Fig. 35: Locating Push Cam Ring From Pump Housing Cap Hole 37. Install the pump preload spring (A) in the pump housing. Fig. 36: Identifying Pump Preload Spring (With Torque Specifications) 38. Coat the new 12.7 mm O-ring (B) with power steering fluid, and install it on the pump housing cap (C). 39. Install the pump housing cap on the pump housing, and tighten it to the specified torque. 40. Install the pressure control valve spring (A) in the pump housing.
2008 Honda Civic EX 2006-08 STEERING Hydraulic Power Steering Components - Civic (All Except Hybrid)
|
