Honda Civic Coupe (2019 year). Instruction - part 6

80

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Shift Lever
Position
Indicator

*

●

Indicates the current shift lever
position.

2 Shifting P. 442, 444

—

Transmission
System
Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Blinks if the transmission system
has a problem.

●

Blinks while driving - Avoid sudden
starts and acceleration and have your
vehicle checked by a dealer immediately.

M (7-speed
manual shift
mode) Indicator/
Shift Indicator

*

●

Comes on when 7-speed manual
shift mode is applied.

2 7-Speed Manual Shift Mode P. 446

—

Shift Up
Indicator

*

●

Comes on when shifting up is
recommended.

2 Shift Up/Down Indicators

*

 P. 449

—

Shift Down
Indicator

*

●

Comes on when shifting down is
recommended.

2 Shift Up/Down Indicators

*

 P. 449

—

* Not available on all models

81

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Seat Belt
Reminder
Indicator

●

Comes on and the beeper sounds
if you are not wearing a seat belt
when you turn the ignition switch
to ON

(

w

*1

.

●

If the front passenger is not
wearing a seat belt, the indicator
comes on a few seconds later.

●

Blinks while driving if either you or
the front passenger has not
fastened a seat belt. The beeper
sounds and the indicator blinks at
regular intervals.

●

The beeper stops and the indicator goes
off when you and the front passenger
fasten their seat belts.

●

Stays on after you or the front
passenger has fastened the seat belt
- A detection error may have occurred in
the sensor. Have your vehicle checked by
a dealer.

2 Seat Belt Reminder P. 40

82

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Low Fuel
Indicator

●

Comes on when the fuel reserve is
running low (approximately 1.8
U.S. gal/7.0 Liter left).

●

Blinks if there is a problem with
the fuel gauge.

●

Comes on - Refuel your vehicle as soon
as possible.

●

Blinks - Have your vehicle checked by a
dealer.

Anti-lock Brake
System (ABS)
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

If it comes on at any other time,
there is a problem with the ABS.

●

Stays on constantly - Have your vehicle
checked by a dealer. With this indicator
on, your vehicle still has normal braking
ability but no anti-lock function.

2 Anti-lock Brake System (ABS) P. 533

Supplemental
Restraint System
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if a problem with any of
the following is detected:
- Supplemental restraint system
- Side airbag system
- Side curtain airbag system
- Seat belt tensioner

●

Stays on constantly or does not come
on at all - Have your vehicle checked by
a dealer.

Auto High-Beam
Indicator

*

• Comes on when all the operating

conditions of the auto high-beam
are met.

2 Auto High-Beam

*

 P. 170

—

* Not available on all models

83

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Vehicle Stability
Assist® (VSA®)
System Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Blinks when VSA® is active.

●

Comes on if there is a problem
with the VSA® system or hill start
assist system.

●

Stays on constantly - Have your vehicle
checked by a dealer.

2 Vehicle Stability Assist® (VSA®), aka

Electronic Stability Control (ESC),
System P. 457

●

Comes on if the VSA® system is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

Vehicle Stability
Assist® (VSA®)
OFF Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when you partially
disable VSA®.

2 VSA® On and Off P. 458

●

Comes on if the VSA® system is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

84

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Electric Power
Steering (EPS)
System Indicator

●

Comes on when you turn the
ignition switch to ON

(

w

*1

, and

goes off when the engine starts.

●

Comes on if there is a problem
with the EPS system.

●

Stays on constantly or does not come
on at all - Have your vehicle checked by
a dealer.

2 If the Electric Power Steering (EPS)

System Indicator Comes On P. 639

SPORT Mode
Indicator

*

●

Comes on when you press the
SPORT button.

●

The shift up backlight remains lit
up in red as long as SPORT mode is
on.

2 SPORT Mode

*

 P. 451

* Not available on all models

85

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Low Tire
Pressure/TPMS
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

.

●

May come on briefly if the ignition
switch is turned to ON

(

w

*1

 and

the vehicle is not moved within 45
seconds, to indicate the calibration
process is not yet complete.

●

Comes on and stays on when:
- One or more tires’ pressures are

determined to be significantly
low.

- The system has not been

calibrated.

●

Comes on while driving - Stop in a safe
place, check tire pressures, and inflate the
tire(s) if necessary.

●

Stays on after the tires are inflated to
the recommended pressures - The
system needs to be calibrated.

2 TPMS Calibration P. 461

●

Blinks for about one minute, and
then stays on if there is a problem
with the TPMS, or when a compact
spare tire

*

 is temporarily installed.

●

Blinks and remains on - Have your
vehicle checked by a dealer. If the vehicle
is fitted with a compact spare, get your
regular tire repaired or replaced and put
back on your vehicle as soon as you can.

●

Comes on if the TPMS is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

U.S.
models

* Not available on all models

86

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

System Message
Indicator

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on along with a beep
when a problem is detected. A
system message on the driver
information interface appears at
the same time.

●

While the indicator is on, press the



(display/information) button to see the
message again.

●

Refer to the Indicators information in this
chapter when a system message appears
on the driver information interface. Take
the appropriate action for the message.

●

The driver information interface does not
return to the normal screen unless the
warning is canceled, or the

 button

is pressed.

—

Turn Signal and
Hazard Warning
Indicators

●

Blinks when you operate the turn
signal lever.

●

Blink along with all turn signals
when you press the hazard
warning button.

●

Does not blink or blinks rapidly

2 Replacing Light Bulbs P. 574, 576,

577

—

High Beam
Indicator

●

Comes on when the high beam
headlights are on.

—

—

Lights On
Indicator

●

Comes on when the light switch
in a position other than OFF or
when the switch is set to AUTO

*



and the exterior lights come on.

●

If you remove the key from the ignition
switch

*1

 while the exterior lights are on, a

chime sounds when the driver’s door is
opened.

—

Fog Light
Indicator

*

●

Comes on when the fog lights are
on.

2 Fog Lights

*

 P. 169

—

* Not available on all models

87

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.
*2:Canadian models only: Apply and hold the brake pedal before turning the ignition on.
*3:Canadian models without smart entry system
*4:Canadian models with smart entry system
*5:Continuously variable transmission models
*6:Manual transmission models

Indicator

Name

On/Blinking

Explanation

Message

Immobilizer
System Indicator

●

Blinks if the immobilizer system
cannot recognize the key
information.

●

Blinks - You cannot start the engine. Turn
the ignition switch to LOCK

(

0

*1

, pull the

key out

*2

, and then insert the key and turn it

to ON

(

w

*1

 again.

Indicator

*3, *5

*3, *6

*3

*4, *5

*4, *6

*4, *5

*4, *6

88

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Immobilizer
System Indicator

●

Blinks if the immobilizer system
cannot recognize the key
information.

●

Repeatedly blinks - The system may be
malfunctioning. Have your vehicle
checked by a dealer.

●

Do not attempt to alter this system or add
other devices to it. Electrical problems can
occur.

—

Security System
Alarm Indicator

●

Blinks when the security system
alarm has been set.

2 Security System Alarm P. 153

—

ECON Mode
Indicator

*

●

Comes on when you press the
ECON button.

2 ECON Mode

*

 P. 452

CRUISE MAIN
Indicator

*

●

Comes on when you press the
CRUISE button.

2 Cruise Control* P. 454

—

CRUISE
CONTROL
Indicator

*

●

Comes on if you have set a speed
for cruise control.

2 Cruise Control* P. 454

—

Indicator

Indicator

* Not available on all models

89

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation (RDM)
Indicator

*

●

Comes on for a few seconds
when you turn the ignition switch
to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem
with the RDM system.

●

Stays on constantly - Have your vehicle
checked by a dealer.

●

Comes on if the RDM is
deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

* Not available on all models

90

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Road Departure
Mitigation (RDM)
Indicator

*

●

Comes on when the RDM system
shuts itself off.

●

Stays on - The temperature inside the
camera is too high.
Use the climate control system to cool
down the camera.
The system activates when the
temperature inside the camera cools
down.

2 Front Sensor Camera P. 524

●

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator and message come back on
after you cleaned the area around the
camera.

2 Front Sensor Camera P. 524

●

Comes on if there is a problem
with the RDM system.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 429

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

* Not available on all models

91

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Adaptive Cruise
Control (ACC)
with Low Speed
Follow (LSF)

*



Indicator
(Amber)

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem
with ACC with LSF

*

.

●

Comes on while driving - Have your
vehicle checked by a dealer.

●

Comes on if the ACC with LSF

*

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

●

Comes on if there is a problem
with ACC with LSF

*

.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

ACC with LSF

*

 has been

automatically canceled.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 429

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

Adaptive Cruise
Control (ACC)
with Low Speed
Follow (LSF)

*



Indicator
(Green)

*

●

Comes on when you press the
MAIN button.

2 Adaptive Cruise Control (ACC) with

Low Speed Follow (LSF)

*

 P. 481

2 Adaptive Cruise Control (ACC)

*

 P. 497

—

* Not available on all models

92

uu

Indicators

u

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Lane Keeping
Assist System
(LKAS) Indicator
(Amber)

*

●

Comes on for a few seconds
when you turn the ignition switch
to ON

(

w

*1

, then goes off.

●

Comes on if there is a problem
with the LKAS.

●

Stays on constantly - Have your vehicle
checked by a dealer.

Lane Keeping
Assist System
(LKAS) Indicator
(Green)

*

●

Comes on when you press the
MAIN button.

2 Lane Keeping Assist System (LKAS)

P. 512

—

* Not available on all models

93

uu

Indicators

u

Continued

In

strum

e

nt Pa

nel

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an ignition switch.

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

)

Indicator

*

●

Comes on for a few seconds when
you turn the ignition switch to ON

(

w

*1

, then goes off.

●

Comes on when you deactivate
the CMBS

TM

. A driver information

interface message appears for five
seconds.

●

Comes on if there is a problem
with the CMBS

TM

.

●

Stays on constantly without the
CMBS

TM

 off - Have your vehicle checked

by a dealer.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

) P. 471

●

Comes on if the CMBS

TM

 is

deactivated temporarily after the
battery has been disconnected,
then re-connected.

●

Drive a short distance at more than 12
mph (20 km/h). The indicator should go
off. If it does not, have your vehicle
checked by a dealer.

* Not available on all models

94

uu

Indicators

u

In

strum

e

nt Pa

nel

Indicator

Name

On/Blinking

Explanation

Message

Collision
Mitigation
Braking
System

TM



(CMBS

TM

)

Indicator

*

●

Comes on when the CMBS

TM



shuts itself off.

●

Stays on - The area around the camera is
blocked by dirt, mud, etc. Stop your
vehicle in a safe place, and wipe it off with
a soft cloth.

2 Front Sensor Camera P. 524

●

When the radar sensor gets dirty, stop
your vehicle in a safe place, and wipe off
dirt using a soft cloth.

●

Have your vehicle checked by a dealer if
the indicator does not go off even after
you clean the sensor cover.

2 Collision Mitigation Braking

System

TM

 (CMBS

TM

) P. 471

●

Stays on - The temperature inside the
camera is too high. Use the climate control
system to cool down the camera. The
system activates when the temperature
inside the camera cools down.

2 Front Sensor Camera P. 524

●

Comes on if there is a problem
with the CMBS

TM

.

●

Indicator may comes on
temporarily when the Maximum
Load Limit is exceeded.

●

Make sure the total load is within the
Maximum Load Limit.

2 Maximum Load Limit P. 429

●

Stays on constantly - Have your vehicle
checked by a dealer.

—

* Not available on all models

95

uu

Indicators

u

Driver Information Interface Warning and Information Messages

Continued

In

strum

e

nt Pa

nel

Driver Information Interface Warning and Information Messages

The following messages appear only on the driver information interface. Press the

 (display/information) button to see the message

again with the system message indicator on.

Message

Condition

Explanation

●

Appears if either door or the trunk is not completely
closed.

●

Appears if either door or the trunk is opened while
driving. The beeper sounds.

●

Goes off when both doors and the trunk are closed.

●

Appears when the washer fluid gets low.

●

Refill the washer fluid.

2 Refilling Window Washer Fluid P. 569

●

Appears when the scheduled maintenance is due
soon.

●

Consequently, Maintenance Due Now and
Maintenance Past Due follow.

2 Maintenance Minder Messages on the Driver

Information Interface P. 551

●

Appears when there is a problem with the sensor on
the battery.

●

Have your vehicle checked by a dealer.

2 Checking the Battery P. 592

●

Appears along with the battery charging system
indicator when the battery is not charging.

●

Turn off the climate control system and rear defogger to
reduce electricity consumption.

2 If the Charging System Indicator Comes On P. 635

●

Appears when the engine coolant temperature gets
abnormally high.

2 Overheating P. 633

Canadian models
