gearbox. Disconnect the exhaust mounting rubber (C). Fig. 36: Identifying Stiffner Plate And Mounting Bracket 24. Remove the stiffner plate (A) and harness clip (B). Fig. 37: Identifying Stiffner Plate And Harness Clip 25. Remove the front mount mounting bolt (A) and nut (B) then, remove the lower radiator hose from the front mount bracket.
2008 Honda Civic LX 2006-08 TRANSMISSION Manual Transmission (6-Speed)(Except Hybrid) - Civic
|
