CALIBRATION-TO-VACUUM DIAGRAM REFERENCE (RANGER)

Application/Calibration No.

See

2.3L

3-R31-A20-510/05, 3-R32-A20-510/05, 3-R32-B20-510/05

Fig. 30

3.0L

Flex Fuel

2-R31-AF0-512-10

Fig. 31

Under 3750 GVW

3-R31-A30-510/06,3-R31-C30-510/05, 3-R32-A30-510/06, 3-R32-C30-510/05

Fig. 31

Over 3750 GVW

3-R31-B30-511/10/06, 3-R32-B30-511/10/06

Fig. 31

4.0L

Under 3750 GVW

3-R31-A40-505, 3-R31-A40-505

Fig. 32

Under 3750 GVW - 112" Wheel Base

3-R31-D40-510/05

Fig. 32

Under 3750 GVW - 118" Wheel Base

3-R31-D40-510/05

Fig. 32

Over 3750 GVW

3-R31-E40-510/05, 3-R31-F40-510/05, 3-R31-B40-505, 3-R31-C40-505

Fig. 32



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Vacuum Diagrams - Trucks



Fig. 30: Vacuum Diagram - Ranger (2.3L)
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Vacuum Diagrams - Trucks





2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Vacuum Diagrams - Trucks



Fig. 31: Vacuum Diagram - Ranger (3.0L)
Courtesy of FORD MOTOR CO.

Fig. 32: Vacuum Diagram - Ranger (4.0L)
Courtesy of FORD MOTOR CO.

WINDSTAR

CALIBRATION-TO-VACUUM DIAGRAM REFERENCE (WINDSTAR)

Application/Calibration No.

See

3-A31-BA0-505

Fig. 33
