272

uu

Audio System Basic Operation

u

HondaLink®

Features

You can check the messages that are received quickly in the shortcut operation.

1. A message appears and notifies you of a

new message on the header area.

u

When the message is received, a
notification ring can be heard.

2. A message icon is continuously displayed in

the header area until the new message is
read.

■

Vehicle Information and Message from Honda Tips

Message
Icon

273

uu

Audio System Basic Operation

u

HondaLink®

Features

3. From the top of the screen, swipe down to

see the messages.

4. Select a new message to open.

274

uu

Audio System Basic Operation

u

Wi-Fi Connection

Features

Wi-Fi Connection

You can connect the Display Audio to the Internet using Wi-Fi and browse websites
or use online services on the audio/information screen. If your phone has wireless
hotspot capabilities, the system can be tethered to the phone. Use the following
steps to setup.

1. Select .
2. Select Settings.
3. Select Bluetooth/Wi-Fi.
4. Select the Wi-Fi tab.
5. Select Wi-Fi On/Off Status, then On.
6. Select Wi-Fi Device List.

u

Make sure your phone’s Wi-Fi setting is
in access point (tethering) mode.

u

Select the phone you want to connect to
the system.

u

If you do not find the phone you want to
connect in the list, select Scan.

7. Select Connect.

u

If needed, enter a password for your
phone and select OK.

u

When the connection is successful, the

 icon is displayed on the top of the

screen.

8. Select

 to go back to the home screen.

■

Wi-Fi mode (setting for the first time)

1

Wi-Fi mode (setting for the first time)

You cannot go through the setting procedure while a
vehicle is moving. Park in a safe place to setup the
Wi-Fi connection.

Some cell phone carriers charge for tethering and
smartphone data use. Check your phone’s data
subscription package.

Check your phone manual to find out if the phone
has Wi-Fi connectivity.

You can confirm whether Wi-Fi connection is on or
off with the

 icon on Wi-Fi Device List. Network

speed will not be displayed on this screen.

12ᾉ34

AAAAA

BBBBB
CCCCC
DDDDD
EEEEE

275

uu

Audio System Basic Operation

u

Wi-Fi Connection

Features

Make sure your phone's Wi-Fi setting is in access point (tethering) mode.

■

Wi-Fi mode (after the initial setting has been made)

1

Wi-Fi mode (after the initial setting has been made)

You may need to go through an initial setup for Wi-Fi
connection again after you boot your phone.

iPhone users

276

uu

Audio System Basic Operation

u

Siri Eyes Free

Features

Siri Eyes Free

You can talk to Siri using the

 (Talk) button on the steering wheel when your

iPhone is paired to the Bluetooth® HandsFreeLink® (HFL) system.

2 Phone Setup P. 343

■

Using Siri Eyes Free

1

Siri Eyes Free

Siri is a trademark of Apple Inc.

Check Apple Inc. website for features available for
Siri.

We recommend against using Siri other than in Siri
Eyes Free while operating a vehicle.

1

Using Siri Eyes Free

Some commands work only on specific phone
features or apps.

 (Talk) Button

Press and hold until the display
changes as shown.

 (Hang-up/back) Button

Press to deactivate Siri Eyes Free.

While in Siri Eyes Free:
The display remains the same.
No feedback or commands
appear.

Appears when Siri is activated
in Siri Eyes Free

277

uu

Audio System Basic Operation

u

Apple CarPlay

Continued

Features

Apple CarPlay

If you connect an Apple CarPlay-compatible iPhone to the system via the 1.5A USB
port, you can use the audio/information screen, instead of the iPhone display, to
make a phone call, listen to music, view maps (navigation), and access messages.

2 USB Ports P. 205

■

Phone

Access the contact list, make phone calls, or listen to voice mail.

■

Messages

Check and reply to text messages, or have messages read to you.

■

Music

Play music stored on your iPhone.

■

Apple CarPlay Menu

1

Apple CarPlay

Only iPhone 5 or newer versions with iOS 8.4 or later
are compatible with Apple CarPlay.

Park in a safe place before connecting your iPhone to
Apple CarPlay and when launching any compatible
apps.

To use Apple CarPlay, connect the USB cable to the
USB port (1.5A). The USB port (1.0A) will not enable
Apple CarPlay operation.

2 USB Ports P. 205

To directly access the Apple CarPlay phone function,
press Phone on the home screen. While connected
to Apple CarPlay, calls are only made through Apple
CarPlay. If you want to make a call with Bluetooth®
HandsFreeLink®, turn Apple CarPlay OFF or detach
the USB cable from your iPhone.

2 Setting Up Apple CarPlay P. 278

When your iPhone is connected to Apple CarPlay, it is
not possible to use the Bluetooth® Audio or
Bluetooth® HandsFreeLink®. However, other
previously paired phones can stream audio via
Bluetooth® while Apple CarPlay is connected.

2 Phone Setup P. 343

For details on countries and regions where Apple
CarPlay is available, as well as information pertaining
to function, refer to the Apple homepage.

: Select the Honda
icon to go back to
the Home screen

Home screen

Apple CarPlay icon

Apple CarPlay menu screen

Go back to the Apple
CarPlay menu screen

uu

Audio System Basic Operation

u

Apple CarPlay

278

Features

■

Maps

Display Apple Maps and use the navigation function just as you would on your
iPhone.

Only one navigation system (pre-installed navigation or Apple CarPlay) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.

After you have connected your iPhone to the system via the 1.5A USB port, use the
following procedure to set up Apple CarPlay. Use of Apple CarPlay will result in the
transmission of certain user and vehicle information (such as vehicle location, speed,
and status) to your iPhone to enhance the Apple CarPlay experience. You will need
to consent to the sharing of this information on the Display Audio Screen.

■

Enabling Apple CarPlay

Enable once: Allows only once. (Prompt
shows again next time.)
Always Enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

■

Setting Up Apple CarPlay

1

Apple CarPlay

Apple CarPlay Operating Requirements &
Limitations
Apple CarPlay requires a compatible iPhone with an
active cellular connection and data plan. Your
carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Apple
CarPlay functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Apple CarPlay functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Apple CarPlay performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Apple CarPlay. Refer to the Apple
homepage for information on compatible apps.

Models with navigation system

1

Setting Up Apple CarPlay

You can also use the method below to set up Apple
CarPlay:
Select HOME

Settings

Smartphone

Apple

CarPlay

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to /from your iPhone by Apple CarPlay is
governed by the Apple iOS terms and conditions and
Apple’s Privacy Policy.

279

uu

Audio System Basic Operation

u

Apple CarPlay

Features

Press and hold the talk button to activate Siri.

■

Operating Apple CarPlay with Siri

1

Operating Apple CarPlay with Siri

Below are examples of questions and commands for
Siri.

•

What movies are playing today?

•

Call dad at work.

•

What song is this?

•

How’s the weather tomorrow?

•

Read my latest email.

•

Find a table for four tonight in Chicago.

For more information, please visit
www.apple.com/ios/siri.

 (Talk) button:

Press and hold to activate Siri.
Press again to deactivate Siri.
Press and release to activate standard voice recognition system.

280

uu

Audio System Basic Operation

u

Android Auto

Features

Android Auto

When you connect an Android phone to the Display Audio system via the 1.5A USB
port, Android Auto is automatically initiated. When connected via Android Auto,
you can use the audio/information screen to access the Phone, Google Maps
(Navigation), Google Play Music, and Google Now functions. When you first use
Android Auto, a tutorial will appear on the screen.
We recommend that you complete this tutorial while safely parked before using
Android Auto.

2 USB Ports P. 205
2 Auto Pairing Connection P. 282

1

Android Auto

To use Android Auto, you need to download the
Android Auto app from Google Play to your
smartphone.

Only Android 5.0 (Lollipop) or later versions are
compatible with Android Auto.
Bluetooth A2DP cannot be used with Android Auto
phone.

Park in a safe place before connecting your Android
phone to Android Auto and when launching any
compatible apps.

To use Android Auto, connect the USB cable to the
USB port (1.5A). The USB port (1.0A) will not enable
Android Auto operation.

2 USB Ports P. 205

When your Android phone is connected to Android
Auto, it is not possible to use the Bluetooth® Audio.
However, other previously paired phones can stream
audio via Bluetooth® while Android Auto is
connected.

2 Phone Setup P. 343

Continued

281

uu

Audio System Basic Operation

u

Android Auto

Features

a

 Maps (Navigation)

Display Google Maps and use the navigation function just as you would with your
Android phone. When the vehicle is in motion, it is not possible to make keyboard
entries. Stop the vehicle in a safe location to undertake a search or provide other
inputs.

Only one navigation system (pre-installed navigation or Android Auto) can give
directions at a time. When you are using one system, directions to any prior
destination set on the other system will be canceled, and the system you are
currently using will direct you to your destination.
The audio/information screen shows you turn-by-turn driving directions to your
destination.

b

 Phone (Communication)

Make and receive phone calls as well as listen to voicemail.

c

 Google Now (Home screen)

Display useful information organized by Android Auto into simple cards that appear
just when they’re needed.

■

Android Auto Menu

1

Android Auto

For details on countries and regions where Android
Auto is available, as well as information pertaining to
function, refer to the Android Auto homepage.

Android Auto Operating Requirements &
Limitations
Android Auto requires a compatible Android phone
with an active cellular connection and data plan.
Your carrier’s rate plans will apply.

Changes in operating systems, hardware, software,
and other technology integral to providing Android
Auto functionality, as well as new or revised
governmental regulations, may result in a decrease or
cessation of Android Auto functionality and services.
Honda cannot and does not provide any warranty or
guarantee of future Android Auto performance or
functionality.

It is possible to use 3rd party apps if they are
compatible with Android Auto. Refer to the Android
Auto homepage for information on compatible apps.

: Go back to

the Home screen

Android Auto icon

6

Models with navigation system

uu

Audio System Basic Operation

u

Android Auto

282

Features

d

 Music and audio

Play Google Play Music and music apps that are compatible with Android Auto.
To switch between music apps, press this icon.

e

 Go back to the Home Screen.

f

 Voice

Operate Android Auto with your voice.

When you connect an Android phone to the unit via the 1.5A USB port, Android
Auto is automatically initiated.

■

Enabling Android Auto

Enable once: Allows only once. (Prompt
shows again next time.)
Always Enable: Allows anytime. (Prompt
does not show again.)
Cancel: Does not allow this consent.

You may change the consent settings under
the Smartphone settings menu.

■

Auto Pairing Connection

1

Enabling Android Auto

Only initialize Android Auto when you safely parked.
When Android Auto first detects your phone, you will
need to set up your phone so that auto pairing is
possible. Refer to the instruction manual that came
with your phone.

You can use the method below to change Android
Auto settings after you have completed the initial
setup:
Select HOME

Settings

Smartphone

Android

Auto

Use of user and vehicle information
The use and handling of user and vehicle information
transmitted to /from your phone by Android Auto is
governed by the Google’s Privacy Policy.

283

uu

Audio System Basic Operation

u

Android Auto

Features

Press and hold the talk button to operate Android Auto with your voice.

■

Operating Android Auto with Voice Recognition

1

Operating Android Auto with Voice Recognition

Below are examples of commands you can give with
voice recognition:

•

Reply to text.

•

Call my wife.

•

Navigate to Honda.

•

Play my music.

•

Send a text message to my wife.

•

Call flower shop.

For more information, please refer to the Android
Auto homepage.

You can also activate the voice recognition function
by pressing the

 icon in the upper-right corner of

the screen.

 (Talk) button:

Press and hold to operate Android Auto with your voice.
Press and release to activate standard voice recognition system.

 (Hang-up/back) button:

Press to deactivate voice recognition.

284

Features

Audio Error Messages

iPod/USB Flash Drive

If an error occurs while playing an iPod or USB flash drive, you may see the following
error messages. If you cannot clear the error message, contact an authorized Honda
Clarity Plug-In Hybrid dealer.

Error Message

Solution

USB Error

Appears when there is a problem with the audio system. Check if the device is compatible with the
audio system.

A charging error has
occurred with the connected
USB device. When safe
please check the
compatibility of the device
and USB cable and try again.

Appears when an incompatible device is connected. Disconnect the device. Then turn the audio system
off, and turn it on again. Do not reconnect the device that caused the error.

Unsupported Version

Appears when an unsupported iPod is connected. If it appears when a supported iPod is connected,
update the iPod software to the newer version.

Connect Retry

Appears when the system does not acknowledge the iPod. Reconnect the iPod.

Unplayable File

Appears when the files in the USB flash drive are copyright protected or an unsupported format. This
error message appears for about three seconds, then plays the next song.

285

uu

Audio Error Messages

u

iPod/USB Flash Drive

Features

Error Message

Solution

No Data

Appears when the iPod is empty.

Appears when the USB flash drive is empty or there are no MP3, WMA, or AAC files in the USB flash
drive.

Check that compatible files are stored on the device.

Unsupported

Appears when an unsupported device is connected. If it appears when a supported device is
connected, reconnect the device.

iPod

USB flash drive

iPod and USB flash drive

286

uu

Audio Error Messages

u

Pandora®

Features

Pandora®

If an error occurs while playing Pandora®, you may see the following error messages.
If you cannot clear the error message, contact an authorized Honda Clarity Plug-In
Hybrid dealer.

Error Message

Solution

To begin listening, select a station from the Stations list.

Appears when there is no station list on the device. Use the device
to create a station.

The maximum number of tracks that can be skipped has been
reached.

Appears when you try to skip a track or select Like/Dislike over
the predetermined number of times in an hour.

Unable to play PANDORA. Please try again later.
Unable to rate track. Please try again.
Unable to save bookmark.

Appears when the commanded operation fails. Try again later.

No Data

Appears when no data is available with Pandora® activated.
Reboot the app and reconnect the device.

PANDORA App version is not supported.

Appears when Pandora® version is not supported. Update
Pandora® to the latest version.

PANDORA system maintenance.

Appears when the Pandora® server is in maintenance. Try again
later.

Unable to connect to PANDORA. When stopped, check your
mobile phone.

Appears when Pandora® is unable to play music. Check your
device.

Unable to connect to PANDORA. When stopped, check your
mobile phone.

Appears when Pandora® app is not installed on your device. Install
Pandora® app to your device.

U.S. models

287

uu

Audio Error Messages

u

Android/Apps

Features

Android/Apps

If an error occurs while using the audio system or apps, you may see the following
error messages. If you cannot clear the error message, contact an authorized Honda
Clarity Plug-In Hybrid dealer.

*1:****part is variable characters, and will change depending upon where an error

occurs.

Error Message

*1

Solution

Unfortunately, **** has
stopped.

Error has occurred within app, select OK on the screen to close the app.

**** is not responding.
Would you like to close it?

App is not responding.
Select Wait if you can wait for a response from app a little longer. If it does not respond even if you keep
waiting, select OK to close the app and restart it. If the error message continues, perform Factory Data
Reset.

2 Defaulting All the Settings P. 331
