160

Co
ntrols

Adjusting the Seats

Adjusting the Seat Positions

Adjust the driver's seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger's seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the front power seat(s)

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

Horizontal Position
Adjustment

Height Adjustment
(Driver’s seat only)

Seat-back Angle
Adjustment

Lumbar Support
Adjustment
(Driver’s seat only)

* Not available on all models

Continued

161

Adjusting the Seats

Adjusting the Seat Positions

Co
ntrols

■

Adjusting the front manual seat(s)

Adjusting the front manual seat(s)

Once a seat is adjusted correctly, rock it back and
forth to make sure it is locked in position.

Horizontal Position
Adjustment
Pull up on the bar to move the
seat, then release the bar.

Height Adjustment
(Driver side only)
Pull up or push down the lever
to raise or lower the seat.

Seat-back Angle
Adjustment
Pull up the lever to
change the angle.

Driver’s seat is shown.

* Not available on all models

Adjusting the Seats

Adjusting the Seat Positions

162

Co
ntrols

Adjust the driver's seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The front seat passenger should also adjust
their seat-back to a comfortable, upright
position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant's chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

163

Adjusting the Seats

Head Restraints

Continued

Co
ntrols

Head Restraints

Your vehicle is equipped with head restraints
in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant's head rests against the
center of the restraint. The tops of the
occupant's ears should be level with the
center height of the restraint.
To raise the head restraint: Pull it upward.
To lower the head restraint: Push it down
while pressing the release button.

■

Adjusting the Front and Rear Outer Head Restraint Positions

Head Restraints

In order for the head restraint system to work
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any object between an occupant and
the seat-back.

•

Install each restraint in its proper location.

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

Adjusting the Seats

Head Restraints

164

Co
ntrols

A passenger sitting in the center back seating
position should adjust the height of their head
restraint to an appropriate position before the
vehicle begins moving.
To raise the head restraint:
Pull it upward.
To lower the head restraint:
Push it down while pressing the release
button.

Head restraints can be removed for cleaning or repair.

To remove a head restraint:
Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:
Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Changing the Rear Center Seat Head Restraint Positions

■

Removing and Reinstalling the Head Restraints

Removing and Reinstalling the Head Restraints

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

165

Adjusting the Seats

Maintain a Proper Sitting Position

Co
ntrols

Maintain a Proper Sitting Position

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine is
off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is greatly
increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

Maintain a Proper Sitting Position

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

166

Adjusting the Seats

Rear Seats

Co
ntrols

Rear Seats

1. Remove the center shoulder belt from the

guide.

2. Pull the release lever in the trunk to release

the lock.

3. Fold the seat-back down.

If the rear head restraints get caught on the
front seat-backs, remove the head restraints.

2 Removing and Reinstalling the Head

Restraints P. 164

■

Folding Down the Rear Seat

Folding Down the Rear Seat

The rear seat-back(s

) can be folded down to

accommodate bulkier items in the trunk.

Never drive with the seat-back folded down and the
trunk lid open.

2 Exhaust Gas Hazard P. 64

To lock a seat-back upright, push it backwards until it
locks.
When returning the seat-back to its original position,
push it firmly back. Also, make sure all rear shoulder
belts are positioned in front of the seat-back, and the
center shoulder belt is re-positioned in the guide.

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

2 Passenger Airbag Off Indicator P. 50

Make sure all items in the trunk or items
extending through the opening into the rear
seat is properly secured. Loose items can fly
forward if you have to brake hard.

The front seat(s) must be far enough forward so they
do not interfere with the rear seats as they fold
down.

Guide

Center
Shoulder Belt

Release
Lever

* Not available on all models

167

Adjusting the Seats

Armrest

Co
ntrols

Armrest

Pull down the armrest in the center seat-back.

■

Using the Rear Seat Armrest

168

Co
ntrols

Interior Lights/Interior Convenience Items

Interior Lights

■

The interior lights come on regardless of
whether the doors are open or closed.

■

Door activated

The interior lights come on in the following
situations:
• When any of the doors are opened.
• You unlock the driver’s door.

• You remove the key from the ignition

switch.

• When the power mode is set to VEHICLE

OFF (LOCK).

■

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

■

Interior Light Switches

Interior Light Switches

In the door activated position, the interior lights fade out
and go off about 30 seconds after the doors are closed.
The lights go off after 30 seconds in the following
situations:

•

When you unlock the driver's door but do not open it.

•

When you remove the key from the ignition switch
but do not open a door.

•

When you set the power mode to VEHICLE OFF
(LOCK) but do not open a door.

You can change the interior lights dimming time.

2 Customized Features P. 103, 298 , 316

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you turn the ignition switch to ON

(

•

When you close the driver’s door with the key in
the ignition switch.

•

When you close the driver’s door in ACCESSORY
mode.

If you leave any of the doors open without the key in
the ignition switch

, the interior lights go off after

about 15 minutes.

*1: Models with the smart entry system have an ENGINE
START/STOP button instead of an ignition switch.

Models without smart entry system

Models with smart entry system

Models without smart entry system

Models with smart entry system

Door Activated Position

Off

Door Activated
Position

Off

Models without smart entry system

Models with smart entry system

169

Interior Lights/Interior Convenience Items

Interior Lights

Co
ntrols

The map lights can be turned on and off by
pressing the lenses.

■

Map Lights

Map Lights

When the ceiling light switch is in the door activated
position and any door is open, the map light will not
go off when you press the lens.

170

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

Interior Convenience Items

Pull the handle to open the glove box.

You can lock the glove box with the built-in
key.

Pull the handle to open the console
compartment.

■

Glove Box

Glove Box

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

Handle

To Lock

Models with smart entry system

■

Console Compartment

171

Interior Lights/Interior Convenience Items

Interior Convenience Items

Continued

Co
ntrols

Pull the handle to open the pocket.

■

Center Pocket

Handle

Interior Lights/Interior Convenience Items

Interior Convenience Items

172

Co
ntrols

■

Front seat beverage holders

Are located in the console between the front
seats.

■

Front door beverage holders

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

■

Beverage Holders

Beverage Holders

NOTICE

Spilled liquids damage the upholstery, carpeting, and
electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Continued

173

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

The accessory power sockets can be used when the ignition switch is in ACCESSORY

(

q or ON

(

■

Accessory power socket (console panel)

Open the cover to use it.

■

Accessory power socket (console
compartment)

Open the console lid and the cover to use it.

*1: Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Accessory Power Sockets

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.

The accessory power socket is designed to supply
power for 12-volt DC accessories that are rated 180
watts (15 amps) or less.

To prevent battery drain, only use the power socket
with the engine running.

When both sockets are being used, the combined
power rating of the accessories should not exceed
180 watts (15 amps).

Interior Lights/Interior Convenience Items

Interior Convenience Items

174

Co
ntrols

To use the wireless charger, the ignition switch must be in ACCESSORY

(

q or ON

(

Charge a compatible device on the area indicated by the

mark as follows:

1. To turn the system on and off, press and

hold the

(power) button.

When the system is activated, the green
indicator light comes on.

2. Place the device you want to charge on the

charging area.

The system will automatically start
charging the device, and the amber
indicator light will come on.

Make sure that the device is compatible
with the system, and placed with the
chargeable side in the center of the
charging area.

3. When charging is completed, the green

indicator light will come on.

Depending on the device, the amber
indicator light will stay on.

*1:Models with the smart entry system have an ENGINE START/STOP button instead of an
ignition switch.

■

Wireless Charger

Wireless Charger

This system consumes a lot of power, so do not use
the system for a long time when the engine is not
running. This may weaken the battery, making it
difficult to start the engine.

When using the wireless charger, check the user’s manual that
came with the compatible device you want to charge.

CAUTION

Metal objects between the charge pad
and the device to be charged will get
hot and can burn you.
• Always remove foreign objects from

the charge pad before charging the
device.

• Be sure the surface is clear of dust and

other debris before charging.

• Do not spill liquids (i. e. water, drinks,

etc.) on the charger and the device.

• Do not use oil, grease, alcohol,

benzine or thinner for cleaning the
charge pad.

• Do not cover the system with towels,

clothing, or other objects while
charging etc.

• Avoid using spraying hair spray,

insecticides, etc, that may contact the
charge pad surface.

Green Indicator

Amber Indicator

Charging Area

(Power)

Button

* Not available on all models

Continued

175

Interior Lights/Interior Convenience Items

Interior Convenience Items

Co
ntrols

■

When charging does not start

Perform one of the solutions in the following table.

Indicator

Cause

Solution

Green

Amber

Blinking
simulta-

neously

There is an obstacle(s) between
the charging area and the
device.

Remove the
obstacle(s).

The device is not within the
charging area.

Move the device to the
center of the charging
area where

located.

Amber

Blinking

The wireless charger is faulty.

Contact a dealer for
repairs.

Wireless Charger

NOTICE

Do not place any magnetic recording media or
precision machines within the charging area while
charging.
The data on your cards such as credit cards can be
lost because of the magnetic effect. Also precision
machines such as watches can go wrong.

“Qi” and

marks are the registered trademarks

owned by Wireless Power Consortium (WPC).

In the following cases, charging may stop or not start:

•

The device is already fully charged.

•

The temperature of the device is extremely high
while charging.

•

You are at a place that emits strong
electromagnetic wave or noises such as TV station,
electric power plant, or gas station.

A device may not charge if the size or shape of its
chargeable side is not appropriate for use with the
charging area.

Not all devices are compatible with the system.

During the charging phase, it is normal for the
charging area and device to heat up.

Charging may be briefly interrupted when:

•

All the doors or the trunk are closed
- to avoid interference with the proper functioning
of the smart entry system.

•

The position of the device is altered.

Do not charge more than one device at a time on a
charging area.

* Not available on all models

Content .. 9 10 11 12 ..
