Honda Ridgeline (2019 year). Instruction - part 25

384

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

See the previous message.

Text/Email

Read/Stop

(Existing a message list)

See the next message.

System reads received message aloud, or
stop message from being read.

Select Account

Select a mail or text message account.

Reply to a received message using one of six
fixed phrases.

Call

Make a call to the sender.

Reply

Continued

385

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To pair a cell phone (when there is no
phone paired to the system)

1. Select .
2. Select Phone.
3. Select Yes.
4. Make sure your phone is in search or

discoverable mode, then select Continue.

u

HFL automatically searches for a
Bluetooth® device.

5. Select your phone when it appears on the

list.

u

If your phone does not appear, you can
select Refresh to search again.

u

If your phone still does not appear, select
Phone Not Found and search for
Bluetooth® devices using your phone.
From your phone, search for
HandsFreeLink.

6. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

■

Phone Setup

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
the system before you can make and receive hands-
free calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to the system.

•

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and return to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.

: The phone is compatible with Bluetooth® Audio.

If there is an active connection to Apple CarPlay or
Android Auto, pairing of additional Bluetooth
compatible devices is unavailable and Add
Bluetooth Device is grayed out from the Bluetooth
device list screen.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

386

Features

■

To change the currently paired phone

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Bluetooth Device List.
3. Select a phone to connect.

u

HFL disconnects the connected phone
and starts searching for another paired
phone.

4. Select Connect

 ,

Connect

, or

Connect

.

■

To change the pairing code setting

1. Select .
2. Select Settings.
3. Select Bluetooth/Wi-Fi.
4. Select the Bluetooth tab.
5. Select Edit Pairing Code.

6. Select Random or Fixed.

1

To change the currently paired phone

If no other phones are found or paired when trying to
switch to another phone, HFL will inform you that the
original phone is connected again.

To pair other phones, select Add Bluetooth Device
from the Bluetooth device list screen.

1

To change the pairing code setting

The default pairing code is 0000 until you change the
setting.
To create your own, select Fixed, and delete the
current code, then enter a new one.

For a randomly generated pairing code each time you
pair a phone, select Random.

387

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To delete a paired phone

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Bluetooth Device List.
3. Select a phone you want to delete.

4. Select Delete.
5. A confirmation message appears on the

screen. Select Yes.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

388

Features

■

To turn on or off the text/e-mail
function

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select the Text/Email tab, then Enable

Text/Email.

u

A pop-up menu appears on the screen.

3. Select On or Off.

■

To turn on or off the text/e-mail notice

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select the Text/Email tab, then New

Message Notification.

u

A pop-up menu appears on the screen.

3. Select On or Off.

■

To Set Up Text/E-mail Message Options

1

To Set Up Text/E-mail Message Options

To use the text/e-mail message function, it may be
necessary to set up on your phone.

1

To turn on or off the text/e-mail notice

On: A pop-up notification comes on every time you
receive a new message.
Off: The message you receive is stored in the system
without notification.

Continued

389

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

You can change the ring tone setting.

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Ring Tone.
3. Select Fixed or Mobile Phone.

■

Ring Tone

1

Ring Tone

Fixed: The fixed ring tone sounds from the speakers.
Mobile Phone: Depending on the make and model
of the mobile phone, the ring tone stored in the
phone will sound if the phone is connected.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

390

Features

■

When Automatic Phone Sync is set to
On:

When your phone is paired, the contents of its
phonebook and call history are automatically
imported to the system.

■

Changing the Automatic Phone Sync
setting

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Automatic Phone Sync.

3. Select On or Off.

■

Automatic Import of Cellular Phonebook and Call History

1

Automatic Import of Cellular Phonebook and Call History

When you select a name from the list in the cellular
phonebook, you can see up to three category icons.
The icons indicate what types of numbers are stored
for that name.

On some phones, it may not be possible to import the
category icons to the system.

The phonebook is updated after every connection.
Call history is updated after every connection or call.

Home

Mobile

Work

Pager

Fax

Car

Other

Voice

Pref

Blank

Continued

391

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Up to 20 speed dial numbers can be stored per phone.

To store a speed dial number:
1. Go to the Phone menu screen.

2 Phone menu screen P. 383

2. Select Speed Dial.
3. Select New Entry.

From Import from Call History:

u

Select a number from the call history.

From Manual Input:

u

Input the number manually.

From Import from Phonebook:

u

Select a number from the connected cell
phone’s imported phonebook.

4. When the speed dial is successfully stored,

you are asked to create a voice tag for the
number. Select Yes or No.

5. Select Record to store a voice tag for the

speed dial entry.

u

Using the

 button, follow the prompts

to store a voice tag for the speed dial
entry.

■

Speed Dial

1

Speed Dial

When a voice tag is stored, press the

 button to

call the number using the voice tag. Say the voice tag
name.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

392

Features

■

To add a voice tag to a stored speed
dial number

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

u

From the pop-up menu, select Edit.

4. Select Voice Tag.

u

From the pop-up menu, select Record.

5. Select Record, or use the

 button and

follow the prompts to complete the voice
tag.

■

To delete a voice tag

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

u

From the pop-up menu, select Edit.

4. Select Voice Tag.

u

From the pop-up menu, select Clear.

5. A confirmation message appears on the

screen. Select Yes.

1

Speed Dial

Avoid using duplicate voice tags.
Avoid using “home” as a voice tag.
It is easier for the system to recognize a longer name.
For example, use “John Smith” instead of “John.”

393

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To edit a speed dial

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

u

From the pop-up menu, select Edit.

4. Select a setting you want.

■

To delete a speed dial

1. Go to the Phone settings screen.

2 Phone settings screen P. 380

2. Select Edit Speed Dial.
3. Select an existing speed dial entry.

u

From the pop-up menu, select Delete.

4. A confirmation message appears on the

screen. Select Yes.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

394

Features

Add phonetic modifications or a new voice tag to the phone’s contact name so that
it is easier for HFL to recognize voice commands.

■

To add a new voice tag

1. Select .
2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to add

phonetic modification to.

■

Phonebook Phonetic Modification

1

Phonebook Phonetic Modification

You can store up to 20 phonetic modification items.

395

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

7. Select New Voice Tag.
8. Select a contact name you want to add to.

u

The pop-up menu appears on the
screen.

9. Select Modify.

10. Using Record or the

 button, follow the

prompts to complete the voice tag.

11. You will receive a confirmation message

on the screen, then select OK.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

396

Features

■

To modify a voice tag

1. Select .
2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to modify

phonetic modification.

7. Select a contact name you want to

modify.

u

The pop-up menu appears on the
screen.

8. Select Modify.
9. Using Record or the

 button, follow the

prompts to complete the voice tag.

10. You will receive a confirmation message

on the screen, then select OK.

11. Select OK.

1

Phonebook Phonetic Modification

You can only modify or delete contact names for the
currently connected phone.

397

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To delete a modified voice tag

1. Select .
2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to delete

phonetic modification.

7. Select a contact name you want to delete.

u

The pop-up menu appears on the screen.

8. Select Delete.

u

The selected contact name has been
selected.

9. Select OK.

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

398

Features

■

To delete all modified voice tags

1. Select .
2. Select Settings.
3. Select System.
4. Select the Voice Recog tab.
5. Select Phonebook Phonetic

Modification.

6. Select the phone you want to delete

phonetic modification.

u

The contact name list appears.

7. Select Delete All.
8. You will receive a confirmation message on

the screen, then select Yes.

You can make calls by inputting any phone
number, or by using the imported
phonebook, call history, speed dial entries, or
redial.

■

Making a Call

1

Making a Call

Any voice-tagged speed dial entry can be dialed by
voice from most screens.

Press the

 button and say the voice tag name.

Once a call is connected, you can hear the voice of
the person you are calling through the audio
speakers.

While there is an active connection with Apple
CarPlay, phone calls cannot be made with
HandsFreeLink® and are only made from Apple
CarPlay.

399

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To make a call using the imported
phonebook

1. Go to the Phone menu screen.

2 Phone menu screen P. 383

2. Select Phonebook.
3. Select a name.

u

You can also search by letter. Select
Search.

u

Use the keyboard on the touch screen for
entering name, if multiple numbers exist
select a number.

4. Select a number.

u

Dialing starts automatically.

■

To make a call using a phone number

1. Go to the Phone menu screen.

2 Phone menu screen P. 383

2. Select Dial.
3. Select a number.

u

Use the keyboard on the touch screen for
entering numbers.

4. Select Dial.

u

Dialing starts automatically.

AAA

AAA
BBB

BBB
CCC

CCC

AAA
BBB
CCC
