Symptom Troubleshooting (cont’d)

C503

SRS MAIN HARNESS 3P CONNECTOR

BLU

11. Turn the ignition switch ON (II), and measure

voltage.

Faulty SRS indicator circuit in the gauge

assembly; replace the SRS indicator circuit board in
the gauge assembly.

Go to step 12.

12. Turn the ignition switch OFF.

13. Disconnect the dashboard wire harness 3P

connector C503 from the SRS main harness (A).

14. Connect a voltmeter between the No. 1 terminal of

the SRS main harness 3P connector and body
ground.

15. Turn the ignition switch ON (II), and measure the

voltage.

Short to power in the BLU wire of the SRS

main harness; repair the harness.

Go to step 16.

16. Turn the ignition switch OFF.

17. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait 3 minutes.

18. Disconnect the driver’s airbag connector (A), front

passenger’s airbag connector (B), and both seat
belt tensioner 2P connectors (C).

Wire side of female terminals

Is ther e 8.5 V or less f or 6 seconds af ter the
ignition switch has been tur ned ON ( II)?

Is ther e 8.5 V or mor e f or 6 seconds af ter the
ignition switch has been tur ned ON ( II)?

03/07/29 10:41:24 61S0X050_230_0338

＋

−

０１

０７

YES

23-339

SRS MAIN HARNESS 18P CONNECTOR

19. Disconnect the SRS main harness 18P connector

(A) from the SRS unit.

20. Connect a voltmeter between the No. 6 terminal

(

) of the SRS main harness 18P connector and

body ground.

21. Turn the ignition switch ON (II), and measure the

voltage. There should be 0.5 V or less.

Faulty SRS unit; replace the SRS unit (see

page 23-382).

Short to power in the BLU wire of the SRS

main harness; replace the harness.

Wire side of female terminals

Is voltage as specif ied?

03/07/29 10:41:24 61S0X050_230_0339

−

０８

Ｓ０Ｘ４ＡＺ４Ｈ４６４０００５６６０２ＦＡＡＴ０１

’99-01 Models

SRS indicator stays on when in ‘‘SCS’’ menu
method

YES

23-340

SRS

Symptom Troubleshooting (cont’d)

NOTE:

• If you cannot retrieve DTCs with the HDS using the

SRS menu method, retrieve the flash codes with the
Tester in SCS mode (see page 23-36).

• A new SRS unit must sense the entire system is OK

before completing its initial self-test. The most
common cause of an incomplete self-test is the
failure to replace all deployed parts after a collision,
in particular, seat belt tensioners.

• An incomplete self-test prevents the HDS from

retrieving DTCs, although flash codes are available in
the Tester’s SCS mode.

1. Erase the DTC memory by ‘‘SCS’’ menu method

(see page 23-38).

Go to step 37.

Go to step 2.

2. Check the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

Go to step 17.

Go to step 3.

3. Replace the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

4. Turn the ignition switch ON (II) and wait for 30

seconds. Then turn the ignition switch OFF.

5. Check the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

The system is OK at this time.

Go to step 6.

6. Replace the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

7. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

8. Disconnect the driver’s airbag connector (A), front

passenger’s airbag connector (B), and both seat
belt tensioner 2P connectors (C).

Does the SRS indicator go of f while the DT C
memor y is er ased?

Is the f use OK ?

03/07/29 10:41:25 61S0X050_230_0340

−

０２

０３

１２

YES

23-341

9. Disconnect the SRS main harness 18P connector

(A) from the SRS unit.

10. Reconnect the negative battery cable.

11. Turn the ignition switch ON (II), and wait for 30

seconds. Then turn the ignition switch OFF.

12. Check the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

Short to ground in the SRS unit; replace the

SRS unit.

Go to step 13.

13. Replace the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

14. Disconnect the SRS main harness 2P connector (A)

from the driver’s under-dash fuse/relay box.

15. Turn the ignition switch ON (II), and wait for 30

seconds. Then turn the ignition switch OFF.

16. Check the No. 2 (10A) fuse in the driver’s under-

dash fuse/relay box.

Short to ground in the dashboard wire

harness; replace the dashboard wire harness.

Short to ground in the driver’s under-dash

fuse/relay box No. 2 (10A) fuse line; replace the
driver’s under-dash fuse/relay box or repair it.

17. Turn the ignition switch OFF. Disconnect the

battery negative cable, and wait for 3 minutes.

18. Disconnect the driver’s airbag connector (A), front

passenger’s airbag connector (B), and both seat
belt tensioner 2P connectors (C).

(cont’d)

Is the f use OK ?

03/07/29 10:41:26 61S0X050_230_0341
