Honda Civic Hatchback (2018 year). Instruction - part 14

Interior Lights/Interior Convenience Items

Interior Convenience Items

208

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

Move the armrest rearward to use the
beverage holders.

To place a short beverage container:
Move the removable beverage holder tray
forward.

To place a tall beverage container: Move
the removable beverage holder tray rearward.

■

Beverage Holders

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

209

Interior Lights/Interior Convenience Items

Interior Convenience Items

Continued

Co
ntrols

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

Are located on the rear seat.

1.5 L engine models

2.0 L engine models

* Not available on all models

210

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

■

Door beverage holders

Front seat

Rear seat

Continued

211

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The accessory power socket can be used when the ignition switch is in ACCESSORY

(

q or ON

(

Open the cover to use it.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Accessory Power Socket

Accessory Power Socket

NOTICE

Do not insert an automotive type cigarette lighter
element. This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

Interior Lights/Interior Convenience Items

Interior Convenience Items

212

Co
ntrols

To use the wireless charger, the power mode must be in ACCESSORY or ON.
Charge a compatible device on the area indicated by the

mark as follows:

1. To turn the system on and off, press and

hold the

(power) button.

When the system is activated, the green
indicator light comes on.

2. Place the device you want to charge on the

charging area.

The system will automatically start
charging the device, and the amber
indicator light will come on.

Make sure that the device is compatible
with the system, and placed with the
chargeable side in the center of the
charging area.

3. When charging is completed, the green

indicator light will come on.

Depending on the device, the amber
indicator light will stay on.

■

Wireless Charger

Canadian models

Wireless Charger

This system consumes a lot of power. Do not use the
system for a long time when the engine is not
running. This may weaken the battery, making it
difficult to start the engine.

When using the wireless charger, check the user’s
manual that came with the compatible device you
want to charge.

CAUTION

Metal objects between the charge pad and
the device to be charged will get hot and
can burn you.
• Always remove foreign objects from the

charge pad before charging the device.

• Be sure the surface is clear of dust and

other debris before charging.

• Do not spill liquids (i. e. water, drinks,

etc.) on the charger and the device.

• Do not use oil, grease, alcohol, benzine

or thinner for cleaning the charge pad.

• Do not cover the system with towels,

clothing, or other objects while charging
etc.

• Avoid spraying aerosols which may come

in contact with the change pad surface.

Green Indicator

Amber Indicator

Charging Area

(Power) Button

* Not available on all models

Continued

213

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
center of the charging
area where

located.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

Wireless Charger

NOTICE

Do not place any magnetic recording media or precision
machines within the charging area while charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches can go wrong.

“Qi” and

marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic waves or noises, such as TV
station, electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors and the hatch are closed
- to avoid interference with the proper functioning
of the smart entry system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

* Not available on all models

Interior Lights/Interior Convenience Items

Interior Convenience Items

214

Co
ntrols

There are coat hooks on the left and right
door pillars.

■

Coat Hooks

Coat Hooks

The coat hook is not designed for large or heavy
items.

Continued

215

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The cargo hook in the cargo area can be used
to hang a light items.

The tie-down anchors on the cargo area floor
can be used to install a net for securing items.

■

Cargo Hook

Cargo Hook

NOTICE

Do not hang a large object or an object that weighs
more than 6 lbs (3 kg) on the cargo hook.
Hanging heavy or large objects may damage the
hook.

Hook

■

Tie-down Anchors

Tie-down Anchors

Do not let anyone access items in the cargo area
while driving. Loose items can cause injury if you have
to brake hard.

Anchor

Interior Lights/Interior Convenience Items

Interior Convenience Items

216

Co
ntrols

The cargo area cover can be used to conceal
your parcels and protect them from direct
sunlight.

■

To extend:

Pull the handle fully towards the hook on the
other side and let the hook catch hold of the
handle.

■

To retract:

Slip the rods out of the hooks, then slowly roll
it back until it is completely retracted.

■

Cargo area cover extension

The extension is attached at the back of the
hatch by four clips. It extends the covering
area when you close the hatch. To remove,
unclip the extension from the hatch. When
reinstalling the extension, make sure that the
tabs come to the near side.

■

Cargo Area Cover

Cargo Area Cover

Do not access parcels in the cargo area while driving.
This may cause injury if you have to brake hard.

Do not stack objects higher than the top of the seat
in the cargo area. They could block your view and be
thrown about the vehicle during a sudden stop.

To prevent cargo area cover damage:

•

Do not place items on the cargo area cover.

•

Do not put weight on the cargo area cover.

Handle

Hooks

Extension

Clips

Tab

Clips

217

Interior Lights/Interior Convenience Items

Interior Convenience Items

Continued

Co
ntrols

■

To remove:

Push and hold the lever in the direction of the
arrow mark on the housing and lift the
housing out of its position.

The housing can be installed on either side of
the cargo area.

Mark

Lever

Interior Lights/Interior Convenience Items

Interior Convenience Items

218

Co
ntrols

The ignition switch must be in ON

(

to use

the seat heaters.

Press the seat heater button:
Once - The HI setting (three indicators on)
Twice - The MID setting (two indicators on)
Three times - The LO setting (one indicator on)
Four times - The OFF setting (no indicators on)

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Front Seat Heaters

Front Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

219

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The power mode must be in ON to use the
seat heaters.

There is no heater in the rear center seating
position.

While in HI, the heater cycles on and off.

The appropriate indicator will be on
while the seat heater is on. Briefly press
the switch on the opposite side to turn
the heater off. The indicator will be off.

■

Rear Seat Heaters

Rear Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

In the LO setting, the heater runs continuously and
does not automatically turn off.

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

* Not available on all models

220

Co
ntrols

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the temperature control dial.
3. Press the

(ON/OFF) button to cancel.

Using Automatic Climate Control

If any buttons/icons

are pressed while using the

climate control system in auto, the function of the
button/icon

that was pressed will take priority.

The AUTO indicator will go off, but functions
unrelated to the button/icon

that was pressed will

be controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on auto, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Models with color audio system

AUTO Button

Temperature
Control Dial

(Recirculation) Button

(ON/OFF) Button

Fan Control
Dial

A/C (Air
Conditioning)
Button

Dashboard
vents

Dashboard
and floor
vents

Floor vents

Floor and
defroster
vents

* Not available on all models

Continued

221

Climate Control System

Using Automatic Climate Control

Co
ntrols

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the temperature control dial.
3. Press the

(ON/OFF) button to cancel.

Using Automatic Climate Control

Pressing the

button switches the climate control

system between on and off. When turned on, the
system returns to your last selection.

While ECON mode is active, the climate control
system may have reduced cooling performance.

Press the

(CLIMATE) button to display

A/C, MODE, fan control information on the audio/
information screen to operate manually. Select icon
to turn on or off A/C, change the vent mode, or
change the fan speed.

Models with ECON button

Models with Display Audio

Models without SYNC button

A/C (Air Conditioning) Icon

Fan Control Icon

Temperature
Control Dial

AUTO Button

(Recirculation) Button

(CLIMATE)

Button

Fan Control
Dial

(ON/OFF) Button

(Fresh Air) Button

MODE Control
Icon
(Floor vents)

MODE Control
Icon
(Dashboard vents)

MODE Control Icon
(Floor and
defroster vents)

MODE Control Icon
(Dashboard and
floor vents)

222

Climate Control System

Using Automatic Climate Control

Co
ntrols

Use the system when the engine is running.
1. Press the AUTO button.
2. Adjust the interior temperature using the driver’s side or passenger’s side

temperature control dial.

3. Press the

(ON/OFF) button to cancel.

Models with Display Audio

Models with SYNC button

A/C (Air Conditioning) Icon

MODE Control
Icon
(Floor vents)

Fan Control Icon

Driver’s Side
Temperature
Control Dial

AUTO Button

(Recirculation) Button

(CLIMATE) Button

Passenger’s
Side
Temperature
Control Dial

(ON/OFF) Button

SYNC (Synchronization) Button

MODE Control
Icon
(Dashboard vents)

MODE Control Icon
(Floor and
defroster vents)

MODE Control Icon
(Dashboard and
floor vents)

223

Climate Control System

Using Automatic Climate Control

Continued

Co
ntrols

■

Switching between the recirculation and fresh air modes

Press the

(recirculation) button and switch the mode depending on

environmental conditions.
Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.
Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

Press the

(recirculation) or

(fresh air) button to switch the mode

depending on environmental conditions.

Recirculation mode (indicator on): Recirculates air from the vehicle’s interior

through the system.

Fresh air mode (indicator on): Maintains outside ventilation. Keep the system

in fresh air mode in normal situations.

Models without fresh air button

Models with fresh air button

Content .. 12 13 14 15 ..
