The bolt will be screwed into the inside female screw of the adjusting nut 3 Loosen the bolt again to screw the externally threaded nut into the sleeve 4 Remove the bolt. Fig. 29: Removing Special Bolts From Outside Passenger Door 10. If necessary, remove the dashboard side cover (A). 1 Gently pull out along the rear edge to release the hooks (B). 2 Gently pull out on the side cover to release the hooks (C), then remove
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Dashboard - Civic (All Except Hybrid)
|
