Fig. 438: Disconnecting IAC Electrical Connector - 4X2, 4.6L 15. Position the exhaust manifold to EGR valve tube aside. Disconnect the upper fitting. Loosen the lower fitting. Position the tube aside.
2003 Ford Pickup F150 2003 ENGINE Engine - 4.6L & 5.4L - F150 Pickup
|
