10. Top of L4 Engine

FUEL INJECTORS

11. Front of L4 Engine

PRIMARY HO2S
CONNECTOR
(All except
’01-’02 L4 ULEV)
A/F SENSOR
(’01-’02 L4 ULEV)
(4-GRY)

12. Left Front of L4 Engine

ALTERNATOR

14. Left Rear of L4 Engine

IAT SENSOR

EVAP
CANISTER
PURGE
VALVE

G101
