Honda e (2021 year). Manual in english - page 11





uu

Gauges and Displays

u

Driver Information Interface

162

In

strum

e

nt Pa

nel

Compass

Shows the compass screen.

Turn-by-turn directions

When driving guidance is provided by the navigation system, Android Auto or Apple
CarPlay, turn-by-turn directions to your destination appear.

2

Refer to the Navigation System Manual

2

Android Auto

 P. 313

2

Apple CarPlay

 P. 309

Navigation

1

Navigation

You can select whether to have the turn-by-turn
display come on or not during the route guidance.

2

Customized Features

 P. 327

When the compass or turn-by-turn directions are
displayed, you can control some navigation system
functions on the driver information interface by
scrolling the left selector wheel.

2

Refer to the Navigation System Manual

163

uu

Gauges and Displays

u

Driver Information Interface

Continued

In

strum

e

nt Pa

nel

Sets the speed alarm on and changes the speed alarm setting.

Roll the left selector wheel, the speed alarm setting changes as follows:

*1:Default Setting

Speed Alarm

a

Speed Alarm 1 On/Off

*1

b

Speed Alarm 2 On/Off

*1

c

Speed Alarm 1 Speed Setting [50 km/h (30mph)

*1

]

d

Speed Alarm 2 Speed Setting [80 km/h (50mph)

*1

]

e

Back

164

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Appears when any of the seat belts are latched or unlatched.

Shows the service reminder system.

2

Service Reminder System

*

 P. 582

Seat Belts

Maintenance

*

* Not available on all models

Continued

165

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Indicates the state of the Road Departure Mitigation system, Blind Spot Information
System

*

, Low Speed Braking Control and CMBS such as On, Off, or Failure, by

colour and letters.

The following colours indicate the state of any of the above mentioned systems:

Green: The system is on.

Gray: The system is off.

Amber: There is a problem with the system.

Safety Support

1

Safety Support

If a system is indicated by the colour amber, have
your vehicle checked by a dealer immediately.

To turn on or off each system, first rotate the left
selector wheel to switch displays. From the next
display you can select which system to turn on or off.

2

Road Departure Mitigation On and Off



P. 481

2

Blind spot information On and Off

 P. 426

2

System On and Off

 P. 444

2

CMBS On and Off

 P. 434

You can also confirm the state of the each function
by the colour of the safety support indicator.

2

Safety Support Indicator (Amber)

 P. 125

2

Safety Support Indicator (Green/Gray)



P. 128

* Not available on all models

166

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

a

Area Info for the Road Departure Mitigation system

b

Road Departure Mitigation system Icon and State Info

c

Area Info for the Blind Spot Information

*

d

Blind Spot Information

*

 Icon and State Info

e

Area Info for the Low Speed Braking Control

f

Low Speed Braking Control Icon and State Info

g

Area Info for the CMBS

h

CMBS Icon and State Info

3

5

* Not available on all models

Continued

167

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Change the settings to your liking.

Arrange content

You can choose which icons to display on the home screen.

1.

Roll the left selector wheel to scroll to select

, then press the left selector wheel.

2.

Roll the left selector wheel to scroll to select

, then press the left selector wheel.

3.

Roll the left selector wheel to scroll
between icons, then press the left selector
wheel to check or uncheck them.

Customize Display

1

Customize Display

Icons that are gray cannot be removed from the
home screen.

uu

Gauges and Displays

u

Driver Information Interface

168

In

strum

e

nt Pa

nel

Enables you to show another speed unit on the driver information interface and set
the displayed measurements to read in either km/h or mph.

Press and hold the left selector wheel when you select

 on the driver information

interface. Each time you do this, the unit will change from km/h to mph or vice
versa. After this, a confirmation screen will appear for a few seconds.

2

Driver Information Interface Warning and Information Messages

 P. 130

Displays the current status of the High Voltage
battery.
The colour of the circle represents the current
High Voltage battery status.

Green: Charging

Amber: High Voltage battery is running low
(approximately 15% left)

White: When other than the above or when
fully charged

Unit Change

Information

Remaining Battery

1

Remaining Battery

If amber is displayed, charge the High Voltage battery
as soon as possible.

169

uu

Gauges and Displays

u

Driver Information Interface

In

strum

e

nt Pa

nel

Displays the current status of the timer climate
control system.

2

Pre-Conditioning Climate Schedule
Setting

 P. 323

Displays the current charging status.

2

Charging

 P. 562

Pre-Conditioning Climate Schedule

Charging Time Remaining

170

171

Controls

This chapter explains how to operate the various controls necessary for driving.

Locking and Unlocking the Doors

Key .................................................. 172
Low Keyless Remote Signal Strength .... 174
Locking/Unlocking the Doors from the

Outside .......................................... 175

Locking/Unlocking the Doors from the

Inside ............................................. 182

Childproof Door Locks ..................... 184
NFC Marks ....................................... 185

Tailgate

.............................................. 186

Security System

Immobilizer System .......................... 188

Security System Alarm...................... 189
Ultrasonic Sensors

*

.......................... 191

Tilt Sensor

*

...................................... 192

Super Locking

*

................................ 193

Windows

........................................... 194

Operating the Switches Around the

Steering Wheel

POWER Button................................. 197
Lights............................................... 201
Auto High-Beam .............................. 206
Wipers and Washers ........................ 210
Rear Demister Button....................... 213

Adjusting the Steering Wheel .......... 214

Adjustment of Each Type of Mirror

Centre Camera Mirror System

*

........ 215

Interior Rearview Mirror

*

................. 220

Side Camera Mirror System.............. 221

Seats

.................................................. 227

Interior Convenience Items

.............. 235

Climate Control System

................... 247

* Not available on all models

172

Co
ntrols

Locking and Unlocking the Doors

Key

This vehicle comes with the following key:

Use the keys to start and stop the power
system, and to lock and unlock all the doors,
tailgate, and charge lid.

The built-in key can be used to lock/unlock the
doors when the keyless remote battery
becomes weak and the power door lock/
unlock operation is disabled.

To remove the built-in key, slide the release
knob and then pull out the key. To reinstall
the built-in key, push the built-in key into the
keyless remote until it clicks.

1

Key

All the keys have an immobilizer system. The
immobilizer system helps to protect against vehicle
theft.

2

Immobilizer System

 P. 188

Follow the advice below to prevent damage to the
keys:

Do not leave the keys in direct sunlight, or in
locations with high temperature or high humidity.

Do not drop the keys or set heavy objects on them.

Keep the keys away from liquids, dust and sand.

Do not take the keys apart except for replacing the
battery.

If the circuits in the keys are damaged, the power
system may not activate, and the remote transmitter
may not work.
If the keys do not work properly, have them
inspected by a dealer.

You can turn the climate control system on and off
using the keyless remote.

2

Remote Climate Pre-Conditioning

 P. 250

Keyless Remote

Built-in Key

a

Release Knob

b

Built-in Key

173

uu

Locking and Unlocking the Doors

u

Key

Co
ntrols

Contains a number that you will need if you
purchase a replacement key.

Key Number Tag

1

Key Number Tag

Keep the key number tag separate from the key in a
safe place outside of your vehicle.
If you wish to purchase an additional key, contact a
dealer.

If you lose your key and you cannot activate the
power system, contact a dealer.

174

uu

Locking and Unlocking the Doors

u

Low Keyless Remote Signal Strength

Co
ntrols

Low Keyless Remote Signal Strength

The vehicle transmits radio waves to locate the keyless remote when locking/
unlocking the doors, tailgate and charge lid, or to activate the power system.

In the following cases, locking/unlocking the doors and tailgate, or activating the
power system may be inhibited or operation may be unstable:

Strong radio waves are being transmitted by nearby equipment.

You are carrying the keyless remote together with telecommunications
equipment, laptop computers, mobile phones, or wireless devices.

A metallic object is touching or covering the keyless remote.

1

Low Keyless Remote Signal Strength

Communication between the keyless remote and the
vehicle consumes the keyless remote’s battery.
Battery life is about two years, but this varies
depending on regularity of use.
The battery is consumed whenever the keyless
remote is receiving strong radio waves. Avoid placing
it near electrical appliances such as televisions and
personal computers.

175

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Continued

Co
ntrols

Locking/Unlocking the Doors from the Outside

When you carry the keyless remote, the front
door outer handles automatically pop in/out
and you can lock/unlock the doors and
tailgate.
You can lock/unlock the doors and tailgate
within a radius of about 80 cm (32 inches) of
the front door outer handles or tailgate outer
handle.

Locking the doors and tailgate

Touch the door lock sensor on the front door
or press the lock button on the tailgate.

u

Some exterior lights flash three times; all
the doors and tailgate lock; front door
outer handles pop in if they are popped
out; and the security system sets.

Using the Keyless Access System

1

Using the Keyless Access System

You can lock or unlock doors using the keyless access
system only when the power mode is in VEHICLE OFF.

Do not leave the keyless remote in the vehicle
when you get out. Carry it with you.

Even if you are not carrying the keyless remote, you
can lock/unlock the doors and the tailgate while
someone else with the remote is within range.

The door may be locked or unlocked if the door
handle is covered with water in heavy rain or in a
car wash if the keyless remote is within range.

If you grip a front door handle or touch a door lock
sensor wearing gloves, the door sensor may be
slow to respond or may not respond by locking or
unlocking the doors.

After locking the door, you have up to 2 seconds
during which you can pull the door handle to
confirm whether the door is locked. If you need to
unlock the door immediately after locking it, wait
at least 2 seconds before gripping the handle,
otherwise the door will not unlock.

The door may not open if you pull it immediately
after gripping the door handle. Grip the handle
again and confirm that the door is unlocked before
pulling the handle.

Even within the 80 cm (32 inches) radius, you may
not be able to lock/unlock the doors and the
tailgate with the keyless remote if it is above or
below the outside handle.

The keyless remote may not operate if it is too close
to the door and door glass.

a

Door Lock Sensor

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

176

Co
ntrols

Unlocking the doors and tailgate

When you walk to the vehicle while carrying
the keyless remote, front door outer handles
will automatically pop out.

The auto pop-out function activates when all
doors are locked, and the keyless remote is
within a 2 m (6.5 feet) radius of the outside
front door outer handles.

1

Using the Keyless Access System

If you do not open a door or the tailgate within 30
seconds of unlocking the vehicle, the doors and
tailgate will automatically relock and the front door
outer handle of the doors will automatically pop back
in.

If you lock the doors and then keep the keyless
remote within the detection range for more than 2
minutes, the auto pop-out function will be disabled.
If the function is disabled, pop out the handle
manually or use the unlock button on the keyless
remote.

a

Lock Button

Continued

177

uu

Locking and Unlocking the Doors

u

Locking/Unlocking the Doors from the Outside

Co
ntrols

Pushing out the front door outer handle
manually:

Push the front side inwards.

u

When the front door outer handle
doesn't pop-out automatically, push the
front side inwards.

Grab the front door outer handle:

u

All the doors and tailgate unlock.

u

Some exterior light flash once.

Press the tailgate outer handle:

u

The tailgate and all doors unlock.

u

Some exterior lights flash once.

u

Front door outer handles pop out.

2

Opening/Closing the Tailgate

 P. 187

a

Outer Handle

1

Using the Keyless Access System

If you walk away from the vehicle when the power
system is on, the auto pop-out function will not
work.

If you lock the doors and tailgate, and take the
keyless remote out of the 2 m (6.5 feet) detection
range and then bring it back into the range within 10
seconds, the auto pop-out function will not work. In
this case, pop out the door handle manually or use
the remote transmitter.
If, however, you bring the keyless remote back into
range after 10 seconds, the handles will
automatically pop out.

Front door outer handles will pop back in 30 seconds
after the driver's door is closed or when the
transmission is taken out of

(

P

.

If the vehicle is left for more than 8 days, the auto
pop-out function will not work. In this case, unlock
the vehicle using the remote transmitter.

If the front door outer handle is popped out and the
keyless remote is taken out of the 2 m (6.5 feet)
detection range, the handle will pop back in after 30
seconds.

The light flash settings and auto pop-out function
can be customized using the audio/information
screen.

2

How to Customize the Vehicle Settings



P. 336















Content      ..     9      10      11      12     ..
