Honda Crosstour (2015 year). Instruction - part 10

144

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box. You
can lock the glove box with the master key or
the built-in key.

■

Glove Box

1

Glove Box

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

To Lock

145

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Pull the handle to open the console
compartment.

■

Removable tray

The tray in the console compartment is
detachable.

To remove this tray, slide it forward, then pull
it up.

■

Console Compartment

Removable Tray

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

146

Co
ntrols

■

Front seat beverage holders

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Continued

147

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The accessory power sockets can be used when the ignition switch is in ACCESSORY

(

q or ON

(

w

*1

.

■

Accessory power socket (console panel)

Open the cover to use it.

■

Accessory power socket (console
compartment)

Open the console lid and the cover to use it.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.

The accessory power socket is designed to supply
power for 12 volt DC accessories that are rated 120
watts or less (10 amps).

To prevent battery drain, only use the power socket
with the engine running.

When each sockets is being used simultaneously, the
combined power rating of the accessories should not
exceed 120 watts (10 amps).

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

148

Co
ntrols

■

Accessory power socket (cargo area)

Open the cover to use it.

There is a coat hook on the rear left grab
handle. Pull it down to use it.

■

Coat Hook

1

Coat Hook

The coat hook is not designed for large or heavy
items.

Continued

149

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

Use floor cargo hooks to secure luggage in the
cargo area.

There are also hooks on both sides of the
cargo area.

■

Cargo Hooks

1

Cargo Hooks

Each hook is designed to hold up to 56.2 lbs (25.5 kg)
of weight.

Hooks

Hooks

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

150

Co
ntrols

Pull the handle to open the cargo floor lid.
The reverse side of the cargo floor lid is water-
proofed. Flip the lid to use the water-proofed
side.

■

To keep the lid open:

1. Remove the hook from the back of the

cargo floor lid.

2. Pull the hook to the hole on the side panel.

■

Removable box

The removable box is under the cargo floor.

To remove the box, lift it up with the straps on
both sides.

■

Under-floor Storage Area

1

Under-floor Storage Area

NOTICE

Do not put objects that weigh more than 22.1 lbs (10
kg) in the removable box. Exceeding the maximum
load may damage the box.

Do not leave water, soil, sand, or perishable foods in
the removable box. Rotting food and dirt on the floor
may cause the breakdown of electrical equipment.

Strap

151

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Co
ntrols

Pull the strap to raise the lid.

The reverse side of each lid is water-proofed.
Flip the lids, then replace each other side.

■

Side Storage Compartments

Strap

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

152

Co
ntrols

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

Pull the lid to open the pocket.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

■

Center Pocket(s)

*

* Not available on all models

153

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Co
ntrols

The ignition switch must be in ON

(

w

*1

 to use

the seat heaters. The HI setting heats the seats
faster than the LO setting.

There is no heater in the passenger’s seat-
back due to the side airbag cutoff system.

While in HI, the heater cycles on and off.

u

The appropriate indicator will be on
while the seat heater is on. Briefly press
the switch on the opposite side to turn
the heater off. The indicator will be off.
When a comfortable temperature is
reached, select LO to keep the seat
warm.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Seat Heaters

*

1

Seat Heaters

*

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

In the LO setting, the heater runs continuously and
does not automatically turn off.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

154

Co
ntrols

Heating and Cooling System

*

Using Vents, Heating and A/C

Mode Buttons
Change airflow.

Floor and defroster vents
Floor vents
Dashboard, floor and back of the center console vents
Dashboard and back of the center console vents

Fan Control Dial
Adjusts the fan speed.
Rotate the dial all the
way to OFF to turn
everything off.

 Button

Turns on the A/C, selects airflow from the
dashboard and back of the center console vents,
and switches the mode to recirculation.

A/C Button
Press to cool the interior or
dehumidify while heating.

Windshield Defroster Button
Turns on the A/C, selects airflow from
the defroster vents at the base of the
windshield, and switches the mode to
fresh air.

Temperature
Control Dial
Adjusts the interior
temperature.

 (Recirculation) Button

Press the

 button and switch the mode

depending on environmental conditions.

Recirculation Mode (indicator on):
Recirculates air from the vehicle’s interior through
the system.

Fresh Air Mode (indicator off):
Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

* Not available on all models

Continued

155

uu

Heating and Cooling System

*

u

Using Vents, Heating and A/C

Co
ntrols

The heater uses heat from the engine coolant
to warm the air.
1. Adjust the fan speed using the fan control

dial.

2. Select .
3. Adjust the temperature using the

temperature control dial.

■

To rapidly warm up the interior

1. Set the fan to the maximum speed.
2. Select .
3. Set the temperature to maximum warm.
4. Press the

 button (the indicator on).

■

To dehumidify the interior

When used in combination with the heater, the air conditioning system makes the
interior warm and dry and can prevent the windows from fogging up.
1. Adjust the fan speed using the fan control dial.
2. Press the A/C button to turn on the air conditioning.
3. Select .
4. Adjust the temperature using the temperature control dial.

■

Heating

1

Heating

When you select

, the mode automatically

switches to fresh air.

1

To rapidly warm up the interior

Change to fresh air mode as soon as the interior gets
warm enough. The windows may fog up if kept in
recirculation mode.

uu

Heating and Cooling System

*

u

Using Vents, Heating and A/C

156

Co
ntrols

1. Adjust the fan speed using the fan control

dial.

2. Select .
3. Adjust the temperature using the

temperature control dial.

4. Press the A/C button (the indicator on).

■

To rapidly cool down the interior

1. Set the fan to the maximum speed.
2. Set the temperature to maximum cool.
3. Press the

 button (the indicator on).

Pressing the

 button turns the air

conditioning system on and automatically
switches the system to fresh air mode.

■

To rapidly defrost the windows

1. Set the fan to the maximum speed.

2. Press the

 button.

3. Press the

 button (the indicator on).

4. Set the temperature to maximum heat.

■

Cooling

1

To rapidly cool down the interior

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows.

■

Defrosting the Windshield and Windows

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.
Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.
If the side windows fog up, adjust the vents so that
the air hits the side windows.

1

To rapidly defrost the windows

After defrosting the windows, switch over to fresh air
mode.
If you keep the system in recirculation mode, the
windows may fog up from humidity. This impedes
visibility.

157

Continued

Co
ntrols

Climate Control System

*

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select. The system also selects the proper mix of heated or
cooled air that raises or lowers the interior temperature to your preference as quickly as possible.

Floor and
defroster vents

Floor vents

Dashboard, floor
and back of the
center console vents

Dashboard and
back of the center
console vents

AUTO Button

Driver’s Side
Temperature
Control Switch

Passenger’s Side
Temperature
Control Switch

 /

 (Fan Control)

Buttons

 (Recirculation)

Button

A/C (Air Conditioning)
Button

Models without audio/information screen

Floor and
defroster vents

Floor vents

Dashboard, floor
and back of the
center console vents

Dashboard and
back of the center
console vents

AUTO
Button

Driver’s Side
Temperature
Control Switch

 (Recirculation)

Button

 /

 (Fan Control)

Buttons

A/C (Air Conditioning)
Button

Passenger’s Side
Temperature
Control Switch

Models with audio/information screen

* Not available on all models

uu

Climate Control System

*

u

Using Automatic Climate Control

158

Co
ntrols

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side control

switch.

3. Press the

 (On/Off) button to cancel.

■

Switching between the recirculation and fresh air modes

Press the

 (recirculation) button and switch the mode depending on

environmental conditions.
Recirculation Mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh Air Mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in auto, the function of the button
that was pressed will take priority.
The AUTO indicator will go off, but functions
unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Pressing the

 button switches the climate

control system between on and off. When turned on,
the system returns to your last selection.

Continued

159

uu

Climate Control System

*

u

Using Automatic Climate Control

Co
ntrols

Pressing the

 button turns the air

conditioning system on and automatically
switches the system to fresh air mode.

Pressing the

 button again to turn off, the

system returns to the previous settings.

■

Defrosting the Windshield and Windows

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.
When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

Models without audio/
information screen

Models with audio/
information screen
