Fig. 12: Identifying Rear Fender Cover Screws

2. Install the fender cover in the reverse order of removal.

REAR STRAKE REPLACEMENT

FOR SOME MODELS

Remove the bolts, then remove the rear strake (A) from the body.

1. Remove the clips (A) and bolts (B), then remove the rear floor undercover (C).

Take care not to scratch the rear bumper (D).

2008 Honda Civic EX

2006-08 ACCESSORIES AND EQUIPMENT Fenderwell - Civic (All Except Hybrid)

Fig. 13: Identifying Rear Floor Undercover Clips (With Torque
Specifications)

2. Install the strike in the reverse order of removal,

REAR AIR OUTLET REPLACEMENT

1. Remove the rear bumper (see REAR BUMPER

REMOVAL/INSTALLATION ).

2. Detach the hooks (A), then remove the rear air outlet (B). Take care not to

scratch the body.

Fig. 14: Removing Rear Air Outlet

3. Install the air outlet by pushing on the hook portions until the hooks snap into

place.

2008 Honda Civic EX

2006-08 ACCESSORIES AND EQUIPMENT Fenderwell - Civic (All Except Hybrid)

2006-08 ACCESSORIES AND EQUIPMENT

Frame - Civic (Except Hybrid)

UPPER DASHBOARD SUPPORT GUSSET REPLACEMENT

UPPER DASHBOARD SUPPORT GUSSET TORQUE

NOTE:

Refer to the FUEL FILL DOOR (GX) (SUPPLEMENT) article
for additional information for the GX model.

NOTE:

Take care not to scratch the body.

2008 Honda Civic EX

2006-08 ACCESSORIES AND EQUIPMENT Frame - Civic (Except Hybrid)

2008 Honda Civic EX

2006-08 ACCESSORIES AND EQUIPMENT Frame - Civic (Except Hybrid)

Fig. 1: Identifying Upper Dashboard Support Gusset Components (With
Torque Specifications)

REAR FLOOR UPPER CROSS-MEMBER GUSSET REPLACEMENT

REAR FLOOR UPPER CROSS-MEMBER GUSSET TORQUE

NOTE:

Take care not to scratch the body.

2008 Honda Civic EX

2006-08 ACCESSORIES AND EQUIPMENT Frame - Civic (Except Hybrid)
