Fig. 19: Disconnecting Block Heater Wire Extension From Block Heater Wiring
Courtesy of FORD MOTOR CO.

3. Raise and support the vehicle. For additional information, refer to JACKING & HOISTING .

4. Disconnect the (A) block heater wiring from the (B) block heater (6A051) and remove.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup



Fig. 20: Disconnecting Block Heater Wiring From Block Heater
Courtesy of FORD MOTOR CO.

5. Remove the block heater.

1. Loosen the block heater retaining screw.

2. Twist and slide the block heater to release the retainer clip and remove. Discard the retainer clip.

CAUTION: Do not loosen the block heater retaining screw more than

necessary for removal.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup



Fig. 21: Removing Block Heater
Courtesy of FORD MOTOR CO.

NOTE:

To ease installation, coat the block heater seal and the cylinder block hole
with grease.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup



Fig. 22: Installing Block Heater
Courtesy of FORD MOTOR CO.

6. To install, reverse the removal procedure.

THERMOSTAT - 4.2L

Removal

1. Partially drain the cooling system. For additional information, refer to COOLING SYSTEM

DRAINING, FILLING & BLEEDING .

2. Remove the upper radiator hose.

3. Remove the water thermostat and paper gasket assembly.

1. Remove the bolts.

2. Remove the water outlet connection.

3. Remove the water thermostat and paper gasket assembly.



2003 Ford Pickup F150

2003 ENGINE Engine Cooling - F150 Pickup
