen.

2.

Drag and drop the icon to where you want
it to be.

3.

Select

Done

.

u

The screen will return to the home
screen.

1

To move icons on the home screen

Select

Tips

 to show tips. To hide them, select it again.

Select and hold.

Drag and drop.

uu

Audio System Basic Operation

u

Audio/Information Screen

242

Features

To remove icons on the home screen

You can delete the icons on the home screen.

1.

Select and hold an icon.

u

The screen switches to the customization
screen.

2.

Drag and drop the icon you want to remove
to the

Hide

 icon.

u

The icon is removed from the home
screen.

3.

Select

Done

.

u

The screen will return to the home
screen.

1

To remove icons on the home screen

Apps will not be deleted by deleting the icon on the
home screen.

Select

Tips

 to show tips. To hide them, select it again.

Select and hold.

Drag and drop to

Hide

 icon.

Continued

243

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To shortcut icons on the home screen

You can store up to three icons on the upper left of the home screen.

1.

Select and hold an icon.

u

The screen switches to the customization
screen.

2.

Drag and drop the icon you want to store to
the upper left of the home screen.

u

The icon is a shortcut.

3.

Select

Done

.

u

The screen will return to the home
screen.

1

To shortcut icons on the home screen

Select

Tips

 to show tips. To hide them, select it again.

Select and hold.

Drag and

drop to

preset icon.

Shortcut

Icons

244

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

1.

Select the system status icon.

u

The status area appears.

2.

Select an item to see the details.

3.

Press the

 button or the system status

icon to close the area.

Status Area

System

Status Icon

Status Area

245

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

You can edit, show, or hide the meter contents on the driver information interface.

1.

Press the

 button.

2.

Select

Settings

.

3.

Select

System

.

4.

Select

Config. of Instrument Panel

.

5.

Select and hold the content you wish to
show or hide.

u

The checked items are displayed on the
driver information interface.

Editing order

To change the order of the contents on the driver information interface, first select:

1.

Press the

 button.

2.

Select

Settings

.

3.

Select

System

.

4.

Select

Config. of Instrument Panel

.

5.

Select

Reorder

.

6.

Select and hold the contents you want to
move.

7.

Drag and drop the contents to where you
want them to be.

8.

Select

Done

.

Customizing the Meter

1

Customizing the Meter

You can store up to three customized configurations.
To select or customize a configuration, select

Select

configuration

.

When you select

Select configuration

 during

customization, the settings you changed will be
saved.

246

uu

Audio System Basic Operation

u

System Updates

Features

System Updates

The audio system’s firmware can be updated with a Wi-Fi connection or with a USB
device.

Wireless connection mode setup

1.

Press the

 button.

2.

Select

System Updates

.

3.

Select

Settings

.

4.

Select

Connection Setup

.

5.

Select

Change Mode

.

6.

Select

Network

, then

Confirm

.

u

The display returns to the network list.

7.

Select an access point from the network list,
then

Save

.

u

If the audio system requires a password,
enter a password.

How to Update Wirelessly

1

Wireless connection mode setup

If your vehicle has a telematics control unit (TCU), you
do not need the wireless connection mode setup.

Continued

247

uu

Audio System Basic Operation

u

System Updates

Features

How to update

When the audio system update is available, the notification is shown on the audio/
information screen. Use the following procedure to update the system.

1.

Press the

 button.

2.

Select

System Updates

.

3.

Select

via Wireless

.

u

If a notification is displayed on the
screen, the screen of step 5 will be
displayed.

4.

Select

Download Now

.

u

A notification appears on the screen.

1

How to update

You can update the system via Wi-Fi, but cannot use
the captive portal that require login or agreement the
terms of use on the browser.

Your download will be canceled if:

Your Wi-Fi connection is severed.

You turn off the power system when the 12-volt
battery is low on power.

Your download will recommence the next time a Wi-
Fi connection is established.

Notification

uu

Audio System Basic Operation

u

System Updates

248

Features

5.

Select

Install Now

 or

Install while

Vehicle OFF

.

u

A notification appears on the screen if
the update is successful.

1

How to update

For the 12-volt battery protection,

Install while

Vehicle OFF

 cannot be selected when the battery is

low on power. If you want to install the updated
data, recharge the battery or select

Install Now

.

249

uu

Audio System Basic Operation

u

System Updates

Continued

Features

Automatic download settings

Use the following procedure to change to the automatic download setting.

1.

Press the

 button.

2.

Select

System Updates

.

3.

Select

Settings

.

4.

Select

Auto Download

.

5.

Select the access point, then

Yes

.

View a version and update status

Use the following procedure to confirm the version and update status.

1.

Press the

 button.

2.

Select

System Updates

.

3.

Select

Settings

.

4.

Select

Version Status

.

uu

Audio System Basic Operation

u

System Updates

250

Features

Download the update files from the server

1.

Press the

 button.

2.

Select

System Updates

.

3.

Select

via USB

.

u

A notification appears on the screen.

4.

Connect a USB device into the USB port.

u

The inventory data is copied into the USB
device.

2

USB Ports

 P. 225

5.

Remove the USB device from the USB port.

6.

Connect the USB device into your
computer, and then download the update
files.

u

Follow the link to download the required
software update files. Refer to

https://usb.honda.com

 for instructions.

How to Update with a USB Device

1

How to Update with a USB Device

A USB device with a minimum of 8 GB of free space
or more is recommended.

Be sure to delete any previous inventory or update
files from the USB before starting the USB update
process.

251

uu

Audio System Basic Operation

u

System Updates

Features

Update the audio system

1.

Press the

 button.

2.

Select

System Updates

.

3.

Select

via USB

.

u

A notification appears on the screen.

4.

Connect the USB device with the update
files into the USB port.

u

A notification appears on the screen.

2

USB Ports

 P. 225

5.

Select

Install Now

.

u

A notification appears on the screen if
the update is successful.

252

uu

Audio System Basic Operation

u

Adjusting the Sound

Features

Adjusting the Sound

1.

Press the

 button.

2.

Select an audio source icon.

3.

Select

Sound

.

4.

Select the setting you want.

5.

Select

Save

.

Select an item from the following choices:

Bass / Treble

: Treble, Midrange, Bass

Balance / Fader

: Balance, Fader

DTS Neural Surround

*

: DTS Neural

Surround

TM

Speed Volume Compensation

: Speed

Volume Compensation (SVC)

1

Adjusting the Sound

The SVC adjusts the volume level based on the
vehicle speed. As you go faster, audio volume
increases. As you slow down, audio volume
decreases.

You can also adjust the sound the following
procedure.
1. Press the

 button.

2. Select

Settings

.

3. Select

Sound

.

To reset each setting for

Bass / Treble

Balance /

Fader

DTS Neural Surround

*

 and

Speed Volume

Compensation

 select

Default

.

* Not available on all models















Content      ..     13      14      15      16     ..
