Honda Pilot (2019 year). Instruction - part 18





271

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Phone

Displays the HFL information.

Bluetooth® HandsFreeLink® P. 479

Trip Computer

Displays the trip computer information.
• Current Drive tab: Displays the current trip information.
• Trip A/Trip B tab: Displays information for the current and three previous drives.

The information is stored every time you reset Trip A/B.
To reset Trip A/B, select Reset.
To change the setting of how to reset Trip A/B, select Settings, then select Trip
A Reset Method
 or Trip B Reset Method.

Clock

Displays the clock.

System Updates

Updates the software version of the audio system.

System Updates P. 284

FM/AM/Sirius XM

*

/CD

*

/USB/Bluetooth Audio/AUX Input/My Honda

Music/Social Playlist

Displays the each audio information.

Settings

Enters the customizing menu screen.

Customized Features P. 432

* Not available on all models

272

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

Navigation

*

Displays the navigation screen.

Refer to the Navigation System Manual

HondaLink

Displays the HondaLink® screen.

HondaLink® P. 333

Apple CarPlay/Android Auto

Displays the Apple CarPlay or Android Auto.

Apple CarPlay P. 341
Android Auto P. 344

Messages

Displays the text message screen.

Bluetooth® HandsFreeLink® P. 479

CabinTalk

*

Displays the CabinTalk screen.

CabinTalk

TM*

 P. 505

* Not available on all models

273

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Rear Entertainment

*

Displays the rear audio screen.

Blu-ray/DVD Rear Entertainment System

*

 P. 377

AT&T Hotspot

*

Displays the AT&T Hotspot screen.

File Manager

Displays the file manager screen.

File Manager P. 290

* Not available on all models

uu

Audio System Basic Operation

u

Audio/Information Screen

274

Features

You can change, store, and delete the wallpaper on the audio/information screen.

Import wallpaper

1. Connect the USB flash drive to the front

USB port.

USB Ports P. 245

2. Select Clock.
3. Select Settings.
4. Select Clock Faces.
5. Select Add More.

u

The File Manager screen is displayed.

6. Import a desired picture.

How to Transfer a File P. 290

u

The display will return to the Clock Faces
screen.

Wallpaper Setup

1

Wallpaper Setup

The wallpaper you set up on Clock Faces cannot be
displayed on the driver information interface.

The file name must be fewer than 255 characters.

The file format of the image that can be imported
is BMP, GIF, JPEG, PNG, or WebP.

If the USB flash drive does not have any pictures,
the No Data message appears.

275

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

Select wallpaper

1. Select Clock.
2. Select Settings.
3. Select Clock Faces.
4. Select a desired wallpaper.

u

The preview is displayed on the screen.

5. Select Save.

u

The display will return to the clock screen.

To view wallpaper once it is set

1. Select .
2. Select Clock.

Delete wallpaper

1. Select Clock.
2. Select Settings.
3. Select Clock Faces.
4. Select Delete Photos.

u

The File Manager screen is displayed.

5. Delete a picture.

How to Delete a File P. 293

u

The display will return to the Clock Faces screen.

uu

Audio System Basic Operation

u

Audio/Information Screen

276

Features

To change to a next screen

Selecting

 or

, or swiping the screen left or right changes to the next screen.

Home Screen

1

Home Screen

The home screen has 5 pages. You cannot add any
more pages.

Select

 to go directly back to the first page of the

home screen from any page.

Swipe

 Icon

>

 Icon

<

Current page position

<

>

Continued

277

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To add app icons on the home screen

App icons can be added on the home screen.

1. Select .
2. Select

All Apps.

3. Check the box of the app you want to add.

u

The app icon will be added on the home
screen.

1

To add app icons on the home screen

Pre-installed apps may not start up normally. If this
occurs, you need to reset the system.

Defaulting All the Settings P. 450

If you perform Factory Data Reset, it may reset all
the settings to their factory default.

Defaulting All the Settings P. 450

In case those apps still do not startup normally even
after Factory Data Reset, contact your dealer.

There is a possibility that a browser is shut down in
the situation of the use. In that situation, the screen
will return to before the browser startup.

Check Box

 All Apps

Icon

uu

Audio System Basic Operation

u

Audio/Information Screen

278

Features

To move icons on the home screen

You can change location on the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon to where you want

it to be.

3. Select Done.

u

The screen will return to the home
screen.

1

To move icons on the home screen

Select Tips to show tips. To hide them, select it again.

Select and hold.

Drag and drop.

Continued

279

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

To remove icons on the home screen

You can delete the icons on the home screen.

1. Select and hold an icon.

u

The screen switches to the customization
screen.

2. Drag and drop the icon you want to remove

to the Hide icon.

u

The icon is removed from the home
screen.

3. Select Done.

u

The screen will return to the home
screen.

1

To remove icons on the home screen

Apps will not be deleted by deleting the icon on the
home screen.

Select Tips to show tips. To hide them, select it again.

Select and hold.

Drag and drop to
Hide icon.

uu

Audio System Basic Operation

u

Audio/Information Screen

280

Features

To create shortcuts for apps displayed on the home screen

Three shortcut icons for accessing apps displayed on the home screen are displayed
in the upper left area of the screen. You can replace any of these shortcut icons with
an icon of your preference.

1. From the home screen, select and hold the

icon that you want to store in the upper left
of the screen.

u

The screen will switch to the
customization screen.

2. Drag the icon over to the upper left of the

screen and drop it over the icon that you
want to replace.

u

The new icon will appear in place of the
old icon.

3. Select Done.

u

The screen will return to the home
screen.

1

To create shortcuts for apps displayed on the home screen

Select Tips to show tips. To hide them, select it again.

Select and hold.

Drag and
drop to preset
icon.

Preset
Icons

281

uu

Audio System Basic Operation

u

Audio/Information Screen

Continued

Features

1. Select the system status icon.

u

The status area appears.

2. Select an item to see the details.
3. Select

 or the system status icon to close

the area.

Status Area

System
Status Icon

Status Area

uu

Audio System Basic Operation

u

Audio/Information Screen

282

Features

Some of the audio system’s apps can be updated wirelessly when connected via Wi-
Fi, or Bluetooth® in conjunction with the HondaLink® app installed on a compatible
iOS or Android device. If an update is available, a notification is displayed at the top
of the screen with the respective app’s update icon.

To update an app:

1. A notification appears and notifies you of a

update message on the header area.

2. Select the system status icon, and then

select the software update notification
from the list.

Updating Apps

1

Updating Apps

The wireless updates are for the apps on the audio
system only.

To update compatible apps on your iPhone or
Android phone, please visit the App Store or Google
Play Store, respectively.

283

uu

Audio System Basic Operation

u

Audio/Information Screen

Features

3. Select Download.

4. Select OK.

u

A notification appears on the screen if
the update is successful. Select OK.

u

Restart the engine for the update to be
applied.

284

uu

Audio System Basic Operation

u

System Updates

Features

System Updates

The audio system’s firmware can be updated with a Wi-Fi connection or with a USB
device.

Wireless connection mode setup

1. Select .
2. Select System Updates.
3. Select Settings.
4. Select Connection Setup.

5. Select Change Mode.
6. Select Network, then Save.

u

The display returns to the network list.

7. Select an access point from the network list,

then Connect.

u

If the audio system requires a password,
enter a password.

How to Update Wirelessly

1

Wireless connection mode setup

If your vehicle has a telematics control unit (TCU), you
do not need the wireless connection mode setup.

285

uu

Audio System Basic Operation

u

System Updates

Continued

Features

How to update

When the audio system update is available, the notification is shown on the audio/
information screen. Use the following procedure to update the system.

1. Select .
2. Select System Updates.

3. Select via Wireless.
4. Select Download Now.

u

A notification appears on the screen.

Notification

uu

Audio System Basic Operation

u

System Updates

286

Features

5. Select Install Now or Install while

Vehicle OFF.

u

A notification appears on the screen if
the update is successful.

1

How to update

If Install while Vehicle OFF is selected and the user
turns the vehicle back on after the update has been
completed, for 3 to 5 minutes the system will rebuild
the applications, during which time the Honda logo
will be displayed.
