Fig. 56: Removing A/C Vacuum Reservoir Tank And Bracket
Courtesy of FORD MOTOR CO.

Installation

1. To install, reverse the removal procedure.

BLOWER MOTOR SPEED CONTROL

Removal and Installation

1. Disengage the stops and lower the glove compartment door.

NOTE:

When positioning the A/C vacuum reservoir tank, make sure that the
bottom locator and two top tabs align with the battery tray.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup



Fig. 57: Disengaging Stops
Courtesy of FORD MOTOR CO.

2. Remove the right front scuff plate.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup



Fig. 58: Removing Right Front Scuff Plate
Courtesy of FORD MOTOR CO.

3. Position aside the weatherstrip.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup



Fig. 59: Locating Weatherstrip
Courtesy of FORD MOTOR CO.

4. Remove the RH front kickpad.



2003 Ford Pickup F150

2003 HVAC Control Components - F150 Pickup
