Fig. 7: Identifying Special Tool(s)
Courtesy of FORD MOTOR CO.

Disconnect

1. Perform the fuel line venting procedure; refer to FUEL LINE EVACUATION .

2. Remove the fuel tube clip.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Fuel System - General Information - Natural Gas - F150 Pickup



Fig. 8: Removing Fuel Tube Clip
Courtesy of FORD MOTOR CO.

3. Install the Spring Lock Coupling Disconnect Tool.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Fuel System - General Information - Natural Gas - F150 Pickup



Fig. 9: Installing Spring Lock Coupling Disconnect Tool
Courtesy of FORD MOTOR CO.

4. Close and push the Spring Lock Coupling Disconnect Tool into the open side of the cage.



2003 Ford Pickup F150

2003 GENERAL INFORMATION Fuel System - General Information - Natural Gas - F150 Pickup



Fig. 10: Pushing Spring Lock Coupling Disconnect Tool Into Open Side Of Cage
Courtesy of FORD MOTOR CO.

5. Separate the fitting.
