9. With all the restraint system diagnostic tools removed, prove out the supplemental restraint system (SRS).

Refer to SYSTEM OPERATION CHECK .

REAR SEAT CUSHION - SUPERCAB

Disassembly and Assembly

1. Remove the seat. Refer to REAR SEAT-SUPERCAB .

2. Unclip the J-clip.

Fig. 305: identifying Unclip J-Clip
Courtesy of FORD MOTOR CO.

3. Remove the upholstery (63804).

WARNING:

The restraint system diagnostic tool is for restraint system service
only. Remove from the vehicle prior to road use. Failure to remove
could result in injury and possible violation of vehicle safety
standards.

NOTE:

The 60 percent seat is shown. The 40 percent and captains seat are
similar.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 306: Removing Upholstery
Courtesy of FORD MOTOR CO.

4. Remove the seat cushion pad from the frame (63840).

5. To assemble, reverse the disassembly procedure.

REAR SEAT CUSHION - SUPERCREW 60 PERCENT

Disassembly and Assembly

1. Remove the seat. Refer to REAR SEAT-60 PERCENT, SUPERCREW .

2. Remove the seat backrest. For additional information refer to REAR SEAT BACKREST-

SUPERCREW 60 PERCENT .

3. Remove the safety belt divider.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 307: Removing Safety Belt Divider
Courtesy of FORD MOTOR CO.

4. Remove the seat backrest latch cable.

z

Release the cable tension and remove the cable from the cable pin and guide loop.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 308: Removing Seat Backrest Latch Cable
Courtesy of FORD MOTOR CO.

5. Remove the screw.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
