To improve fuel economy, the engine stops and then restarts as detailed below. When Auto Idle Stop is on, the Auto Idle Stop indicator
(green) comes on.

(P545)

Automatic transmission

Engine status

Deceleration

Stop the vehicle and depress the brake
pedal.

Stop

Keep the brake pedal depressed.

Start-up

Release the brake pedal.

Off

Restarting

* Not available on all models

Quick

Referenc

e Guide

Eco Assist® System

Ambient Meter

● The color of the ambient meter changes

to green to indicate that the vehicle is
being driven in a fuel efficient manner.

ECON Button

(P550 )

Helps maximize fuel economy.

ECON Mode Indicator

(P89 )

Comes on when the ECON button is pressed.

The message is displayed for a few seconds when the
ECON button is pressed.

Quick

Referenc

e Guide

Safe Driving

(P33)

Airbags

(P47)

● Your vehicle is fitted with airbags to help protect you and

your passengers during a moderate-to-severe collision.

Child Safety

(P60)

● All children 12 and younger should be seated in the rear seat.

● Smaller children should be properly restrained in a forward-facing child seat.

● Infants must be properly restrained in a rear-facing child seat.

Exhaust Gas Hazard

(P76)

● Your vehicle emits dangerous exhaust gases that contain carbon

monoxide. Do not run the engine in confined spaces where carbon
monoxide gas can accumulate.

Before Driving Checklist

(P508)

● Before driving, check that the front seats, head restraints,

steering wheel, and mirrors have been properly adjusted.

Seat Belts

(P39)

● Fasten your seat belt and sit upright well

back in the seat.

● Check that your passengers are wearing

their seat belts correctly.

Fasten your lap belt as
low as possible.

Quick

Referenc

e Guide

Instrument Panel

(P79)

System Indicators

Malfunction Indicator

Lamp

Charging System

Indicator

Anti-lock Brake System

(ABS) Indicator

Vehicle Stability Assist®

(VSA®) System

Indicator

VSA® OFF Indicator

Low Tire Pressure/

TPMS Indicator

Immobilizer System

Indicator/Security

System Alarm Indicator

Lights Indicators

Lights On Indicator

High Beam Indicator

Fog Light Indicator

Lane Keeping Assist
System (LKAS)
Indicator (Green/
Amber)

Seat Belt Reminder

Indicator

System Indicators

Econ Mode Indicator

System Message

Indicator

Parking Brake and
Brake System Indicator
(Red)

Supplemental

Restraint System

Indicator

Driver Information Interface

Tachometer

M (Sequential mode) Indicator/
Sequential Mode Gear Selection Indicator

Speedometer

Fuel Gauge

Gear Position Indicator/

Transmission System

Indicator

Auto Idle Stop System

Indicator (Amber)

Auto Idle Stop

Indicator (Green)

Gauges

(P110)

/Driver Information Interface

(P111)

/System

Indicators

(P80)

Adaptive Cruise

Control (ACC)

Indicator (Green/

Amber)

Turn Signal and

Hazard Warning

Indicators

Electric Power Steering

(EPS) System Indicator

Blind spot information

System Indicator

Temperature Gauge

Parking Brake and
Brake System Indicator
(Amber)

U.S.

Canada

System Indicators

U.S.

Canada

Low Fuel Indicator

Auto High-Beam

Indicator

Road Departure

Mitigation (RDM)

Indicator

Collision Mitigation
Braking System

(CMBS

) Indicator

All-wheel drive

system (AWD)

Indicator

Intelligent Traction
Management
Indicator

Quick

Referenc

e Guide

Controls

(P135)

Clock

(P136)

Press and hold the MENU/CLOCK
button for two seconds.

Select Adjust Clock, then press

Rotate

to adjust the hours.

Press

to switch to minute

adjustment.

Rotate

to adjust the minutes.

Press

to switch to Set.

Press

to complete clock adjustment.

Models with color audio system

These indications are used to show how to
operate the selector knob.
● Rotate

to select.

● Press

enter.

To adjust time

To adjust date

Select

, then select Settings.

Select System, then Date & Time.

Select Set Date & Time.

Models with Display Audio

Select Automatic Date & Time, then
select OFF.

Select Set Date or Set Time.

Adjust the dates, hours and minutes by
selecting /

Select Save to set the time.

The navigation system receives signals from
GPS satellites, updating the clock
automatically.

ENGINE START/STOP
Button

(P171)

Press the button to change the vehicle’s
power mode.

3 4

Models with navigation system

* Not available on all models

Quick

Referenc

e Guide

Turn Signals

(P174)

Lights

(P175)

Turn Signal Control Lever

Right

Left

Light Control Switches

Low Beam

High Beam

Flashing

Wipers and Washers

(P183)

*1:Models with automatic intermittent

wipers

*2:Models without automatic intermittent

wipers

Wiper/Washer Control Lever

MIST
OFF
AUTO

: Wiper speed varies

automatically
INT

: Low speed with

intermittent
LO: Low speed wipe
HI: High speed wipe

Pull toward
you to spray
washer fluid.

Adjustment Ring
Low Sensitivity

Lower speed, fewer sweeps

High Sensitivity

Higher speed, more sweeps

(

- :

(

AUTO should always be turned OFF before
the following situations in order to prevent
severe damage to the wiper system:
● Cleaning the windshield

● Driving through a car wash

● No rain present

Steering Wheel

(P191)

● To adjust, push the adjustment lever

down, adjust to the desired position, then
pull up the lever back in place.

Models with automatic intermittent wipers
