Honda Insight (2022 year). Manual in english - page 9





uu

Gauges and Driver Information Interface

u

Driver Information Interface

140

In

strum

ent Pa

nel

Compass

Shows the compass screen.

Turn-by-Turn Directions

When driving guidance is provided by the
navigation system

*

, Android Auto or Apple

CarPlay, turn-by-turn directions to your
destination appear.

2

Refer to the Navigation System Manual

2

Android Auto

TM

 P. 298

2

Apple CarPlay

TM

 P. 294

Navigation

1

Navigation

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

2

Customized Features

 P. 326

When the compass or turn-by-turn directions are
displayed, you can control some navigation system
functions on the driver information interface by
scrolling the left selector wheel.

2

Refer to the navigation system

Models with navigation system

Compass

Turn-By-Turn Driving Directions

* Not available on all models

Continued

141

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

2

Driver Information Interface Warning and
Information Messages

 P. 104

Oil Life

Shows the remaining oil life and Maintenance
Minder

TM

.

2

Maintenance Minder

TM

 P. 493

Warnings

1

Warnings

If there are no Warnings,

None

 message appears on

the driver information interface.

(Example)

Maintenance

142

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Shows the current phone information.

2

Bluetooth

®

 HandsFreeLink

®

 P. 349

Phone

143

uu

Gauges and Driver Information Interface

u

Driver Information Interface

Continued

In

strum

ent Pa

nel

Shows the current audio information.

2

Audio System Basic Operation

 P. 230

Audio

144

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Shows the traffic sign recognition system.

2

Traffic Sign Recognition System

 P. 459

Traffic Sign Recognition System

Continued

145

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

The Driver Attention Monitor analyzes steering inputs to determine if the vehicle is
being driven in a manner consistent with drowsy or inattentive driving. If it
determines that the vehicle is being driven in such a manner, it will display the
degree of the driver’s attention on the driver information interface.

When you select

Driver Attention

 on the

driver information interface, bars on it light up
in white to indicate the degree of the driver’s
attention.

2

Accessing contents in the main display



P. 132

Driver Attention Monitor

1

Driver Attention Monitor

The Driver Attention Monitor cannot always detect if
the driver is tired or inattentive.
Regardless of the system’s feedback, if you are
feeling tired, stop in a safe location and rest for as
long as needed.

Driver Information

Interface

Left Selector

Wheel

 (home) Button

Level

146

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

If two bars light up, the

Driver Attention

Level Low

 message will appear.

If one bar lights up, the

Driver Attention

Level Low. Time For A Break

 message will

appear, a beep will sound, and the steering
wheel will vibrate.
If this message appears, stop in a safe location
and rest for as long as needed.
The message will disappear when the left
selector wheel is pressed or when the system
has determined that the driver is driving
normally.
If the driver does not take a break and the
monitor continues to detect that the driver is
very tired, the message will appear again after
approximately 15 minutes, accompanied by a
beep and steering wheel vibrations.
The message does not appear when the
traveling time is 30 minutes or less.

Continued

147

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

The Driver Attention Monitor resets when:

The power mode is set to VEHICLE OFF.

The driver unfastens the seat belt and opens the door while the vehicle is stopped.

For the Driver Attention Monitor to function:

The vehicle must be traveling above 25 mph (40 km/h).

The electric power steering (EPS) system indicator must be off.

Depending on driving conditions or other factors, the Driver Attention
Monitor may not function in the following circumstances:

The steering assist function of the Lane Keeping Assist System (LKAS) is active.

2

Lane Keeping Assist System (LKAS)

 P. 446

The condition of the road is poor, e.g. the surface is unpaved or bumpy.

It is windy.

The driver is frequently operating the vehicle in an assertive manner such as
changing lanes or accelerating.

Customizing

You can change the Driver Attention Monitor settings. Select

Tactile And Audible

Alert

Tactile Alert

, or

OFF

.

2

Customized Features

 P. 326

1

For the Driver Attention Monitor to function:

The bars on the driver information interface remain
grayed out unless the Driver Attention Monitor is
functioning.

uu

Gauges and Driver Information Interface

u

Driver Information Interface

148

In

strum

ent Pa

nel

Shows the distance between your vehicle and
the vehicle detected ahead.
Informs you whether ACC with Low Speed
Follow and/or LKAS is activated or not. If ACC
with Low Speed Follow is activated, the set
following interval is displayed. If LKAS is
activated, the displayed lane marks change to
indicate that LKAS is activated.

2

Adaptive Cruise Control (ACC) with Low
Speed Follow

 P. 428

2

Lane Keeping Assist System (LKAS)

 P. 446

Driving Support Information

1

Driving Support Information

In case ACC with Low Speed Follow is not activated,
when the distance between your vehicle and the
vehicle ahead becomes too small, the section behind
the vehicle icon turns amber and alerts you.

Amber gradation

Icon of vehicle ahead

Distance of vehicle ahead

When ACC and LKAS is in On

Set Vehicle Interval

ACC on: The section behind the

vehicle icon turns green.
LKAS on: The lane outlines

appear on the display.
LKAS starts: The lane lines

change to solid ones.
LKAS suspend: The lane lines

change to dotted ones.

Continued

149

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Indicates the state of RDM, CMBS

TM

 and blind spot information system, such as On,

Off, or Failure, by color and letters.

The following colors indicate the state of any of the above mentioned systems:

Green: The system is on.

Gray: The system is off.

Amber: There is a problem with the system.

Safety Support

1

Safety Support

If a system is indicated by the color amber, have your
vehicle checked by a dealer immediately.

To turn on or off each system, first rotate the left
selector wheel to switch displays. From the next
display you can select which system to turn on or off.

2

RDM On and Off

 P. 456

2

CMBS

TM

 On and Off

 P. 422

2

Blind spot information System On and Off



P. 413

You can also confirm the state of the each function
by the color of the safety support indicator.

2

Safety Support Indicator (Amber)

 P. 100

2

Safety Support Indicator (Green/Gray)



P. 103

Area Info for

CMBS

TM

CMBS

TM

 Icon

and State Info

RDM Icon and

State Info

Area Info

for RDM

Area Info for

Blind spot

information

system

Blind spot

information

system Icon

and State Info

150

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Shows the average fuel economy for the last
three driving cycles (1-3), and the current
driving cycle (0) in mpg or l/100 km.

Each time you set the power mode to ON, the
display is updated, and the oldest record is
deleted.

Average Fuel Economy Records

Continued

151

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Eco Drive Display

The vehicle icon on the display moves forward or backward while driving.
The more aggressive the acceleration is, the further the icon moves forward.
The more aggressive the deceleration is, the further the icon moves backward.
Keep the icon near the center of the circle for better fuel economy while driving.

Eco Drive Display/Drive Cycle Score/Lifetime Points

1

Eco Drive Display

Switch between the average fuel economy A and
average fuel economy B by rolling the left selector
wheel.

Aggressive

Deceleration

Fuel-Efficient

Driving

Aggressive

Acceleration

Moderate

Deceleration

Moderate

Acceleration

Average Fuel

Economy

Vehicle Icon

152

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Drive Cycle Score/Lifetime Points

Appear for a few seconds when you set the power mode to VEHICLE OFF. Each has
three stages. Depending on your driving style, the leaf icon(s) and the gauge
increase or decrease to indicate that you have reached a different stage of fuel
economy.

Resetting the Drive Cycle Score

1.

Make sure the shift position is in

(

P

. Turn the power mode to ON.

2.

If ECON mode is on, press the

ECON

 button to turn it off.

3.

Turn the power mode to VEHICLE OFF.

4.

Turn the power mode to ON again.

u

Make sure to complete steps from 4 through 6 within 30 seconds.

5.

Depress the brake pedal twice.

u

The color of the ambient meter will change from white to green.

u

When the

Fuel Efficiency Backlight

 setting on the audio/information screen

is off, the color stays white.

6.

Press the

ECON

 button twice.

u

The color of the ambient meter will turn to monochrome.

7.

Turn the power mode to VEHICLE OFF.

Drive Cycle Score

Lifetime Points

Advancing

to 2nd

Stage

Advancing

to 3rd

Stage

Receding

to 3rd

Stage

Receding

to 2nd

Stage

153

uu

Gauges and Driver Information Interface

u

Driver Information Interface

In

strum

ent Pa

nel

Displays the power flow of the motor and engine, indicating the vehicle’s power
source and whether the battery is being charged.

Power Flow Monitor

1

Power Flow Monitor

While the vehicle is stationary with the engine
running, the following may appear on the driver
information interface.

Engine ON

Engine OFF

Power Flow

Engine

Power is supplied

by the motor and

the engine.

Hybrid (HV)

Power is supplied

by the motor.

Electric Vehicle (EV)

Power is being supplied to

charge the High Voltage

battery and supply power

to the wheels.

Engine (Direct Drive)

The motor is

charging the High

Voltage battery.

Regeneration

Power is being

supplied by the

engine only.

The engine is running

and the motor is

charging the High

Voltage battery.

155

Controls

This chapter explains how to operate the various controls necessary for driving.

Clock

.................................................. 156

Locking and Unlocking the Doors

Key .................................................. 157
Low Keyless Remote Signal Strength ...159
Locking/Unlocking the Doors from the

Outside .......................................... 160

Locking/Unlocking the Doors from the

Inside ............................................. 167

Childproof Door Locks ..................... 169
Auto Door Locking/Unlocking .......... 170

Opening and Closing the Trunk

....... 171

Security System

Immobilizer System .......................... 174

Security System Alarm...................... 175

Opening and Closing the Windows

... 177

Moonroof

*

................................................ 180

Operating the Switches Around the

Steering Wheel

POWER Button................................. 181
Turn Signals ..................................... 184
Light Switches.................................. 185
Fog Lights

*

...................................... 188

Daytime Running Lights ................... 188
Auto High-Beam .............................. 189
Wipers and Washers ........................ 192

Rear Defogger/Heated Door Mirror

Button ........................................ 194

Brightness Control ........................... 195
Adjusting the Steering Wheel .......... 196

Adjusting the Mirrors

Interior Rearview Mirror ................... 197
Power Door Mirrors ......................... 198

Adjusting the Seats

.......................... 199

Interior Lights/Interior Convenience

Items

................................................ 207

Climate Control System

Using Automatic Climate Control .... 216
Automatic Climate Control Sensors... 222

* Not available on all models

156

Co
ntrols

Clock

Adjusting the Clock

You can adjust the time manually in the audio/information screen with the power
mode in ON.

Using the Settings menu on the audio/
information screen

1.

Press the

, then select

Settings

.

2.

Select

System

.

3.

Select

Day & Time

.

4.

Select

Set Date & Time

.

5.

Select

Automatic Date & Time

, then

select

OFF

.

To adjust time:
6.

Select

Set Time

.

7.

Selecting /

.

8.

Select

Save

 to set the time.

To adjust date:
6.

Select

Set Date

.

7.

Selecting /

.

8.

Select

Save

 to set the date.

Adjusting the Time

1

Clock

The clock is automatically updated through the audio
system.

You can customize the clock display to show the 12
hour clock or 24 hour clock.

2

Customized Features

 P. 326

1

Using the Settings menu on the audio/information screen

You can also adjust the clock by touching the clock
displayed on the upper right corner of the display or
the

Clock

 icon on the home screen.

1. Touch the clock on the display.

The clock screen of the select face-type appears.

2. Select

Settings

.

3. Select

Day & Time

.

4. Select

Set Date & Time

.

5. Select

Automatic Date & Time

, then select

OFF

.

6. Select

Set Date

 or

Set Time

.

7. Adjusting the dates, hours and minutes by

selecting /

.

8. Select

Save

 to set the time.

You can customize the date display to

MM/DD/

YYYY

DD/MM/YYYY

 or

YYYY/MM/DD

.

2

Customized Features

 P. 326

3 4

3 4

3 4















Content      ..     7      8      9      10     ..
