Fig. 114: Disconnecting Vent Hose
Courtesy of FORD MOTOR CO.

10. Remove the bolt.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Rear Drive Axle/Differential - Ford 9.75-inch - F150 Pickup



Fig. 115: Removing Bolt
Courtesy of FORD MOTOR CO.

11. Remove the brake lines from the clips.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Rear Drive Axle/Differential - Ford 9.75-inch - F150 Pickup



Fig. 116: Removing Brake Lines From Clips
Courtesy of FORD MOTOR CO.

12. Remove the driveshaft. For additional information, Refer to REMOVAL AND INSTALLATION .

13. Disconnect the electrical connector.



2003 Ford Pickup F150

2003 DRIVELINE/AXLES Rear Drive Axle/Differential - Ford 9.75-inch - F150 Pickup



Fig. 117: Disconnecting Electrical Connector
Courtesy of FORD MOTOR CO.

14. Remove the stabilizer-to-axle housing U-bolts and nuts.
