Honda Pilot (2019 year). Instruction - part 11

159

Opening and Closing the Tailgate

Opening/Closing the Power Tailgate

Continued

Co
ntrols

Press the button on the tailgate to close the
power tailgate.

The beeper sounds.

If you press the button again while the power
tailgate is moving, it will stop. Press and
release the button again, and the power
tailgate will reverse direction.

■

Using the Tailgate Inner Button

Opening and Closing the Tailgate

Opening/Closing the Power Tailgate

160

Co
ntrols

If you manually close the power tailgate, it latches automatically.

Automatically lowers the power tailgate when there is a possibility that the fully
opened power tailgate can fall down by its own weight (for example, by snow on
the tailgate). The beeper sounds while the power tailgate lowers.

■

Auto-Closer

■

Power Tailgate Fall Detection

Auto-Closer

The auto-closer feature does not activate if you press
the tailgate outer handle while the power tailgate is
closing.

Do not put any force on the tailgate while the power
tailgate is latching.

Keep your hands away from the tailgate when you
manually close the tailgate and let it latch
automatically. It is dangerous to put your hands
around the tailgate as it starts to latch itself.

Power Tailgate Fall Detection

If you try to manually close the power tailgate
immediately after it fully opens, the power tailgate
fall detection may be activated.

Once the power tailgate fall detection activates, wait
until the power tailgate fully closes. Keep away from
the power tailgate when it is in motion.

If the power tailgate fall detection constantly
activates, consult at a dealer.

161

Opening and Closing the Tailgate

Opening/Closing the Tailgate

Continued

Co
ntrols

Opening/Closing the Tailgate

When all the doors are unlocked or press the
tailgate unlock button on the remote
transmitter, the tailgate is unlocked.
Press the tailgate outer handle and lift open
the tailgate.

If you are carrying the smart entry remote, you
do not have to unlock the tailgate before
opening it.

To close the tailgate, grab the inner handle,
pull the tailgate down, and push it closed
from outside.

■

Using the Tailgate Outer Handle

Using the Tailgate Outer Handle

Do not leave the key, remote transmitter, or smart
entry remote in the cargo area before closing the
tailgate.

Even if you are not carrying the smart entry remote,
you can lock/unlock the tailgate while someone else
with the remote is within range.

Models with smart entry system

Outer
Handle

Models with smart entry system

Inner Handle

Opening and Closing the Tailgate

Opening/Closing the Tailgate

162

Co
ntrols

Press the tailgate unlock button to unlock the
tailgate.

■

Using the Remote Transmitter

Using the Remote Transmitter

If you have unlocked and opened the tailgate using
the remote transmitter or smart entry remote, when
closing, the tailgate locks automatically.

Tailgate
Unlock
Button

163

Continued

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when pressing the ENGINE START/STOP button:
• Do not allow objects that emit strong radio waves near the ENGINE START/

STOP button.

• Make sure the key is not covered by or touching a metal object.
• Do not bring a key from another vehicle’s immobilizer system near the ENGINE

START/STOP button.

• Do not put the key near magnetic items. Electronic device, such as televisions and

audio systems emit strong magnetic fields. Note that even a key chain can
become magnetic.

Security System Alarm

The security system alarm activates when the tailgate, hood or doors are forcibly
opened. The alarm does not activate if the tailgate or doors are opened with the key,
remote transmitter or smart entry system

However, the alarm activates if a door is opened with the key and then the hood is
opened before the power mode is set to ON.

However, the alarm activates if a door is opened with the key and then the
transmission is taken out of

(

P or the hood is opened before the power mode set

to ON.

Immobilizer System

NOTICE

Leaving the key in the vehicle can result in theft or
accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

Security System Alarm

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

The security alarm continues for a maximum of two
minutes until the security system alarm deactivates.

Automatic transmission models with electronic gear selector

Automatic transmission models with shift lever

* Not available on all models

Security System

Security System Alarm

164

Co
ntrols

■

When the security system alarm activates

The horn sounds intermittently, and some exterior lights flash.

■

To deactivate the security system alarm

Unlock the vehicle using the key, remote transmitter or smart entry system

. The

system, along with the horn and flashing lights, is deactivated.

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The power mode is set to VEHICLE OFF (LOCK).
• The hood is closed.
• All doors and the tailgate are locked from outside with the key, remote

transmitter, or smart entry system

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system alarm is set.

■

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the remote
transmitter or smart entry system

, or the power mode is set to ON. The security

system alarm indicator goes off at the same time.

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab.

•

Opening the hood with the hood release.

•

Taking the transmission out of

(

If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the key, remote transmitter or
smart entry system

* Not available on all models

165

Security System

Security System Alarm

Co
ntrols

■

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

■

Canceling panic mode

Press any button on the remote transmitter, or
set the power mode to ON.

■

Panic Mode

Panic
Button

166

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors.

The driver’s side switches can be used to open and close all the windows. The power
window lock button on the driver’s side must be switched off (not pushed in,
indicator off) to open and close the windows from anywhere other than the driver’s
seat.

When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on if a
child is in the vehicle.

■

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

■

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Opening/Closing Windows with Auto-Open/Close Function

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF (LOCK).
Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it stops closing and reverse direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

ON
OFF

Power Window
Lock Button

Front Passenger’s
Window Switch

Driver’s Window
Switch

Indicator

167

Opening and Closing the Windows

Opening/Closing the Power Windows

Continued

Co
ntrols

To open: Push the switch down.
To close: Pull the switch up.

Release the switch when the window reaches
the desired position.

To open: Press the unlock button, and then
within 10 seconds, press it again and hold it.

If the windows and moonroof

stop midway,

repeat the procedure.

■

Opening/Closing Windows without Auto-Open/Close
Function

Open

■

Opening Windows and the Moonroof

with the Remote

Unlock
Button

* Not available on all models

168

Opening and Closing the Windows

Opening/Closing the Power Windows

Co
ntrols

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.

To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows/
moonroof

at the desired position. If you want

further adjustment, repeat the same
operation.

■

Opening/Closing Windows and the Moonroof

with the Key

Open

* Not available on all models

169

Co
ntrols

Moonroof

Opening and Closing the Moonroof

You can operate the moonroof when the power mode is in ON. Use the switch in
the front of the ceiling to open and close the moonroof.

■

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
push the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Tilting the moonroof up

To tilt: Push on the center of the moonroof
switch.
To close: Push the switch forward firmly, then
release.

■

Using the Moonroof Switch

Opening and Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you set the power mode to OFF.
Opening either front door cancels this function.

When resistance is detected, the auto reverse function
causes the moonroof to change directions, then stop.
Auto reverse stops sensing when the moonroof is
almost closed to ensure that it fully closes.

You can use the remote transmitter or the key to
operate the moonroof.

2 Opening Windows and the Moonroof

with the Remote P. 167

2 Opening/Closing Windows and the

Moonroof

with the Key P. 168

WARNING

Opening or closing the moonroof on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

Open

Tilt

Models without panoramic roof

Models with panoramic roof

Open

Tilt

* Not available on all models

170

Co
ntrols

Panoramic Roof

Opening/Closing the Sunshade

You can operate the sunshade when the power mode is in ON. Use the switch in the
front of the ceiling to open and close the sunshade.

■

Automatic operation

To open: Pull the switch back firmly.
To close: Push the switch forward firmly.

The sunshade automatically opens or closes all
the way. To stop the sunshade midway, touch
the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.
To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Using the Sunshade Switch

Opening/Closing the Sunshade

The sunshade can be operated for up to 10 minutes
after you set the power mode to OFF.
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the sunshade to change directions,
then stop. Auto reverse stops sensing when the
sunshade is almost closed to ensure that it fully
closes.

The sunshade can be opened or closed to adjust the
amount of light that enters the cabin.

WARNING

Opening or closing the sunshade on
someone’s hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the sunshade before opening or closing it.

Open

* Not available on all models

171

Continued

Co
ntrols

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

*1: Canadian models
*2: U.S. models

■

Changing the Power Mode

ENGINE START/STOP Button

ENGINE START/STOP Button Operating Range
You can start the engine when the smart entry
remote is inside the vehicle.

If the battery of the smart entry remote is getting
low, the engine may not start when you push the
ENGINE START/STOP button. If the engine does not
start, refer to the following link.

2 If the Smart Entry Remote Battery is Weak

P. 698

The engine may also run if the smart entry remote is
close to the door or window, even if it is outside the
vehicle.

ON mode:
The ENGINE START/STOP button is on (in red), if the
engine is running.

If the power mode does not change from VEHICLE
OFF to ACCESSORY, press the ENGINE START/STOP
button while moving the steering wheel left and
right. The steering wheel will unlock, allowing the
mode to change.

Operating Range

Canadian models

Automatic transmission models
with shift lever

Automatic transmission models
with electronic gear selector

VEHICLE OFF (LOCK)
The button is off.
The steering wheel is locked

The power to all electrical
components is turned off.

Press the button without the
transmission in

(

Press the button with the
transmission in

(

Press the button.

Without pressing
the brake pedal

ACCESSORY
The button blinks (in red).
Operate the audio system and
other accessories in this position.

ON
The button blinks (in red).
All electrical components can be
used.

Put the transmission into

(

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

172

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the transmission in

(

P and the

power mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid draining the battery.

When in this mode:
The steering wheel does not lock.
You cannot lock or unlock doors with the remote transmitter or the smart entry
system.

Press the ENGINE START/STOP button to switch the mode to VEHICLE OFF (LOCK).

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
beeper sounds.

■

Automatic Power Off

■

Power Mode Reminder

ENGINE START/STOP Button

Do not leave the power mode in ACCESSORY or ON
when you get out.

Canadian models

173

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

Co
ntrols

Warning buzzers may sound from inside and/
or outside the vehicle to remind you that the
smart entry remote is out of the vehicle. If the
buzzer continues even after the remote is put
back inside, place it to be within its
operational range.

■

When the power mode is in ON

If the smart entry remote is taken out of the
vehicle, and the driver’s door is closed, a
warning buzzer sounds from both inside and
outside the vehicle. A warning message on
the driver information interface notifies the
driver inside that the remote is outside of the
vehicle.

■

When the power mode is in
ACCESSORY

If the smart entry remote is taken out of the
vehicle, and all the doors are closed, a
warning buzzer sounds from outside the
vehicle.

■

Smart Entry Remote Reminder

Smart Entry Remote Reminder

When the smart entry remote is within the system’s
operational range, and the driver’s door is closed, the
warning function cancels.

If the smart entry remote is taken out of the vehicle
after the engine has been started, you can no longer
change the ENGINE START/STOP button mode or
restart the engine. Always make sure if the remote is
in your vehicle when you operate the ENGINE
START/STOP button.

Removing the smart entry remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the smart entry remote on the dashboard
or in the glove box. It may cause the warning buzzer
to go off. Under some other conditions that can
prevent the vehicle from locating the remote, the
warning buzzer may also go off even if the remote is
within the system’s operational range.

174

Operating the Switches Around the Steering Wheel

Turn Signals

Co
ntrols

Turn Signals

The turn signals can be used when the power
mode is in ON.

■

One-touch turn signal

When you lightly push up or down and release
the turn signal lever, the exterior turn signals
and turn signal indicator blink three times.
This feature can be used when signaling for a
lane change.

Right Turn

Left Turn

Content .. 9 10 11 12 ..
