Fig. 16: Connecting A Clear Waste Line To Rh Rear Bleeder Screw And Other End In A Container
Partially Filled With Brake Fluid
Courtesy of FORD MOTOR CO.

3. Loosen the RH rear bleeder screw until a stream of brake fluid comes out. While the assistant maintains

pressure on the brake pedal (2455), tighten the RH rear bleeder screw.

z

Repeat until clear, bubble-free fluid comes out.

z

Refill the brake master cylinder reservoir as necessary.

4. Tighten the RH rear bleeder screw, and disconnect the waste line.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Brake System - General Information - F150 Pickup



Fig. 17: Identifying Rubber Drain Tube Connected To Bleeder Screw
Courtesy of FORD MOTOR CO.

5. Repeat Steps 2, 3 and 4 for the LH rear bleeder screw, the RH front disc brake caliper (2B120) bleeder

screw, and the LH front disc brake caliper bleeder screw, in that order.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Brake System - General Information - F150 Pickup



Fig. 18: Identifying Front Disc Brake Caliper Bleeder Screw
Courtesy of FORD MOTOR CO.

6. Connect the scan tool DCL cable adapter into the vehicle data link connector (DLC) under the dash, and

follow the scan tool instructions.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Brake System - General Information - F150 Pickup



Fig. 19: Connecting Scan Tool DCL Cable Adapter Into Vehicle Data Link Connector (DLC)
Under
Courtesy of FORD MOTOR CO.

7. Repeat the system bleed procedure as outlined in Steps 1 through 5.

Caliper

WARNING:

Use of any other than approved DOT 3 brake fluid will cause permanent
damage to brake components and will render the brakes inoperative.
