Geely FC. Manual part - 97
Exterior/inner trim board--Exterior seal tape of left rear door glass Exterior seal tape of left rear door glass Change Hint: z When assembling, please work by the sequence which is opposite with disassembling sequence; if necessary, it will have assembling instruction. z Changing procedure for right side is same as left side. Protective adhesive tape 385 1. Disassemble exterior seal tape of left rear door glass [68000196] (a) Affix protective adhesive tape to the lower part of exterior seal tape of left rear door glass. (b) Use disassembling tool or scraper for trim tape to disas- semble exterior seal tape of left rear door glass. Hint: before using scraper, the needled top of scraper should be twisted with adhesive tape. |
