Fig. 18: Removing Intake Manifold (4.6L)
Courtesy of FORD MOTOR CO.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Fig. 19: Intake Manifold Tightening Sequence (4.6L & 5.4L 2V)



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Courtesy of FORD MOTOR CO.

Removal & Installation (4.6L - Lower Intake Manifold)

1. Remove intake manifold. See REMOVAL & INSTALLATION (4.6L) . Remove fuel lines and

injectors. Remove noise shield from lower intake manifold. See Fig. 20 and Fig. 21 .

2. Remove lower intake manifold bolts. Remove lower intake manifold. Clean all mating surfaces.

3. To install, reverse removal procedure. Tighten fasteners to specification. See Fig. 22 . See TORQUE

SPECIFICATIONS . Fill and bleed the engine cooling system.



2003 Ford Pickup F150

2003 ENGINE PERFORMANCE Removal & Installation - Blackwood, Expedition, F150 Pickup & Navigator - Gasoline



Fig. 20: Exploded View Of Intake Manifold (4.6L - 1 Of 2)
Courtesy of FORD MOTOR CO.
