Fig. 26: Removing Fuel Tank Temperature Sensor
Courtesy of FORD MOTOR CO.

3. To install, reverse the removal procedure.

FUEL TANK PRESSURE SENSOR

Removal and Installation

1. Releive the bi-fuel system pressure. Refer to PRESSURE RELIEF -- NATURAL GAS BI-FUEL

SYSTEM .

2. Disconnect the electrical connector.

NOTE:

Make sure the surface area where the sensor is to be mounted is clean of
residue.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Bi-Fuel - F150 Pickup



Fig. 27: Disconnecting Electrical Connector
Courtesy of FORD MOTOR CO.

3. Remove the fuel tank pressure sensor.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Bi-Fuel - F150 Pickup



Fig. 28: Removing Fuel Tank Pressure Sensor
Courtesy of FORD MOTOR CO.

4. To install, reverse the removal procedure.



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Bi-Fuel - F150 Pickup



2003 ENGINE

Fuel Tank And Lines-Natural Gas - F150 Pickup

SPECIFICATIONS

GENERAL SPECIFICATIONS

Fig. 1: Fuel Tank And Lines - Natural Gas General Specifications
Courtesy of FORD MOTOR CO.

TORQUE SPECIFICATIONS



2003 Ford Pickup F150

2003 ENGINE Fuel Tank And Lines-Natural Gas - F150 Pickup
