Fig. 72: Detaching Harness Clip And Disconnecting Power Door Lock
Actuator Connector

3. Pass the cable (D) and the harnesses (E) through the holes (F) and slit (G) in

the plastic cover (H), then remove it.

4. Carefully move the glass (A) until you can see the bolts, then remove them.

Release the glass from the holder (B), then remove it from the regulator (C),
and carefully lower the glass. Take care not to drop the glass inside the door.

Fig. 73: Removing Glass And Bolts (With Specifications)

5. Remove the bolt (A) from the rear lower channel (B). Pull the glass run

channel (C) away as needed, and remove the screw (D).

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Doors - Civic (All Except Hybrid)

Fig. 74: Removing Rear Lower Channel Bolt (With Specifications)

6. Pull the glass run channel (A) away as needed. Pull the rear lower channel (B)

forward from the quarter glass seal (C) then release the upper hook (D) from
the door. Remove the rear lower channel from the rear door glass (E), then pull
the channel up to remove it.

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Doors - Civic (All Except Hybrid)

Fig. 75: Removing Rear Lower Channel From Rear Door Glass

7. Remove the rear lower channel (A) from the glass run channel (B).

Fig. 76: Removing Rear Lower Channel From Glass Run Channel

8. Carefully remove the glass (A) out through the window slot. Take care not to

drop the glass inside the door.

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Doors - Civic (All Except Hybrid)

Fig. 77: Removing Glass Out Through Window Slot

9. Remove the quarter glass (A). Take care not to damage the outer weatherstrip

(B).

Fig. 78: Removing Quarter Glass

10. Disconnect the connector (A) from the regulator (B).

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Doors - Civic (All Except Hybrid)
