2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - F150 Pickup - CNG

Fig. 40: Locating Fuel Tank Solenoid Fuel Line & Electrical Connector
Courtesy of FORD MOTOR CO.

Fig. 41: Locating Upper Stone Shield Support Strap Bolt & Nut
Courtesy of FORD MOTOR CO.

2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - F150 Pickup - CNG

Fig. 42: Locating Rear Fuel Tank Support Strap Retaining Nut
Courtesy of FORD MOTOR CO.

2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - F150 Pickup - CNG

Fig. 43: Locating Front Fuel Tank Support Strap Retaining Bolts
Courtesy of FORD MOTOR CO.

FUEL TANK PRESSURE SENSOR

Manufacturer does not provide a removal and installation procedure. See Fig. 2 .

FUEL TANK SOLENOID

For removal & installation, see FUEL TANK SOLENOID under SOLENOIDS.

FUEL TANK TEMPERATURE SENSOR

For removal and installation, see FUEL TANK TEMPERATURE SENSOR under SENSORS &
SWITCHES.

TORQUE SPECIFICATIONS

Application

Ft. Lbs. (N.m)

Coalescer/Fuel Filter Bolts

16-23 (22-32)

Fuel Filter Cover

30 (41)
