Honda Odyssey (2019 year). Instruction

192

Operating the Switches Around the Steering Wheel

Fog Lights

Co
ntrols

Fog Lights

When the low beam headlights are on, turn
the fog light switch on to use the fog lights.

When the fog lights are on, the indicator in the
instrument panel will be on.
They go off when the headlights turn off, or when
the daytime running lights are on.

2 Fog Light Indicator

P. 93

Fog Light Switch

* Not available on all models

193

Operating the Switches Around the Steering Wheel

Daytime Running Lights

Co
ntrols

Daytime Running Lights

When the conditions listed below are met, the daytime running lights come on:
• The power mode is in ON.
• The headlight switch is off.
• The parking brake is released.

The lights remain on even if you set the parking brake. Setting the power mode to
VEHICLE OFF will turn off the daytime running lights.

The daytime running lights go off once the headlight switch is turned on, or when
the headlight switch is in AUTO

and it is getting dark outside.

The high beam headlights return to the original brightness once the headlight
switch is turned on.

Daytime Running Lights

The parking lights serve as daytime running lights.

The high beam headlights come on slightly dimmer
than normal to serve as daytime running lights.

Models with fog lights

Models without fog lights

* Not available on all models

194

Operating the Switches Around the Steering Wheel

Auto High-Beam

Co
ntrols

Auto High-Beam

Using a camera mounted to the inside of the windshield, this system detects light
sources ahead of the vehicle. Depending on the light source, the system
automatically switches the headlights to high beam for optimal visibility at night.

Auto High-Beam

The auto high-beam determines when to change the
headlight beams by responding to the brightness of
the lights ahead of your vehicle. In the following
cases, the system may not respond to the lights
properly:

•

The brightness of the lights from the preceding or
oncoming vehicle is intense or poor.

•

Visibility is poor due to the weather (rain, snow,
fog, windshield frost, etc.).

•

Other light sources, such as street lights and
electric billboards are illuminating the road ahead.

•

The brightness level of the road ahead constantly
changes.

•

The road is bumpy or with many curves.

•

A vehicle cuts in front of you, or a vehicle in front
of you is not in the preceding or oncoming
direction.

•

Your vehicle is tilted with a heavy load in the rear.

If you find the timing of beam changes inconvenient
for driving, change the headlight beams manually.

If you do not want the system to be activated at any
time when the headlight switch is in AUTO, consult a
dealer or disable the system.

2 Disabling or Re-enabling the System P. 196

■

The headlight switch is in AUTO.

■

The lever is in the low beam
position.

■

The low beams are on and the
system recognizes that you are
driving at night.

■

The vehicle speed is above 45 mph
(72 km/h).

The system operates when:

When the camera detects lights coming from a preceding or oncoming vehicle, the
headlights remain in low beam.

When the camera detects no lights coming from a preceding or oncoming vehicle,
the headlights change to high beam.

The view angle or distance that the camera can detect lights ahead differs
depending on conditions, such as the brightness of the lights and the weather.

How it works

* Not available on all models

Continued

195

Operating the Switches Around the Steering Wheel

Auto High-Beam

Co
ntrols

To activate the system, turn the headlight
switch to AUTO and then set the headlights
to low beam. The auto high-beam indicator
will come on.

2 Light Switches P. 189

The high beams remain on unless:
• You have been driving below 45 mph (72 km/h) for an extended amount of time.
• The speed of the vehicle drops below 30 mph (48 km/h).
• The windshield wipers have been running at a high speed for more than a few

seconds.

• You enter a well lit location.

The high beams come back on once the condition that caused them to turn off no
longer exists.

If needed, you can temporarily turn the high beams off manually. Turn on the high
beams by pushing the lever forward until you hear a click, or flash the high beams
once by pulling the lever toward you. To turn the high beams back on, repeat one
of the procedures.

■

Operating the System

Operating the System

For the auto high-beam to work properly:

•

Do not place an object that reflects light on the
dashboard.

•

Keep the windshield around the camera clean.
When cleaning the windshield, be careful not to
apply windshield cleanser to the camera lens.

•

Do not attach an object, sticker or film to the area
around the camera.

•

Do not touch the camera lens.

If the camera receives a strong impact, or repairing of
the area near the camera is required, consult a dealer.

If the Some Driver Assist Systems Cannot
Operate: Camera Temperature Too High message
appears:

•

Use the climate control system to cool down the
interior and, if necessary, also use defroster mode
with the airflow directed toward the camera.

•

Start driving the vehicle to lower the windshield
temperature, which cools down the area around
the camera.

If the Some Driver Assist Systems Cannot
Operate: Clean Front Windshield message
appears:

•

Park your vehicle in a safe place, and clean the
windshield. If the message does not disappear after
you have cleaned the windshield and driven for a
while, have your vehicle checked by a dealer.

Headlight Switch

Operating the Switches Around the Steering Wheel

Auto High-Beam

196

Co
ntrols

Disable or re-enable the system when the
vehicle is parked and the power mode is in ON
and the light switch is in the AUTO position.
Disabling the system: Pull the light switch
lever toward you and hold it for at least 40
seconds. The auto high-beam indicator in the
meter will blink twice.
Re-enabling the system: Pull the light
switch lever toward you and hold it for at least
30 seconds. The auto high-beam indicator in
the meter will blink once.

■

Disabling or Re-enabling the System

Disabling or Re-enabling the System

The auto high-beam is in the previously selected
disabled or re-enabled setting each time you start the
engine.

197

Operating the Switches Around the Steering Wheel

Wipers and Washers

Continued

Co
ntrols

Wipers and Washers

The windshield wipers and washers can be
used when the power mode is in ON.

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT

/AUTO

, LO,

HI)

Move the lever up or down to change the
wiper settings.

■

Adjusting wiper operation

Turn the adjustment ring to adjust wiper
operation.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever for more than one
second, the spray stops, the wipers sweep two
or three more times to clear the windshield,
then stop.

*1: Models with manual intermittent operation
*2: Models with automatic intermittent operation

■

Windshield Wiper/Washer

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

In cold weather, the blades may freeze to the
windshield.
Operating the wipers in this condition may damage
the wipers. Use the defroster or heated windshield

to warm the windshield, then turn the wipers on.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens.
When the vehicle speeds up, the wiper operation’s
shortest delay setting ( ) and the LO setting become
the same.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

Models with intermittent time adjustment ring

Intermittent Time
Adjustment Ring

MIST

INT

/AUTO

OFF

LO: Low speed wipe

HI: High speed wipe

Pull to
use
washer.

Lower speed, fewer sweeps

Higher speed, more sweeps

* Not available on all models

Operating the Switches Around the Steering Wheel

Wipers and Washers

198

Co
ntrols

When you push the lever down to AUTO, the
windshield wipers sweep once, and go into
the automatic mode.

The wipers operate intermittently, at low
speed, or at high speed and stops in
accordance with the amount of rainfall the
rainfall sensor detects.

■

AUTO sensitivity adjustment

When the wiper function is set to AUTO, you
can adjust the sensitivity of the rainfall sensor
(using the adjustment ring) so that wipers will
operate in accordance with your preference.

Sensor sensitivity

■

Automatic Intermittent Wipers

Wipers and Washers

If the wiper stops operating due to any obstacle such
as the build-up of snow, park the vehicle in a safe
place.
Rotate the wiper switch to OFF, and set the power
mode to ACCESSORY or VEHICLE OFF, then remove
the obstacle.

The wiper motor may stop motor operation
temporarily to prevent an overload. Wiper operation
will return to normal within a few minutes, once the
circuit has returned to normal.

Automatic Intermittent Wipers

The rainfall sensor is in the location shown below.

AUTO should always be turned OFF before the
following situation in order to prevent severe damage
to the wiper system:

•

Cleaning the windshield

•

Driving through a car wash

•

No rain present

Rainfall Sensor

Adjustment Ring

Low Sensitivity

High Sensitivity

* Not available on all models

199

Operating the Switches Around the Steering Wheel

Wipers and Washers

Co
ntrols

The rear wiper and washer can be used when
the power mode is in ON.

■

Wiper switch (OFF, INT, ON)

Change the wiper switch setting according to
the amount of rain.

■

Washer (

)

Sprays while you rotate the switch to this
position.
Hold it to activate the wiper and to spray the
washer. Once released, it stops operating
after a few more sweeps.

■

Operating in reverse

When you shift the transmission to

(

R with the windshield wiper activated, the rear

wiper operates automatically as follows even if its switch is off.

■

Rear Wiper/Washer

ON: Continuous wipe

Washer

OFF

INT: Intermittent

Front Wiper Position

Rear Wiper Operation

INT (Intermittent)

Intermittent

LO (Low speed wipe)
HI (High speed wipe)

Continuous

200

Operating the Switches Around the Steering Wheel

Brightness Control

Co
ntrols

Brightness Control

When the power mode is in ON, you can use
the brightness control knob to adjust
instrument panel brightness.
Brighten: Turn the knob to the right.
Dim: Turn the knob to the left.

You will hear a beeper when the brightness
reaches minimum or maximum. Several
seconds after you have adjusted the
brightness, you will be returned to the
previous screen.

■

Brightness level indicator

The brightness level is shown on the driver
information interface while you are adjusting
it.

Brightness Control

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

To cancel the reduced instrument panel brightness
when the exterior lights are on, turn the knob to the
right until the brightness display is up to max, the
beeper sounds.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

Control Knob

201

Operating the Switches Around the Steering Wheel

Rear Defogger/Heated Door Mirror

Button

Co
ntrols

Rear Defogger/Heated Door Mirror

Button

Press the rear defogger and heated door
mirror button to defog the rear window and
mirrors when the power mode is in ON.

The rear defogger and heated door mirrors
automatically switch off after 10-30 minutes
depending on the outside temperature.

However, if the outside temperature is 32°F
(0°C) or below, they do not automatically
switch off.

Rear Defogger/Heated Door Mirror

Button

This system consumes a lot of power, so turn it off
when the window has been defogged.
Also, do not use the system for a long time while the
engine is idling. This may weaken the battery, making
it difficult to start the engine.

When the outside temperature is below 41°F (5°C),
the heated door mirror may activate automatically for
10 minutes when you set the power mode to ON.

Models with tri-zone climate control
system

Models with dual-zone climate control
system

* Not available on all models

202

Operating the Switches Around the Steering Wheel

Heated Windshield Button

Co
ntrols

Heated Windshield Button

Press the heated windshield button to deice
the windshield when the power mode is in
ON.

Canadian models

Heated Windshield Button

This system consumes a lot of power, so turn it off
when the window has been deiced. Also, do not use
the system for a long period when the engine is
idling. This may weaken the battery, making it
difficult to start the engine.

When the outside temperate is below 39°F (4°C), the
heated windshield may automatically activate. The
system deactivates itself once the outside temperate
reaches 43°F (6°C).

203

Operating the Switches Around the Steering Wheel

Driving Position Memory System

Continued

Co
ntrols

Driving Position Memory System

You can store two driver’s seat positions (except for power lumbar) and outside
mirror positions with the driving position memory system.
When you unlock and open the driver’s door with a remote, the seat and outside
mirrors adjust automatically to one of the two preset positions.

When you enter the vehicle, the driver information interface briefly shows you which
remote transmitter you used to unlock the vehicle.
• DRIVER 1 transmitter is linked to memory button 1.
• DRIVER 2 transmitter is linked to memory button 2.

The driver’s seat moves rearward depending
on the set seating position once you
• Stop the vehicle.
• Put the transmission in

(

• Set the power mode to VEHICLE OFF.
• Then open the driver’s door.
Once the power mode is in the ACCESSORY
position, the driver’s seat moves to the
DRIVER 1 or 2 preset position.

Driving Position Memory System

Using the audio/information screen, you can disable
the automatic seat and door mirrors adjustment
function.

2 Customized Features P. 443

The driver’s seat easy exit feature:

•

Will move rearward to allow you to more easily exit
the vehicle.

•

Can be turned on or off.

2 Customized Features P. 443

System Operation
The system will not operate if:

•

The vehicle speed is above 2 mph (3 km/h).

•

Either memory position button is pressed while the
seat is in motion.

•

The seat position is adjusted while in operation.

•

The memory 1 or 2 position is set fully to the rear.

DRIVER 1

DRIVER 2

* Not available on all models

Operating the Switches Around the Steering Wheel

Driving Position Memory System

204

Co
ntrols

1. Set the power mode to ON. Adjust the

driver’s seat and the door mirrors to the
desired position.

2. Press the SET button.

You will hear the beeper, and the
memory button indicator light will blink.

3. Press and hold memory button

(

1 or

(

within five seconds of pressing the SET
button.

Once the seat and the outside mirrors
position has been memorized, the
indicator light on the button you pressed
stays on.

1. Change to

(

2. Apply the parking brake.
3. Press a memory button (

(

1 or

(

2).

You will hear the beeper, and the
indicator light will blink.

The seat and the door mirrors will
automatically move to the memorized
position. When it has finished moving, you
will hear the beeper, and the indicator light
stays on.

■

Storing a Position in Memory

Storing a Position in Memory

After you press the SET button, the storing operation
will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat and door mirrors position
before the double-beep.

•

You set the power mode to any position except
ON.

Memory
Button 1

Memory
Button 2

SET Button

■

Recalling the Stored Position

Recalling the Stored Position

The seat and the door mirrors will stop moving if you:

•

Press the SET button or memory button

(

1 or

(

•

Adjust the seat position or door mirrors.

•

Put the transmission into a position other than

(

Memory
Button 1

Memory
Button 2

SET Button

205

Operating the Switches Around the Steering Wheel

Adjusting the Steering Wheel

Co
ntrols

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

1. Push the steering wheel adjustment lever

down.

The steering wheel adjustment lever is
under the steering column.

2. Move the steering wheel up or down, and

in or out.

Make sure you can see the instrument
panel gauges and indicators.

3. Pull the steering wheel adjustment lever up

to lock the steering wheel in position.

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

Adjusting the Steering Wheel

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

To adjust

To lock

Lever

206

Co
ntrols

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct driving
position.

Flip the tab to switch the position.
The night position will help to reduce the glare
from headlights behind you when driving
after dark.

When you are driving after dark, the
automatic dimming rearview mirror reduces
the glare from headlights behind you. Press
the auto button to turn this function on and
off. When activated, the auto indicator comes
on.

■

Rearview Mirror with Day and Night Positions

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2 Front Seats P. 209

Tab

Daytime
Position

Night Position

Down

■

Automatic Dimming Rearview Mirror

Automatic Dimming Rearview Mirror

The auto dimming function cancels when the
transmission is in

(

Sensor

Auto Button

* Not available on all models

207

Adjusting the Mirrors

Power Door Mirrors

Continued

Co
ntrols

Power Door Mirrors

You can adjust the door mirrors when the
power mode is in ON.

■

Mirror position adjustment

L/R selector switch: Select the left or right
mirror. After adjusting the mirror, return the
switch to the center position.
Mirror position adjustment switch: Press
the switch left, right, up, or down to move the
mirror.

■

Folding door mirrors

Press the folding button to fold in and out the
door mirrors.

Selector
Switch

Adjustment
Switch

Folding
Button

* Not available on all models

Honda Odyssey (2019 year). Instruction - part 13
